Aosom 370-301V80 Manuel utilisateur

370-301V80

IN230800427V01_US_CA

Electric Ride-on Car

Voiture-jouet électrique

EN_IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY.

FR_IMPORTANT : A LIRE ATTENTIVEMEN ET A CONSERVER POUR VOUS Y REFERER

ULTERIEUREMENT.

● 2.4G remote control

● Music

● Light control

● Forward and backward

● Five Points Safety Belts

● Télécommandes 2,4G

● Musique

● Contrôle de la lumière

● Marche avant et arrière

● Ceintures de sécurité à cinq points

J19

Car body Motor Motor cover

Wheel Drive Wheel Rear part

Armrest Backrest M8 Spanner

M4×12 ﬂat head screws M4×12 round head screws Charger

Manual Remote control Mp3line

Product Speciﬁcations:

Battery:

Drive Motor:

Suitable age:

Maximum weight:

Car Size:

Speed:

Hours of Use:

Charger:

Remote Control Battery:

12V 4.5AH

12V390*2

18+ months

25kg

74*59*46cm

3 km/h

Using 0.8 hours after Charging 8-10 hours

Input: 100V-240V 50/60Hz

Output: 12V 0.5A

AAA1.5V*2(not provided)

Backward

Pairing Speed

Right

Speed indicator light

Left

Brake

Forward

Function

Music switch/Volume -

Pause/play

Music switch/Volume +

Music power switch

Button function

Light control switch

Charging hole

Power switch

● Features

- Supply Voltage: 2X1.5V

- Frequency: 2.4GHz

Instruction for 2.4G remote control

● When moving, never switch between forward and backward – this can damage the

gearbox and motor.

● The remote control requires a battery.

● Only and adult should use the remote control.

● This product is mainly operated by the remote control.

● Button Description

- Forward: Direct the ride- on car to move

forward.

- Backward: Direct the ride-on car to move

backward.

- Pairing: Pair the ride-on car with a

remote controller.

- Left: Direct the ride- on car to turn left.

- Right: Direct the ride- on car to turn right.

- Speed: Adjust the speed of the ride- on car’ s movement as low, moderate or high.

- Brake: Immediately stop the ride-on car and lock the car until released.

● Pairing Instruction

1. Turn on the power of the ride-on car, press and hold the pairing button until the

speed indicator light switches on without ﬂashing.

2. Release the pairing button, and the speed indicator light will switch oﬀ.

3. If the speed indicator light switches on again, then the pairing is successful; if not,

please repeat steps 1 and 2.

4. One successful pairing is all, and no more pairings are needed in later use

● Battery installation

Open the back cover of the remote control with screwdriver and insert two triple A

batteries (AAA 1.5V). Please pay attention to the polarity. Close the back cover and

tighten the screws when the LED light is on, indicating battery installed properly.

Battery needs to be replaced when the LED light dims or blinks.

1.Install the wheel

Insert the caster wheel into the slot on the baseboard, following the direction indicated

by the arrow. Then, secure it using an M4×12 screw.

Battery speciﬁcations

● Never mix new, old or diﬀerent types of batteries together.

● Never mistake positive and negative electrodes of a battery – this could lead to a

short circuit.

● Do not charge non-rechargeable batteries.

● Place batteries into the right polarity.

● Only adults should charge and change batteries.

● Take batteries out of the product when charging.

● Take dead batteries out of the product – keep out the reach of children.

● Use a screwdriver to remove the battery screws, open the cap as the arrow signals,

then insert two AAA 1.5V batteries.

2. Install the motor and drive wheel

First remove the three clamps securing the rear axle to the baseboard. Sequentially

place the motor, drive wheel, and washer on both sides of the rear axle. Secure them

with nuts. Next, connect the wire terminals of the motor to the connector cables and

feed them through the wiring holes in the baseboard. Finally, insert the rear axle and

motor back into the baseboard.

3. Fixed pressure plate, motor cover, rear parts

According to the diagram, secure the pressure plate to the base plate using M4×12

screws.

According to the diagram, secure the motor cover to the base plate using M4×12

screws.

According to the diagram, secure the rear parts to the base plate using M4×12 screws.

JJJJ

4.Connect the power cable

Unscrew the bolts on the seat cushion, open the seat cushion, and according to the

diagram, plug the terminals of the power connection cable into each other.

5.Install the armrest assembly

First, remove the screws from the backrest. Then, pry the armrest supports outward.

With one hand, pull the backrest support outward and hold it ﬁrmly in place. Next,

align the armrest assembly with the screw posts on the backrest and snap it into

place. After it's snapped in, ﬁrst slide the backrest support into the screw posts, then

snap the armrest support into the screw posts, and secure with screws.

6. Install the backrest assembly

Insert the assembled backrest component into the vehicle body in the direction

indicated by the arrows, and snap it into place. Then, secure it using M4×12 ﬂat head

screws and M4×12 round head screws.

7.Install the forward reverse switch

Install the forward-reverse switch in the direction indicated by the arrows. Once it's

properly in place, secure it using M4×12 ﬂat head.

WARNING

- This product must be assembled by an adult.

- When unassembled, this product contains small and sharp parts – keep out the reach

of small children.

- Do not use in traﬃc.

- The seatbelt must be worn when using this product.

- Adult supervision is required when using this product.

- Battery must be charged by an adult. Charge the product before its ﬁrst use.

- Keep packaging out the reach of children to avoid suﬀocation.

- Only use parts provided by the manufacturer.

- Ensure children do not play with the charger.

- Do not use in congested streets, roads, slopes or near drains.

- Do not change the circuit or add electrical devices to the product.

- Keep the car away from water and other liquids to avoid damage.

- The maximum load is 25kg – this product can be used by one child at a time.

- Ensure the power is switched oﬀ when not in use. Remove the battery connector

when it has not been used for a while.

- Before using and charging, check the plug and other parts for any damage.

Charging:

- Charge the battery for less than 10 hours – charging for longer can cause permanent

damage.

- Place the DC plug into the power socket, then put the charger into the plug. Never

use the product when charging.

- This product can be used for one hour – the charging time is 8-10 hours.

- It is normal for charger and battery to stay cool when charging.

- Do not use the connector near water to avoid damage.

- Only use the supplied charger. Using a charger not supplied by the manufacturer can

damage the product.

- When not in use for a long time, charge the product.

Note

Charging steps:

Step 1: The charging hole is under the seat.

Step 2: Insert the plug into the hole.

Step 3: Connect the charger to the power socket.

Warning: Car must be charged by adults only. Car is useless during charging.

Troubleshooting

Problem Cause Solution

- The battery is low.

- Failure to press the switch

button correctly.

- Power connector failure.

- Battery breakdown.

- Electrical devices are

damaged.

- Generator is faulty.

- Ensure battery is fully

charged.

- Follow instructions when

using this product.

- Reinstall the power

connector.

- Change battery.

- Change electrical devices.

- Change generator.

The car does not start.

The battery does not

charge.

- Battery connector failure.

- Charger doesn't charge.

- Faulty charger.

- Reinstall the connector.

- Plug in the charger again.

- Change the charger.

The car doesn't drive

far. - Battery isn't fully charged.

- Overused battery.

- Ensure the battery is fully

charged.

- Change the battery.

There's a slight noise

and the car heats

when charging. - This is normal. - Nothing needs to be done.

The car operates at a

slow speed.

- Overused battery.

- The battery is dead.

- The product has exceeded its

maximum load.

- Uneven driving surface.

- Change the battery.

- Ensure battery is fully

charged.

- Ensure the weight is below

25kg.

- Drive on a ﬂat and even

surface.
