Conguration Guide

Vector Signal Generator

MG3710A

Conguration Guide

2 Configuration Guide lMG3710A

MG3710A-062/162

2ndRF 100 kHz to 2.7 GHz

MG3710A-064/164

2ndRF 100 kHz to 4 GHz

MG3710A-066/166

2ndRF 100 kHz to 6 GHz

Frequency Range for 2ndRF

∗Select one of following

MG3710A-071/171

High Power Extension for 2ndRF

MG3710A-072/172

Low Power Extension for 2ndRF

MG3710A-073/173

Reverse Power Protection for 2ndRF

Pre-installed for 2ndRF

64 Msamples

MG3710A-075/175

ARB Memory Upgrade

256 Msample for 2ndRF

MG3710A-076/176

ARB Memory Upgrade

1024 Msample for 2ndRF

ARBメモリ拡張

∗Select one of following

MG3710A-078/178

Combination of Baseband Signal for

2ndRF

MG3710A-079/179

AWGN for 2ndRF

MG3710A-032

1stRF 100 kHz to 2.7 GHz

MG3710A-034

1stRF 100 kHz to 4 GHz

MG3710A-036

1stRF 100 kHz to 6 GHz

Frequency Range for 1stRF

∗Require one of following

MG3710A-041/141

High Power Extension for 1stRF

MG3710A-042/142

Low Power Extension for 1stRF

MG3710A-043/143

Reverse Power Protection for 1stRF

Pre-installed for 1stRF

64 Msamples

MG3710A-045/145

ARB Memory Upgrade

256 Msample for 1stRF

MG3710A-046/146

ARB Memory Upgrade

1024 Msample for 1stRF

ARB Memory Upgrade

∗Select one of following

MG3710A-048/148

Combination of Baseband Signal for

1stRF

MG3710A-049/149

AWGN for 1stRF

MG3710A-018/118

Analog IQ Input/Output

Pre-installed

Aging Rate: ±1×10–7/day

MG3710A-002/102

High Stability Reference Oscillator

Aging Rate: ±1×10–8/day

MG3710A-001/101

Rubidium Reference Oscillator

Aging Rate: ±1×10–10/month

Reference Oscillator

MG3710A-011/111

2ndary HDD

MG3710A-313

Removable HDD

∗Not simultaneously with Opt. 029

MG3710A-029

OS Upgrade to Windows 7

∗Not simultaneously with Opt. 313

J1539A

AUX Conversion Adaptor

MG3710A-017/117

Universal Input/Output

(with J1539A)

MG3710A-021/121

BER Test Function

(with J1539A)

MG3710A

Vector Signal Generator

Order at least one of these items.

Options with -0xx appended are standard options at shipment.

Options with -1xx can be retrofitted after shipment but no other option numbers can be retrofitted.

