Apelson ICONFLEX60F Manuel utilisateur

Fl ex l- zo ne F le xl -z on e

User Manual

Instruction Manual

Induction Hob

MODEL: ICONFLEX60F

Safety Warnings

This instructions are for your safety. Please read

them thoroughly prior to installation and retain

them for future reference.

The appliance is not to be used by persons

(including children) with reduced physical,

sensory or mental capabilities, or lack of

experience and knowledge, unless they have

been given supervision or instruction.

Children being supervised not to play with the

appliance.

The appliance incorporates an earth

connection for functional purposes only.

WARNING: If the surface is cracked, switch off

the appliance to avoid the possibility of

electric shock.

WARNING:A steam cleaner is not be used.

Metallic objects such as knives, forks, spoons

and lids should not be placed on the hob

surface since they can get hot.

After use, switch off the hob element by its

control and do not rely on the pan detector.

The appliance is not intended to be operated

by means of external timer or separated

remote-control system.

Danger offire: Do not store items onthe

cooking surfaces.

CAUTION:The cooking process has to be

supervised. Ashort term cooking process has

to besupervised continuously.

WARNING: Unattended cooking on a hob with

fat oroil can be dangerous and may result in a

fire.

If the supply cord is damaged, it must be

replaced bythe manufacturer,its service

agentor similarly qualified persons in order to

avoid a hazard.

WARNING:Before obtaining access to

terminals, all supply circuits must be

disconnected.

This appliance can be usedbychildren aged

from 8 years and above and persons with

reduced physical, sensory ormental

capabilities or lack ofexperience and

knowledge if they have been given

supervision or instruction concerning useof

theappliance in a safe way and understand

the hazards involved. children shall notplay

with the appliance. cleaning anduser

maintenance shall notbemade bychildren

without supervision.

WARNING: The appliance and its accessible

parts become hot during use.

Care should betaken to avoid touching

heating elements.

Children less than 8 years of ageshall bekept

away unless continuously supervised.

NEVER try toextinguish a fire with water,but

switch off the appliance and then cover flame

e.g. with a lid ora fire blanket.

WARNING: Use only hob guards designed by

the manufacturer ofthe cooking appliance or

indicated bythe manufacturer ofthe

appliance in the instructions for use as

suitable or hob guards incorporated in the

appliance. The use ofinappropriate guards

can cause accidents.

Ensure the Power cord isn’t accessible after

installation.

Congratulations on the purchase of your new Induction Hob.

We recommend that you spend some time to read this Instruction / Installation

Manual in order to fully understand how to install correctly and operate it.

For installation, please read the installation section.

Read all the safety instructions carefully before use and keep this Instruction /

Installation Manual for future reference.

Product Overview

Top View

User interface

Fl ex l-zon e Fl ex l- zo ne

User interface

Reference Description

AZone select key

BChild lock key

CON/OFF key

D Power/Timer slider regulating key

Boost control key/Keep warm

key

Timer key/Pause key

Heating zone Power

Heating Zone Max.Power（220-240V~ 50/60Hz）

2000/2800W（Booster）

1500/2000W（Booster）

2000/2800W（Booster）

Total Rating Power 7200W

iron pot

magnetic circuit

ceramic glass plate

induction coil

induced currents

AWord on Induction Cooking

Induction cooking is a safe, advanced, efficient, and economical cooking

technology. It works by electromagnetic vibrations generating heat directly in

the pan, rather than indirectly through heating the glass surface. The glass

becomes hot only because thepan eventually warms it up.

Before using your New Induction Hob

Read this guide, taking special note of the ‘Safety Warnings’ section.

Remove any protective film that may still be on your Induction hob.

Using the Touch Controls

The controls respond to touch, so you don’t need to apply any pressure.

Use the ball of your finger, not its tip.

You will hear a beep each time a touch is registered.

Make sure the controls are always clean, dry, and that there is no object (e.g.

a utensil or a cloth)covering them. Even a thin film of water may make the

controls difficult to operate.

Choosing the right Cookware

•Only use cookware with abase suitable for induction

cooking. Look for the induction symbol on the

packaging or on the bottom of the pan.

•You can check whether your cookware is suitable by carrying out

amagnet test. Move amagnet towards the base of the pan. If it

is attracted, the pan is suitable for induction.

•If you do not have amagnet:

1. Put some water in the pan you want to check.

2. If does not flash in the display and the water is heating, the pan is suitable.

•Cookware made from the following materials is not suitable: pure stainless steel, aluminum or

copper without a magnetic base, glass, wood, porcelain, ceramic and earthenware.

Do not use cookware with jagged edges or a curved base.

Make sure that the base of your pan is smooth, sits flat against the glass, and is

the same size asthecooking zone. Use pans whose diameter is as large as the

graphic of the zone selected. Using apot aslightly wider energy will be used at

its maximum efficiency. If you use smaller pot efficiency could beless than

expected. Pot less than 140 mmcould be undetected by the hob. Always

centre your pan on thecooking zone.

Always lift pans off the Induction hob – do not slide, or they may scratch the

glass.

Using your Induction

select key by pressing “ ” key. The symbol 0. selected will stay fully it.

•You have not placed a pan on the correct cooking zone or,

•The pan you’re using is not suitable for induction cooking or,

•The pan is too small or not properly centred on the cooking zone.

No heating takes place unless there is a suitable pan on the cooking zone.

The display will automatically turn off after 1 minutes if no suitable pan is

placed on it.

alternately withthe heatIf the display flashes

setting

This means that:

Hob

To start cooking

1. Touch the ON/OFF key（A）for 3 seconds.

After power on, the buzzer beeps once, all displays

show “ – “, indicating that the induction

hob has entered the state of standby mode.

2. Place a suitable pan on the cooking zone that

you wish to use.

• Make sure the bottom of the pan and

Of the cooking zone are clean and dry.

the surface

3. According to the heating zone where the pan is placed, select a relevant zone

4. Adjust heat setting by touching the slider regulating key(D) control.

• If you don’t choose a heat setting within 1 minute, the induction hob will

automatically switch off. You will need to start again at step 1.

• You can modify the heat setting at any time during cooking.

When you have finished cooking

Touching the relevant zone select key(A) that you wish to switch off.

Press the “-”key will decrease the power to “0” level,

or press the "+" and "-"at the same time, the power level will decrease to

0 straight away.

Beware of hot surfaces

will show which cooking zone is hot to touch. It will disappear when the

surface has cooled down to a safe temperature. It can also be used as an

energy saving function if you want to heat further pans, use the hotplate that is

still hot.

Using the Boost function

Actived the boost function

1. Select the heating zone by touching the zone select key (A).

2. Touching the boost control key(E),the zone indicator show “P” and

the power reach Max.

Cancel the Boost function

1. Touching the relevant zone select key(A) that you wish to cancel.

2. Touching the slider regulating key(D) to cancel the Boost function, then the

cooking zone willrevert to level 9.

• The

function can work in any cooking zone.

• The cooking zone returns to level 9 after 5 minutes.

1.Tou

ch th

e cooking zone selection button that you wish to use keep warm,an

indicato

r next to the key will flash.

2.Touch the button and hold for 3 seconds, the cooking zone indicator will

display .

3. If you want to cancel the keep warm, select the cooking zone you wish to

operate，and then touch the button and hold for

zone will be off.3 seconds. The cooking

Using the Keep warm Function
