1．AOMWAY-HD588 V2 Diversity Monitor
HD588 V2 is the all-in-one monitor with DVR function that is
elaborately designed for FPV purpose by presenting the most authentic
image effect. It is well-equipped with 10.1＂display, LED backlight, dual
built-in 64ch receiver modules with high sensitivity and integrated DVR
is available for real-time recording.
Major Features：
FPV three proofing：no blank screen, no blue, no flicker.
450cd/m2 high brightness, 1000:1 high contrast, 1920 x1200p
full HD display.
10.1” IPS MIPI screen with long service time, LED backlight.
Dual built-in diversity receiver module: 5.8Ghz / 64channels /
-95dBm sensitivity
Auto search for active channel ( scan all the 64 channels with
one single button )
Auto select NTSC/PAL format.
OSD menu: Voltage, Channel, RSSI, Battery Status.
FOV horizontal 85°/85°(Left/Right),FOV vertical
85°/85°(Up/Down).
Two built-in high quality stereo speakers with adjustable
volume bar displayed on screen.
5G8 FPV Monitor HD588 WWW.AOMWAY.COM
________________________________________________________________________
2
Integrated DVR for real time recording and playback, TF card
support to maximum 64G.
Built-in DVR now can record both of RF and AV in video signal,
auto save recording file when accidently power off the monitor.
Built-in 2400mah Li-ion battery, after fully charged, working
time extended to 120mins.
Battery voltage status displayed on screen and low voltage
alarm function is available.
Resolution: D1, PAL: 720*576, NTSC: 720*480.
DC input 8-26V(positive inside and negative outside),DC output
10-12v 1A.
Operating language Options: up to 8 different languages
Display aspect ratio: 16:9 and 4:3, supporting point-to-point
display and zoom-in function allows viewing at a particular
section.
Standard 3.5mm AV in /AV out port.
Standard 5.5*2.1mm DC in and DC out port.
USB for multimedia displayer and firmware upgrade.
Support 1080p HD in display.
Power consumption ≤9W.
Dimensions：246 x 172 x 20mm.
2．Push Button and Interface Illustration
5G8 FPV Monitor HD588 WWW.AOMWAY.COM
________________________________________________________________________
3
A. Front Control Panel Button Function：
POWER: power on/off
SEARCH/▽：auto search channel/scroll down/ multimedia
return key
CH/+: channel selection / increase
FR/-: band selection / decrease
MENU: open or close menu on screen / confirm key
MODE △/ : mode selection / scroll up
Red LED light indicates power on and blue LED light indicates
charging status.
B. Button Operation：
POWER: short press to power on (buzzer will beep once), long
press to power off(buzzer will beep three times).
▽SEARCH/ ：long press to start auto scan all the channels
and pick up the strongest signal to display image.
CH/+: each time press the button to increase the channel from
1 to 8 and finally back to CH1; after enter into a sub-menu,
press “+ ” to scroll down or increase a selected value for
setting.
FR/-: each time press the button, band changes from A to E
LED
5G8 FPV Monitor HD588 WWW.AOMWAY.COM
________________________________________________________________________
4
and finally back to A; after enter into a sub-menu, press “- ” to
scroll up or decrease a selected value for setting.
MENU: single press the button to open interface for setting up
brightness, contrast, color temperature, voice, sharpness,
upgrade, display ratio, image flip, language, system upgrade,
reset, etc..
MODE: single press to show different mode options of
RF/DVR/VIDEO/HD/USB PLAY, using ‘△’ / ‘ ▽’ key scroll up
and down to select, ‘+’ key to confirm the selection.
C. Multimedia Player Function:
Press MODE key first and select Multimedia mode and then
you will be able to view the sub-menu.
a) Use ‘-’ and ‘+’ key to move the cursor to select between
music, movie or text file type, ‘Menu ’key to confirm
selection.
b) After enter into sub-menu, use ‘-’ and ‘+’ key to move up and
down to select file, ‘Menu’key to play/pause, ‘Search’ key
to return.
c) When start playing, press‘Menu’key to display setting
menu ; press‘SEARCH’key to exit the menu; use ‘-’ and ‘+’
key to move the cursor on the setting menu (select “play,
fast backward, fast forward, last one, next one, stop, cycle
5G8 FPV Monitor HD588 WWW.AOMWAY.COM
________________________________________________________________________
5
play, single cycle”); ‘Menu’as the confirm key, when
playing a file, use ‘-’ and ‘+’ key to decrease and increase the
volume.
