Aquatic Serenity 3 Manuel utilisateur

SPECIFICATIONS:

The manufacturer accepts a 1/4” variance. There are variations on each tub and speciﬁcations are subject to change as we improve upon our product as required. The dimensions needed for site preparation

and structure building should be measured from the tub; Aquatic Industries, Inc. assumes no responsibility for preparatory work. www.aquaticwhirlpools.com 800.555.5324

March 2008

Rough-In Plumbing

Measurements

SErENITy 3

SErENITy Air Baths MODEL # AI3AIR7236 / AI3AIR7236TO (Tub Only)

GENERAL SPECIFICATIONS:

Tub Size 71 1/4” x 36” x 23 1/4”

181 cm x 91 cm x 59 cm

Bathing Well 48 1/2” long

24” wide

21 3/4” interior depth

Shipping Weight 245 lbs. / 111 kg

Tub Weight Filled 868 lbs. / 394 kg

Tub Only Weight 126 lbs. / 57 kg

Gallons to Overow 90 gal. / 341 L

ELECTRICAL SPECIFICATIONS:

Blower/Heater 1 HP; 10.5 AMP; 120V

Requirement 15 AMP; 120V, separate circuit

required protected w/ Class A GFCI

• Comfort Pillow - Oval or Rectangle

• Bolt-On Grab Bar

- White, Biscuit, Chrome, Polished Brass, Gold,

Polished Nickel, Satin Nickel or Oil Rubbed Bronze

• Lift & Turn Waste and Overow

- Chrome, Polished Brass, Gold, Polished Nickel,

Satin Nickel or Oil Rubbed Bronze

• Cable Drive Waste and Overow

- Chrome, Polished Brass, Gold, Polished Nickel,

Satin Nickel, Oil Rubbed Bronze or

Color Matched (Bone, White and Biscuit Only)

• Waterproof Remote Control with infrared sensor

and 25’ cord

• Factory Installed Rigid ABS Tile Flange

• Remote Blower Wiring Kit

• Color Matched Acrylic Skirt

• Premium Colors

All acrylic colors featured by Aquatic match the

industry’s leading xture manufacturers.

OPTIONAL EQUIPMENT:

Air Bath System:

- 84 Air Jets

- 1 HP Variable Speed Air Blower with 20-Minute Timer

- 600 Watt Air Heating System

- Electronic Control Package with Wave and Pulse Features

- Automatic Daily Purge and Dry Cycle with Water Sensors

Aquatic Quality Features:

- Chromatherapy

- Raised Seat for Air Jet Action on Thighs

- Slip Resistant Floor

- Air Channels Lined with Antimicrobial Coating

- 2 Arm Rests

- Extra Deep and Long Bathing Well

- Pre-leveled ABS Support Base

- Durable, Easy to Clean, Lucite® Cast Acrylic Surface

- Available in 8 Standard No-Charge Colors

UL & IAPMO Listed, Factory Tested

Limited Lifetime Warranty

STANDARD EQUIPMENT:

Each Serenity Air Bath model is equipped with a 600 watt air heating system to raise the temperature of the air going into the bath. This air tem-

perature will be less than the bathing temperature of the water, but will help to reduce a rapid decrease in water temperature. In addition, the air

coming from the air jets will feel cool against the skin, just as a breeze on a warm day cools your body. This system does not heat the water.

20”

36”

Note: Serenity tub only models feature a

Pre-leveled ABS Support Base.

36”

71 1/4”

21 3/4”

23 1/4”

Fax-On-Demand

Document # 1140

1 1/2”

10 1/2”

Deck Width 2”

This unit is not recommended for shower installations.