MG3710A Vector Signal Generator

Configuration Guide lMG3710A 3

MG3710A-062/162

2ndRF 100 kHz to 2.7 GHz

MG3710A-064/164

2ndRF 100 kHz to 4 GHz

MG3710A-066/166

2ndRF 100 kHz to 6 GHz

Frequency Range for 2ndRF

∗Select one of following

MG3710A-071/171

High Power Extension for 2ndRF

MG3710A-072/172

Low Power Extension for 2ndRF

MG3710A-073/173

Reverse Power Protection for 2ndRF

Pre-installed for 2ndRF

64 Msamples

MG3710A-075/175

ARB Memory Upgrade

256 Msample for 2ndRF

MG3710A-076/176

ARB Memory Upgrade

1024 Msample for 2ndRF

ARBメモリ拡張

∗Select one of following

MG3710A-078/178

Combination of Baseband Signal for

2ndRF

MG3710A-079/179

AWGN for 2ndRF

MG3710A-032

1stRF 100 kHz to 2.7 GHz

MG3710A-034

1stRF 100 kHz to 4 GHz

MG3710A-036

1stRF 100 kHz to 6 GHz

Frequency Range for 1stRF

∗Require one of following

MG3710A-041/141

High Power Extension for 1stRF

MG3710A-042/142

Low Power Extension for 1stRF

MG3710A-043/143

Reverse Power Protection for 1stRF

Pre-installed for 1stRF

64 Msamples

MG3710A-045/145

ARB Memory Upgrade

256 Msample for 1stRF

MG3710A-046/146

ARB Memory Upgrade

1024 Msample for 1stRF

ARB Memory Upgrade

∗Select one of following

MG3710A-048/148

Combination of Baseband Signal for

1stRF

MG3710A-049/149

AWGN for 1stRF

MG3710A-018/118

Analog IQ Input/Output

Pre-installed

Aging Rate: ±1×10–7/day

MG3710A-002/102

High Stability Reference Oscillator

Aging Rate: ±1×10–8/day

MG3710A-001/101

Rubidium Reference Oscillator

Aging Rate: ±1×10–10/month

Reference Oscillator

MG3710A-011/111

2ndary HDD

MG3710A-313

Removable HDD

∗Not simultaneously with Opt. 029

MG3710A-029

OS Upgrade to Windows 7

∗Not simultaneously with Opt. 313

J1539A

AUX Conversion Adaptor

MG3710A-017/117

Universal Input/Output

(with J1539A)

MG3710A-021/121

BER Test Function

(with J1539A)

MG3710A

Vector Signal Generator

Order at least one of these items.

Options with -0xx appended are standard options at shipment.

Options with -1xx can be retrofitted after shipment but no other option numbers can be retrofitted.

4 Configuration Guide lMG3710A

This document explains how to order the new MG3710A and MG3710A retrofit options and software.

Follow the steps below to select your MG3710A configuration.

Functions marked standard are built-in at factory shipment. Options and software can be added as necessary.

Two RF outputs (1stRF and 2ndRF) can be installed in the MG3710A. The options for each RF output are color coded as follows:

Options for both

1stRF and 2ndRF

Options only for

1stRF

Options only for

2ndRF

To add options to the MG3710A order as follows:

Example

Model MG3710A

Option MG3710A-032

Option MG3710A-048

Step. 1 Choose frequency range for 1stRF.

(Required option: The frequency range cannot be upgraded.)

Name Option No. Additional Information

1stRF 100 kHz to 2.7 GHz MG3710A-032 1stRF output of vector signal generator.

Select the model with the required frequency range.

The 1stRF frequency cannot be changed retroactively after ordering.

1stRF 100 kHz to 4 GHz MG3710A-034

1stRF 100 kHz to 6 GHz MG3710A-036

Step. 2 Choose frequency range for 2ndRF.

(This extra option cannot be retrofitted.)

Name Option No. Additional Information

2ndRF 100 kHz to 2.7 GHz MG3710A-062 2ndRF output of vector signal generator.

Select one model with the required frequency range.

The 2ndRF frequency cannot be changed retroactively after ordering.

2ndRF 100 kHz to 4 GHz MG3710A-064

2ndRF 100 kHz to 6 GHz MG3710A-066

Step. 3 Choose frequency reference.

Choose one reference oscillator. The selected reference oscillator performance is enabled and other reference oscillators are disabled.

Name Option No. Additional Information

Standard Reference Oscillator Standard Aging Rate: ±1×10–6/year, ±1×10–7/day

Rubidium Reference Oscillator MG3710A-001 Aging Rate: ±1×10–10/month

High Stability Reference Oscillator MG3710A-002 Aging Rate: ±1×10–7/year, ±1×10–8/day

Configuration Guide lMG3710A 5

Step. 4 Select the signal output level setting range expansion and the reverse input

power protection.

Name Option No. Additional Information

High Power Extension for 1stRF MG3710A-041

Extends signal output setting range upper limit

(Standard +17 dBm)

Opt. 041/141 installed and Opt. 043/143 not installed, CW

Level setting range: Hi limit +30 dBm

Opt. 041/141 installed and Opt. 043/143 installed, CW

Level setting range: Hi limit +25 dBm

Low Power Extension for 1stRF MG3710A-042

Extends signal output setting range lower limit

(Standard –110 dBm)

Level setting range: Lo limit –144 dBm

Reverse Power Protection for 1stRF MG3710A-043

Protects signal output connector against reverse input power

(Standard 2 W nominal)

