Aquatic AI27AIRCOPPER Manuel utilisateur

SPECIFICATIONS:

The manufacturer accepts a 1/4” variance. There are variations on each tub and speciﬁcations are subject to change as we improve upon our product as required. The dimensions needed for site preparation

and structure building should be measured from the tub; Aquatic Industries, Inc. assumes no responsibility for preparatory work. www.aquaticwhirlpools.com 800.555.5324

June 2008

Rough-In Plumbing

Measurements

SErENITy 27

SErENITy Air Baths MODEL # AI27AIRCOPPER / AI27COPPERTO (Tub Only)

GENERAL SPECIFICATIONS:

Tub Size 72” x 36” x 36”

183 cm x 91 cm x 91 cm

Bathing Well 52 1/2” long

25” wide

22” interior depth

Maximum Water Depth 16 3/4”

Shipping Weight 451 lbs. / 205 kg

Tub Weight Filled 1181 lbs. / 515 kg

Tub Only Weight 185 lbs. / 84 kg

Gallons to Overow 120 gal. / 454 L

ELECTRICAL SPECIFICATIONS:

Blower/Heater 1 HP; 10.5 AMP; 120V

Requirement 15 AMP; 120V, separate circuit

required protected w/ Class A GFCI

• This model can be ordered with or without

decorative rings.

Each Serenity 27 bath is handcrafted out of copper.

Please note that the hammered copper with a

weathered nish will vary from model to model and

may gradually change with time due to copper’s

unique character.

OPTIONAL EQUIPMENT:

Air Bath System:

- 1 HP Variable Speed Remote Air Blower with 20-Minute Timer

- 600 Watt Air Heating System

- Electronic Control Package with Wave and Pulse Features

- Automatic Purge and Dry Cycle

- Waterproof Remote Control with Infrared Sensor and 25’ Cord

- Waste and Overow in Oil Rubbed Bronze

Aquatic Quality Features:

- Extra Deep and Long Bathing Well

UL & IAPMO Listed, Factory Tested

Limited Lifetime Warranty

STANDARD EQUIPMENT:

Fax-On-Demand

Document # 1007

Note: This model can be ordered with or without decorative rings.

Each Serenity Air Bath model is equipped with a 600 watt air heating system to raise the temperature of the air going into the bath. This air tem-

perature will be less than the bathing temperature of the water, but will help to reduce a rapid decrease in water temperature. In addition, the air

coming from the air jets will feel cool against the skin, just as a breeze on a warm day cools your body. This system does not heat the water.

Two Person Bath

26”

36”

27”

36”

22 1/2”

54”

72”

36” 52 1/2”

Back Angle 14º

1 3/4”

11 1/4”

Note: This model requires a remote blower location. The

connection for the air blower is under the tub; the blower may

be placed up to 15 feet away and connected by piping under the

oor. Please refer to the Owner’s Manual for detailed installation

instructions. Document #1172 on our Fax-on Demand System or

on our website at www.aquaticwhirlpools.com.

Note: Because the Serenity 27 is a one-of-a-kind handmade bath,

dimensions may vary up to several inches. Please take all measurements

directly from the bath.