D. Right Side Port Illustration：
3.5mm AV in port for video signal input. (need to switch to AV
IN mode).
3.5mm AV out /AAT port for ATT data transmission and video
output.
3.5mm earphone jack for stereo audio out.
5.5*2.1mm DC in/out port (positive inside and negative
outside).
E. Left Side Button and DVR Illustration:
UP: rock the switch upward for scroll up or fast forward.
DOWN: rock the switch downward for scroll down or fast
backward.
OK: vertically press down rocker switch at center for play or
5G8 FPV Monitor HD588 WWW.AOMWAY.COM
________________________________________________________________________
6
pause.
TF card support to maximum 64G.
LED light: indicate DVR is working or not, solid on for standby,
flash for recording.
HDMI_C type connector：support 1080p, 720p HDMI input.
USB_A type connector: support firmware upgrade and
multimedia application.
F. RF Channel/Frequency Chart：
3．DVR Recording & Playback Function:
A. Operation:
Playback function needs to be used under DVR mode, please
use MODE key for correct mode selection.
After enter into DVR mode, your screen will display the video
image received by RF module, meanwhile DVR status is
standby, LED light will be solid on.
5G8 FPV Monitor HD588 WWW.AOMWAY.COM
________________________________________________________________________
7
Single press REC key to start recording, LED light will start
flashing while the dot cursor is blinking at the bottom right
corner of screen.
Press REC key again to stop recording, LED light will stay
solid on and the blinking dot will disappear from screen.
B. DVR Menu & Playback:
a) Long press OK key for 5 seconds to enter into DVR main
menu. DVR menu will have three options to be selected by UP
and DOWN key:
1. Playback Menu
2. Format TF Card
3. Language Selection
Long press REC key to exit DVR menu and DVR will stay
standby.
b) Playback function, short press the center key to select and
enter into sub-menu:
1. DOWN and UP for selecting the file for playback, short
press the center key to confirm.
2. While playing a file, press DOWN for fast backward at
different speed as X1, X2, X4 or X8.
3. Press UP for fast forward at different speed as X1, X2, X4
or X8.
4. Short press the center key is for play/pause.
5G8 FPV Monitor HD588 WWW.AOMWAY.COM
________________________________________________________________________
8
5. Long press the center key to set DVR back to standby
mode.
c) This DVR system automatically saves a separate recording
file every 30 minutes.
4．Battery Charging & Protection:
This monitor is equipped with built-in high capacity Li-ion
battery; please stay cautious of safety when using the battery.
Trying to drive the battery voltage out of its high and low limit
will damage this battery and shorten its lifetime. Suggest using
a standard 15V, 2A battery charger for proper charging. The full
charging process is about to take 3 hours long.
Blue LED indicator on panel stays solid on when charging and it
will go off after charging completed.
After been fully charged, monitor’s working time will be
extended to 120 minutes. When battery voltage drops down to
10.3V, buzzer will start beeping as a low voltage alarm.
5．System Upgrade:
Based on customer’s actual need, AOMWAY will upgrade the system
for better performance in the future; all firmware files will be
published on online forum and our official website.
Upgrade Method：Download latest firmware file to your USB-Key,
5G8 FPV Monitor HD588 WWW.AOMWAY.COM
________________________________________________________________________
9
plug USB-Key to your device port and then Power on→Enter into
menu→Select System Upgrade→Press ‘FRE’ or ‘CH’ key to start→
System starts upgrade process (data reading on top left of screen
and later auto shut down after upgrade completed). Reject your
USB-Key and delete the upgrading file later. After reboot your
monitor, the monitor will be installed with the latest system.
WARNING!!!
Must NOT disconnect the power supply during firmware upgrading
process, please unplug USB-Key and delete upgrading file after
system has been successfully upgraded.
6．Package Contents:
1 X FPV Monitor 1 X Manual
2 X AV Cable 1 X Battery Charger
1 X 5db Dipole Antenna 1 X 6db 5G8 Patch Antenna
7．Caution：
Note that the working environment for built-in battery is
-10-60℃.
Multimedia player is not intended for playing back DVR
recording file; please switch your monitor into DVR mode first.
The internal buzzer for low voltage alarm is only taking effective
Table des matières