Max. reverse input: 20 W nominal (1 MHz < frequency ≤ 2 GHz)

10 W nominal (2 GHz < frequency ≤ 6 GHz)

High Power Extension for 2ndRF MG3710A-071

Extends signal output setting range upper limit

(Standard +17 dBm)

Opt. 071/171 installed and Opt. 073/173 not installed, CW

Level setting range: Hi limit +30 dBm

Opt. 071/171 installed and Opt. 073/173 installed, CW

Level setting range: Hi limit +25 dBm

Low Power Extension for 2ndRF MG3710A-072

Extends signal output setting lower limit

(Standard –110 dBm)

Level setting range: Lo limit –144 dBm

Reverse Power Protection for 2ndRF MG3710A-073

Protects signal output connector against reverse input power

(Standard 2 W nominal)

Max. reverse input: 20 W nominal (1 MHz < frequency ≤ 2 GHz)

10 W nominal (2 GHz < frequency ≤ 6 GHz)

● Setting Range of the Signal output level

Options Setting Range [dBm]

Without RPP∗With RPP∗

Standard –110 to +17 –110 to +17

With High Power Extension –110 to +30 –110 to +25

With Low Power Extension –144 to +17 –144 to +17

With High & Low Power Extension –144 to +30 –144 to +25

∗RPP: Reverse Power Protection

● Accuracy guaranteed upper limit level of the signal output level

Without Reverse Power Protection

Frequency Range Without High Power Extension With High Power Extension

100 kHz ≤ f < 10 MHz +5 dBm +5 dBm

10 MHz ≤ f < 50 MHz +10 dBm +10 dBm

50 MHz ≤ f < 400 MHz

+13 dBm

+20 dBm

400 MHz ≤ f ≤ 3 GHz +23 dBm

3 GHz < f ≤ 4 GHz +20 dBm

4 GHz < f ≤ 5 GHz +13 dBm

5 GHz < f ≤ 6 GHz +11 dBm +11 dBm

With Reverse Power Protection

Frequency Range Without High Power Extension With High Power Extension

100 kHz ≤ f < 10 MHz +2 dBm +2 dBm

10 MHz ≤ f < 50 MHz +7 dBm +7 dBm

50 MHz ≤ f < 400 MHz

+10 dBm

+17 dBm

400 MHz ≤ f ≤ 3 GHz +20 dBm

3 GHz < f ≤ 4 GHz +17 dBm

4 GHz < f ≤ 5 GHz +10 dBm

5 GHz < f ≤ 6 GHz +8 dBm +8 dBm

6 Configuration Guide lMG3710A

Step. 5 Select the baseband vector signal generator ARB memory size option.

The selected memory is enabled and others are disabled.

Name Option No. Additional Information

ARB Memory 64 Msample for 1stRF Standard Standard baseband generator for 160 MHz sampling rate and 64 Msamples ARB

memory size (256 MB)

ARB Memory Upgrade 256 Msample for 1stRF MG3710A-045

Upgrades ARB size to 256 Msamples (1 GB)

With Opt. 048/148 not installed, installs 1 × 256 Msamples

With Opt. 048/148 installed, installs 2 × 256 Msamples

ARB Memory Upgrade 1024 Msample for

1stRF MG3710A-046

Upgrades ARB size to 1024 Msamples (4 GB)

With Opt. 048/148 not installed, installs 1 × 1024 Msamples

With Opt. 048/148 installed, installs 2 × 1024 Msamples

2ARB Memory 64 Msample for 2ndRF Standard Standard baseband generator for 160 MHz sampling rate and 64 Msamples waveform

memory size (256 MB)

ARB Memory Upgrade 256 Msample for

2ndRF MG3710A-075

Upgrades ARB size to 256 Msamples (1 GB)

With Opt. 078/178 not installed, installs 1 × 256 Msamples

With Opt. 078/178 installed, installs 2 × 256 Msamples

ARB Memory Upgrade 1024 Msample for

2ndRF MG3710A-076

Upgrades ARB size to 1024 Msamples (4 GB)

With Opt. 078/178 not installed, installs 1 × 1024 Msamples

With Opt. 078/178 installed, installs 2 × 1024 Msamples

Note: Since each waveform pattern size is different, if the memory is not upgraded, sometimes the waveform pattern cannot be used.

