ACS-2180

Intel 4th Gen. Core i3 Ultra Slim Fanless Box PC

User Manual

Release Date Revision

Sep. 2015 V1.0

Aplex Technology, Inc.

15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan

Tel: 886-2-82262881 Fax: 886-2-82262883 E-mail: [email protected] URL: www.aplextec.com

ACS-2180 User Manual

Revision History

Reversion

Date

Description

1.0

2015/09/21

Official Version

ACS-2180 User Manual

Warning!________________________

Caution

Risk of explosion if the battery is replaced with an incorrect type.

Batteries should be recycled where possible. Disposal of used batteries must be in

accordance with local environmental regulations.

Disclaimer

This information in this document is subject to change without notice. In no event

shall Aplex Technology Inc. be liable for damages of any kind, whether incidental or

consequential, arising from either the use or misuse of information in this

document or in any related materials.

This equipment generates, uses and can radiate radio frequency energy and

if not installed and used in accordance with the instructions manual, it may cause

interference to radio communications. It has been tested and found to comply

with the limits for a Class A computing device pursuant to FCC Rules, which are

designed to provide reasonable protection against such interference when

operated in a commercial environment. Operation of this equipment in a

residential area is likely to cause interference in which case the user at his own

expense will be required to take whatever measures may be required to correct

the interference.

Electric Shock Hazard –Do not operate the machine with its back cover removed.

There are dangerous high voltages inside.

ACS-2180 User Manual

Packing List

Accessories (as ticked) included in this package are:

□Adaptor

□Driver & manual CD disc

□Other.___________________(please specify)

ACS-2180 User Manual

Safety Precautions

Follow the messages below to prevent your systems from damage:

◆Avoid your system from static electricity on all occasions.

◆Prevent electric shock. Don‘t touch any components of this card when

the card is power-on. Always disconnect power when the system is not

in use.

◆Disconnect power when you change any hardware devices. For instance,

when you connect a jumper or install any cards, a surge of power may

damage the electronic components or the whole system.

ACS-2180 User Manual

Table of Contents

Revision History…………………………………………………………………………………………………….1

Warning!/Caution/Disclaimer..............................…………………………….……………………2

Packing List…………………………………….…………………………………………………....................3

Safety Precautions…………………………………….…………….…..……………………....................4

Chapter 1 Getting Started

1.1 Features……..…………………..………………………...…………………………..7

1.2 Specifications…..………………...………………………………………………….7

1.3 Dimensions……..…………………....……………………………………………...8

1.4 Brief Description of ACS-2180………..….…..……………………….……..9

Chapter 2 Hardware

2.1 Mainboard Introduction…………………….....…………………………....10

2.2 Specifications…………………………..…………..………………………………10

2.3 Jumpers and Connectors Location……….……………………………...14

2.4 Jumpers Setting and Connectors…………..………………………..……15

Chapter 3 BIOS Setup

3.1 Operations after POST Screen…...……..……...…………………………45

3.2 BIOS Setup Utility……………………………..………………………………….45

3.3 Main Settings…………………………………..…..………………………………46

3.4 Advanced Settings………………………………………….…………………...47

3.5 Chipset Settings…………………………….………….………………………...51

3.6 Boot Settings……..…………………………..……………….…………………..53

3.7 Security Settings…..………………….…….…………….……………………..54

3.8 Save & Exit Settings………………………..……………..…………………....55

Chapter 4 Installation of Drivers

4.1 Intel (R) CORE AMT Driver…….………....……...………….………………58

4.2 Intel (R) VGA Chipset……………………..………………………….……......60

4.3 Intel (R) LAN Driver………..……………..…………………………..………...63

4.4 Realtek ALC662 HD Audio Driver....………………………………………66

4.5 USB 3.0 Driver……………………………..……………………………………….68

4.6 Intel(R) MEI Driver………….….……….……………………………………….71

ACS-2180 User Manual

Figures

Figure 1.1: Dimensions of ACS-2180……….……….……….…………………………...8

Figure 1.2: Overview of ACS-2180..…………………..……………………………………9

Figure 1.3: I/O side View of ACS-2180…………...........………………………………9

Figure 2.1: Motherboard Dimensions…………………………………………………..13

Figure 2.2: Jumpers and Connectors Location-Board Top……………………..14

Figure 2.3: Jumpers and Connectors Location-Board Bottom……………….14

ACS-2180 User Manual

Chapter 1 Getting Started

1.1 Features

Intel 4th Gen. Core i3 CPU built-in

Fanless Design

Onboard 4GB DDR3L 1600 MHz

9~36V DC Wide-ranging Power Input

Ultra Slim

1 x 2.5”SATA HDD Space

1.2 Specifications

ACS-2180

System

CPU

Intel® 4th Gen. Core i3 CPU onboard

Chipset

SoC

Memory

Onboard 4GB DDR3L SDRAM

Graphic

Intel® HD Graphics 4400/4200

IO Port

USB

2 x USB 3.0 type A

2 x USB 2.0 type A

Serial/Parallel

1 x RS-232/422/485 DB-9, COM1, Default RS-232

1 x RS-232 DB-9, COM2

Audio

1 x Audio Jack

VGA

1 x VGA

LAN

2 x GbE LAN RJ-45

Power

1 x 3-pin DC Power Input Terminal

1 x 2-pin Connector for Power on/off Button

Storage Space

Storage

1 x SD Card Slot, up to 32GB

1 x 2.5”SATA HDD bay for SATA HDD (Easy Accessible)

Expansion

Expansion Slot

1 x Mini PCIe Slot (full size)

Power

Power Input

DC 9~36V

ACS-2180 User Manual

Power Consumption

MAX: 19.7W

Mechanical

Construction

Aluminum Chassis

Chassis Color

RAL 9007

Mounting

Wall Mount, VESA Mount 100 x 100

Dimensions

375.6 x 177.7 x 40mm

Net Weight

2 Kg

Operating System Support

OS Support

Windows Embedded 8.1 Industry Pro, Windows 7 Pro for Embedded,

WES7, WE8S

Environmental

Operating

Temperature

-20~60℃

Storage Temperature

-40~85℃

Storage Humidity

10 to 90% @ 40℃, non-condensing

Certification

CE / FCC Class A

1.3 Dimensions

Figure 1.1: Dimensions of ACS-2180

ACS-2180 User Manual

1.4 Brief Description of ACS-2180

The ACS-2180 is a fanless high-efficiency thermal solution Box PC, powered by Intel

4th Gen. Core i3 CPU built and supporting 4GB DDR3L 1600MHz onboard memory. It

comes with 2 x USB 3.0 type A, 2 x USB 2.0 type A, 2 x LAN, 2 x COM ports, 1 x VGA, 1

x Audio jack, 1 x 3-pin DC Power Input Terminal, and 1 x 2-pin connector for power

on/off button. It supports 1 x 2.5”SATA HDD space, 1 x SD slot up to 32GB, and

9~36V DC wide-ranging power input. It is ideal for Industrial Automation, Factory

Automation, Machine Vision, Process Control, Data Terminal, TI, Surveillance, etc.

and running factory operations from small visual interface and maintenance

applications to large control process applications. The ACS-2180 works very well

along with any of our Display series and it absolutely can provide an easy way to

perform control and field maintenance.

Figure 1.2: Overview of ACS-2180

Figure 1.3: I/O side view of ACS-2180
