AOC A110-E Instructions de fonctionnement

User Operating Manual

A110-E

1Introduction

1.1 Acknowledgements

Many thanks for you choosing this product. The product belongs to MID(Mobile Internet

Device), which is a kind of mobile internet device, delicate, small and exquisite, and

also portable. It is also equipped with a piece of touch LCD of high definition, which

can be used to watch vedios and pictures of high definition. It supports installation of

multiple application programs on office and entertainment. The fantastic operation

interface will give you a brand-new user experience.

This manual systematically introduces diversified functions, using skills and matters needing

attention of this MID, please read this manual carefully before using it.

1.2 Safety Notice

Before using MID, please read information in this section, and make your children learn

about the information. About more detailed information, please refer to safety instructions

and matters needing attention.

Please don’t use MID when you are driving, for fear of hindering safe driving.

In medical places, please observe relevant stipulations and regulations. And in regions

near the medical devices, please shut down MID.

Please shut down MID or enable the airplane mode when boarding, so that the wireless

signals will not interfere control signal of the airplane.

Please shut down MID neighboring electronic equipments with high accuracy, otherwise,

breakdown of electronic equipments may be brought about.

Please don’t dismantle the MID and its accessories on yourself, and only the authorized

agency can maintain this MID.

Please keep MID far away from magnetic equipment, radiation from MID will erase

information stored on the magnetic equipment.

Please don’t use MID in places with high temperature and inflammable gas (such as

nearby gas station).

Please put MID and its accessories in places beyond children’s touch, please don’t let

children use MID without supervision.

During using of this MID, please observe related laws and regulations, respect privacy

and legitimate rights of others.

Please strictly abide by relevant explanations in this manual when using USB data line,

otherwise, MID or personal computer may be damaged.

Please don’t use the MID in humid environment such as bathroom, etc., and the MID

being soaked or rinsed by liquid must be avoided.

1.3 Abbreviation/term

Abbreviation/term Full name Explanations

MID Mobile Internet Device Mobile internet terminal

WIFI Wireless Fidelity Wireless Local Area Network

based on IEEE 802.11 a/b/g/n

TF Trans Flash Alternate name Micro SD,

super miniature storage card

HDMI High Definition

Multimedia Interface

High definition multi-media

interface

2Brief introduction for MID product

2.1 Diagram for MID complete machine

Figure 2-1

Figure 2-2

Front camera

Rear camera

Figure 2-3

Figure 2-4

2.2 Introduction to accessories of MID

Packing list

The following articles are included in your packing box of MID:

Complete machine of MID

Power adaptor

USB connecting line

Quick Start Guide

Warranty card

2.3 MID state and notice

Icon graph for notification

When a prompt message shows on your notice panel, please click the column box and slide

on the screen with your finger to open the notice list. Click options needing to check to see

detailed information. Then you may click the message box and slide upwards to close the

message window. The following are iconography for icons in status bar:

Mail notice Mute

Gmail notice Without SD card

Computer and MID are

connected through USB line Uploading/Downloading

Events waiting to be done Downloading finished

Alarm clock opening

General notice (for example:

synchronous error)

Playing music In data synchronism

Insufficient space of SD card More

WIFI service is connected,

network is available Battery symbol

Airplane mode Charging

Bluetooth is already connected

3Quick start

3.1 Key function

Descriptions for key function:

Power key Press this key for a long time to start up



Under starting up state, press this key for a long time to pop up

shutdown option

Under starting up state, press this key to close the screen



Under starting up state or when breakdown appears, press the

power key for 7 seconds to make your device to restart

Multitask

key

Press this key to browse tasks which have been opened

Return key Press this key to return the last operating step or the previous

operating interface

Homepage

key



Press this key to return back main function interface from any

interface

3.2 Starting up and turning off

Starting up

Press the power key for 3 seconds, you can see the starting up picture. After the system is

started, the machine enters into screen lock state, please unlock according to direction

indication of sliding icon on the interface.

Turning off

1．After pressing the power key for a long time, the shutdown option will pop up.

2．Click Power off.

3.3 Unlocking and closing of the screen

The machine will close automatically when the screen is left unused

1．After the screen being left unused for a period of time, the machine will close screen

automatically, so as to save battery power.

2．Under screen on state, press the power key, the screen will close immediately.

Prompt: if you want to inquire how to set turn-off time of screen, please refer to chapter 9.1.

Turning on under screen off state

If the screen is in off state, you can unlock the screen by pressing power key for a short time

or the return key for a long time. After opening, the screen will enter lock state, press “lock”

icon by your finger and slide up, the screen will be unlocked, press “camera” icon and slide

leftwards, you can enter the camera function.

Figure 3-1

3.4 Use of touch screen

Operating mode in MID

There are various ways to skim the main screen, menu and application program, etc. on your

MID.

Click to select

When you want to use screen keyboard entry, and you want to select items on the homepage

interface such as application program, you only use your finger to click.

Press on

If you want to unlock the available option of a certain item (such as textbox or interlinkage in

the webpage), or move shortcut on the homepage interface and menu of main program, only

press the item.

Slide quickly or slide

Quick sliding or sliding means doing rapid vertical or horizontal drag movement by using

finger on the picture.

Drag

Before you starting to drag, you must press it with your finger and impose a certain pressure,

and don’t loosen the finger before dragging to the wanted position.

Rotate

Aiming at most of pictures, only turn the MID in side direction, the screen direction can be

shifted from cross direction to vertical direction. For example, when you input characters,

watch cinema, etc.

3.5 Homepage interface

All application programs on the machine will be displayed on the main menu screen. You

may use application program, shortcut and user-defined mode to set wallpaper of your

homepage interface

Figure 3-2

Notice bar

Wallpaper

Google Search

Application

program

Skill: in any application programs, you can press homepage key to return homepage

interface.

Custom homepage interface

Change desktop wallpaper

1. Press blank region on the homepage interface to pop up the menu.

2. When the menu popping up, choose source of homepage interface wallpaper you want to

change.

3. After clicking source of wallpaper, click picture you want, and then select “setting

wallpaper”.

Figure 3-3

Figure 3-4