For details, refer to the Waveform Pattern Catalog and the IQproducer catalog.

Step. 6 Select the baseband signal combine and AWGN function options.

Name Option No. Additional Information

Combination of Baseband Signal for 1stRF MG3710A-048

Two internal ARB memories.

Selects two waveform patterns per one RF output for setting mutual frequency offset,

level offset, delay time, etc., to output 2 signals from 1 RF connector

AWGN for 1stRF MG3710A-049

Internal AWGN addition function.

Adjusts AWGN bandwidth range setting as follows for selected waveform pattern:

Band limit: waveform pattern sampling rate × 0.2

to waveform pattern sampling rate × 0.8

CN: ≤40 dB

Combination of Baseband Signal for 2ndRF MG3710A-078

Two internal ARB memories.

Selects two waveform patterns per one RF output for setting mutual frequency offset,

level offset, delay time, etc., to output 2 signals from 1 RF connector

AWGN for 2ndRF MG3710A-079

Internal AWGN addition function.

Adjusts AWGN bandwidth range setting as follows for selected waveform pattern:

Band limit: waveform pattern sampling rate × 0.2

to waveform pattern sampling rate × 0.8

CN: ≤40 dB

Configuration Guide lMG3710A 7

Step. 7 Choose the analog input/output options.

Name Option No. Additional Information

Analog IQ Input/Output MG3710A-018 Installs analog I/Q input and output connectors on rear panel of main frame but only

supports SG1 side (1stRF side)

Step. 8 Choose the external input/output options.

Name Option No. Additional Information

Universal Input/Output MG3710A-017

Installs following signal I/O connectors on rear panel of main frame

Baseband Reference Clock Input/Output

Sweep Output (only supports 1stRF)

Local Signal Input/Output

∗: Also provides J1539A AUX Conversion Adapter for Opt. 017/117 to use rear panel

AUX connector

AUX Conversion Adapter J1539A Adapter for converting rear panel AUX connector to BNC connector

Step. 9 Choose the BER test function.

Name Option No. Additional Information

BER Test Function MG3710A-021

Installs BER measurement function

Input signals: Data, Clock, Enable

Bit rate: 100 bps to 40 Mbps

∗: Also provides J1539A AUX Conversion Adapter for Opt. 021/121 to use rear panel

AUX connector

Step. 10 Choose OS and HDD options.

Name Option No. Additional Information

OS Upgrade to Windows 7 MG3710A-029 Upgrades embedded Windows XP OS to Windows 7 (32-bit, Professional)

This option cannot be applied to Opt. 313 (Removable HDD).

2ndary HDD MG3710A-011 User installable/removable HDD

Removable HDD MG3710A-313 User exchangeable HDD with Windows XP OS

Opt. 029 cannot be applied to this HDD option.

Step. 11 Choose warranty options.

Name Option No. Additional Information

1 Year Warranty Service Standard

Excludes consumables

2 Years Extended Warranty Service MG3710A-ES210

3 Years Extended Warranty Service MG3710A-ES310

5 Years Extended Warranty Service MG3710A-ES510

8 Configuration Guide lMG3710A

Step. 12 Choose waveform pattern software.

The waveform pattern software function sets the selected waveform using previously set parameters. The waveform patterns are installed in

the MG3710A and the signal is output by selecting them.

When outputting a waveform pattern from the MG3710A, no signal is output unless a license for that system is installed in the main frame.

Note: Since the size of each waveform pattern is different, sometimes waveforms cannot be output if the memory upgrade option has not been installed.

For details refer to the waveform pattern catalog.

Name Option No. Additional Information

Standard Waveform Patterns Standard

LTE FDD (E-TM1.1 to E-TM3.3), LTE TDD (E-TM1.1 to E-TM3.3), W-CDMA/HSDPA,

GSM/EDGE, CDMA2000 1X/1xEV-DO,

Bluetooth

®, GPS, PDC, PHS,

Broadcast (ISDB-T/BS/CS/CATV), WLAN (IEEE802.11a/11b/11g)

DFS Radar Pattern MX370073A

Sets pulse signals for testing 5-GHz band WLAN DFS functions.

