PRODUCT: QUANTITY: ITEM #:
Models: ¨CMC ¨ CMW ¨CMP
Designed Smart
Built Solid
CheeseMelters
APW Wyott Foodservice Equipment Company · 729 Third Ave., Dallas, TX 75226
Rev. 05/06/2008
MODEL CDC-24 SHOWN
Reliability backed by APW Wyott’s
Warranty
• APW Wyott’s Cheese Melters is backed by a 1 year
part’s & labor warranty
• Certified by the following agencies:
See reverse side for product specifications.
¨ CMC-24 208V ¨ CMC-24 240V
¨ CMC-36 208V ¨ CMC-36 240V
¨ CMC-48 208V ¨ CMC-48 240V
¨ Counter Mount (C)
¨ Wall Mount (W)
¨ Pass-Through (P)
Bid Specification
Unit construction is stainless steel with 4” heavy-duty
legs as standard, on Counter Mount and Pass-Through
models. Top, sides and back (except pass-through
model) are fully insulated with high quality insulation.
Special designed control allows unit to maintain standby
level with 25% of heating capacity. Unit has four shelf
height “micro switch” that is activated by placing a plate
on the shelf, which provides ultimate finishing capabili-
ties. All controls are solid-state with electrical fan-cooled
compartment. Infrared heaters are easy to snap-in and
out. All hardware is stainless steel. All units are single
phase.
APW Wyott Design Feature
Top, sides and back (except on pass-through models) •
are insulated with 1” of high quality insulation.
When the master switch is ”on,” the unit stays “on” at •
25% of heating capacity.
Four shelf height “micro switch”.•
Food placed on rack activates heat to 100% heat “on”.•
The 24” and 36” models have one unit “on-off” switch •
and one red unit “on” light.
The 48” model has one unit “on-off” switch and one •
red unit “on” light. There are also right-half heater “on”
switches and right and left “on” lights. Use half, or the
entire unit as needed.
Solid-state controls.•
Fan-cooled electrical compartment•
Instant “on,” instant “off” even heating, top quartz ele-•
ments.
CheeseMelters
PRODUCT: QUANTITY: ITEM #:
Models: ¨CMC ¨ CMW ¨CMP
APW Wyott Foodservice Equipment Company · 729 Third Ave., Dallas, TX 75226
Rev. 05/06/2008
#1911
*APW Wyott reserves the right to modify specifications or discontinue models without incurring obligation.
PRODUCT SPECIFICATIONS
Construction:
Stainless steel construction. Top, sides and back
(except pass-through model) have 1” high
quality insulation.
Electrical Specifications:
Units are wired for hard wiring in the field.
Shipping Information:
F.O.B. Cheyenne, Wyoming
CMC-24 208V, 2.4KW, 11.5 Amps 19"H x 27"W x 17"D 76 lbs.
240V, 2.4KW, 10.0 Amps
CMC-36 208V, 3.6KW, 17.3 Amps 19"H x 36 1⁄2"W x 17"D 92 lbs.
240V, 3.6KW, 15 Amps
CMC-48 208V, 4.2KW, 20.2 Amps 19"H x 50"W x 17"D 130 lbs.
240V, 4.2KW, 17.5 Amps
CMW-24 208V, 2.4KW, 11.5 Amps 15"H x 27"W x 17"D 78 lbs.
240V, 2.4KW, 10.0 Amps
CMW-36 208V, 3.6KW, 17.3 Amps 15"H x 361⁄2"W x 17"D 92 lbs.
240V, 3.6KW, 15 Amps
CMW-48 208V, 4.2KW, 20.2 Amps 15"H x 50"W x 17"D 130 lbs.
240V, 4.2KW, 17.5 Amps
CMC-24 208V, 2.4KW, 11.5 Amps 19"H x 27"W x 15 1/8"D 78 lbs.
240V, 2.4KW, 10.0 Amps
CMC-36 208V, 3.6KW, 17.3 Amps 19"H x 36 1⁄2"W x 15 1/8"D 92 lbs.
240V, 3.6KW, 15 Amps
CMC-48 208V, 4.2KW, 20.2 Amps 19"H x 50"W x 15 1/8"D 130 lbs.
240V, 4.2KW, 17.5 Amps
Model Electric Dimensions Lbs
