AOpen CRW9420 / CRW9624
User’s Manual
3
Copyright
Copyright 1998 by this company. All rights reserved. No part of this publication
may be reproduced, transmitted, transcribed, stored in a retrieval system, or
translated into any language or computer language, in any form or by any means,
electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the
prior written permission of this company.
Disclaimer
This company makes no representations or warranties, either expressed or implied,
with respect to the contents hereof and specifically disclaims any warranties,
merchantability or fitness for any particular purpose. Any software described in this
manual is sold or licensed "as is". Should the programs prove defective following
their purchase, the buyer (and not this company, its distributor, or its dealer)
assumes the entire cost of all necessary servicing, repair, and any incidental or
consequential damages resulting from any defect in the software. Further, this
company reserves the right to revise this publication and to make changes from time
to time in the contents hereof without obligation to notify any person of such revision
or changes.
More help for latest information:
AOpen Inc. http://www.aopen.com.tw
AOpen America Inc. http://www.aopenusa.com
AOpen Computer B.U. http://www.aopen.nl
All brand and product names are trademarks and/or registered trademarks
of their respective holders.
4
OUTLINE
1. Overview
The Multimedia Printer Series Drive (the CD-R/RW Drive) can do much
more than read and write the usual CD-R discs. When you load it with a
rewritable CD-RW disc, you can record, read, and edit any kind of data,
because these discs allow you to rewrite information that has already been
recorded.
!High Speed
AOpen's CRW9420 / CRW9624 CD/ReWriter drive offers unprecedented
performance to handle today’s demands by reading CD's at up to 20X /
24X speed and writing CD-R or CD-RW discs at super 4X / 6X speed.
CRW9420 / CRW9624 writes a 650 MB disc in about 18 / 12 minutes.
!High Versatility
The CRW9420 / CRW9624 is an ideal all-in-one solution for reading CD's,
copying audio/software CD's, creating photo/audio/video CD's, or acting as
a storage drive for archiving or backup. The drive (retail pack only) comes
complete with everything you need to make CD's right away, including
bundled software and blank CDs. With this software, you can create your
own CDs.
!High Reliability
An improved anti-heat design and the OPC design boost recording
reliability. Optimum Power Control continually monitors signal levels during
5
recording and adjusts laser power to compensate for a dirty disc. This
feature ensures a flat signal, significantly enhancing reliability.
!High Compatibility
The CRW9420 / CRW9624 supports all major CD formats, offering the user
full backward-compatibility through the huge installed base of CD/ROM
drives and media. What’s more, reordered CD/RW media can be played in
a DVD player with multi-read feature, maintaining future compatibility.
2. Features
!CRW9420 writes CD-R and CD-RW discs at 4X speed (600KB/sec
data transfer rate).
!CRW9624 writes CD-R discs at 6X (900KB/sec) and CD-RW at 4X
speed.
!Reads at up to 20X (3.0MB/sec) / 24X (3.6MB/sec) speed.
!Firmware upgradable.
!Tray model simple to use.
!Industry standard E-IDE (ATAPI) interface.
!Mounts both vertically and horizontally.
!OPC* technology boosts recording reliability.
!New improved anti-heat design.
!2 MBs data buffer memory provided.
!Supports packet write for easy writing to CD-R and CD-RW discs.
* Continuously monitors the signal level during recording and adjusts the laser power to
compensatewhenthediscisdirty,insuringa flatsignal.
6
CONSTRUCTION AND INSTALLATION
1. Basic Construction
The Compact Disc Recorder/ Rewriter Driver’s configuration, Function
Block Diagram and Connector are shown below;
Fig. 1 Compact Disc Rewritable Drive configuration
7
2. Connector
The Connectors are located as shown below. The function of each parts
are also described below.
Fig. 2 Front
8
Fig. 3 Back
9
2.1 Disc Tray
This is the tray for the disc. Place the disc on the ejected disc tray, then
lightly push the tray (or push the eject button) and the CD will be loaded.
Caution: Don' t use force to pull out or push in the disc tray.
This might cause damage to the loading section of the drive.
2.2 Eject Button
This is the button used to eject or bring in the disc tray.
2.3 Busy Indicator
When the disc tray or disc is being accessed, the light shines or flashes
orange.
Even when a disc is loaded or a disc is not being accessed, the light go
out.
When an illegal disc is loaded or some hardware trouble occurs, the
indicator blinks.
2.4 Headphone Jack
This jack is for connecting headphones or mini-speakers.
2.5 Volume Control
This is used to adjust the output volume of the headphone jack. It can't be
used to adjust the output volume for the audio output connectors on the
rear panel.
10
2.6 Emergency Eject hole
When the drive can not eject the Disc Tray because of power failure,
pushing the Emergency Eject hole of the Front Panel by the thin pole make
drive be able to eject the Disc Tray.
Caution: This function is only for emergency case. Do not use
this function in usual case to prevent from mechanical
damage.
2.7 Power Connector
Used to connect to the host computer' s power supply (DC 5V/12V)
Caution: Be careful not to reverse the poser connector when
attaching it. A reversed connection may cause damage to the
equipment (not covered by the warranty).
2.8 E-IDE Connector
Use a 40 pin double-end flat E-IDE cable to connect to the E-IDE interface.
Caution: Connecting or disconnecting connectors while power
is on may result in a short circuit, causing damage to the
equipment. When connecting or disconnecting connectors,
make sure to turn off the power beforehand.
2.9 Audio Output Connector
Used to connect to the sound card. (Analog signal.)
11
2.10 Digital Audio Output (Not used)
Used to connect to the sound card. (Digital signal.) It is not used with this
drive.
2.11 Device Configuration Jumper
Used when selecting the Device Configuration of E-IDE. Don’t use jumpers
to change anything besides the Device Configuration, but keep the drive as
initially set (“Master” position). Configuration changes become valid after
power is turned off, then on again.
Caution: Installing jumper pins besides the ones for Device
Configuration settings may be the cause of damage or
abnormal drive operation.
Fig. 4 Device Configuration Jumper
The Device Configuration Jumper will be set to Master as factory setting.
3. Installation
The Connectors are located as shown below. The function of each parts
are also described below.