The MX370073A supports the waveform patterns for the TELEC and FCC test specications.

Pulse signals are output simply by selecting the pattern.

DFS (ETSI) Waveform Pattern MX370075A

Sets pulse signals for testing 5-GHz band WLAN DFS functions.

The MX370075A supports the waveform patterns for the ETSI specications.

Pulse signals are output simply by selecting the pattern.

ISDB-Tmm Waveform Pattern MX370084A

Archive of ARIB STD-B46 waveform patterns.

Supports MER and spectrum evaluation of Tx characteristics tests and sensitivity/

simple BER tests at Rx characteristics tests.

Configuration Guide lMG3710A 9

Step. 13 Choose IQproducer software license.

IQproducer is PC application software for generating waveform patterns. The parameters are set using IQproducer and the waveform pattern is

created to output the signal by selection at the MG3710A. This one software application includes all the following systems.

Since it runs on any PC, the supported functions and parameter range can be verified before purchase.

When outputting a waveform pattern from the MG3710A, no signal is output unless a license for that system is installed in the main frame.

Note: Since the size of each waveform pattern is different, sometimes waveforms cannot be output if the memory upgrade option has not been installed.

For details refer to the waveform pattern catalog.

Name Option No. Additional Information

HSDPA/HSUPA IQproducer MX370101A

Sets parameters according to 3GPP HSDPA/HSUPA (Uplink and Downlink) specications,

and generates HSDPA/HSUPA waveform patterns including Fixed Reference Channel

(3GPP TS 25.101 Annex A.7).

TDMA IQproducer MX370102A

Sets required parameters for TDMA waveform patterns and generates various

waveform patterns.

Setting parameters include Modulation, Frame, Slot, Data, Filter, etc.

Supports wide application range including public wireless.

CDMA2000 1xEV-DO IQproducer MX370103A Sets parameters according to CDMA2000 1xEV-DO Forward/Reverse specications

and generates 1xEV-DO waveform patterns.

Multi-carrier IQproducer MX370104A Generates multi-carrier waveform patterns combination les using MG3710A Baseband

Signal Combine function (requires Opt. 048/078).

Mobile WiMAX IQproducer MX370105A

Sets parameters according to IEEE 802.16e-2005, IEEE P802.16Rev2/D3

WirelessMAN-OFDMA MAC, PHY specications and generates waveform patterns.

Supports WirelessMAN-OFDMA specication used by 802.16e mobile standard.

DVB-T/H IQproducer MX370106A

Sets parameters according to ETSI EN 300 744 V1.5.1 (2004-11) physical layer

standard and generates DVB-T/H waveform patterns.

Generated waveform patterns can be used for device TRx characteristics evaluation

tests (Error Correction BER, graphics).

Fading IQproducer MX370107A

Performs IQ channel fading processing, correlation matrix calculation, AWGN combination.

Input data le created by selecting waveform pattern le created with other IQproducer

software, and IQ data (ASCII) created with other general-purpose simulation tools.

LTE IQproducer MX370108A Generates wanted waveform patterns with parameters modied according to 3GPP TS

36.211, TS 36.212, TS 25.213 LTE FDD specications.

XG-PHS IQproducer MX370109A Generates wanted waveform patterns with parameters modied according to Next

Generation PHS Specication PHS (XGP: eXtended Global Platform) specications.

LTE TDD IQproducer MX370110A Generates wanted waveform patterns with parameters modied according to 3GPP TS

36.211, TS 36.212, TS 36.213 LTE TDD specications.

WLAN IQproducer MX370111A Generates waveform patterns for IEEE Std 802.11-2007 and IEEE Std 802.11n-2009

IEEE 802.11a/b/g/j/n/p specications.

TD-SCDMA IQproducer MX370112A

Generates wanted waveform patterns with parameters modied according to TD-

SCDMA specications standardized by TRx characteristics evaluation tests (excluding

performance tests) for 3GPP TS 25.221, TS 25.222, TS 25.223, TS 25.105, TS 25.142

10 Configuration Guide lMG3710A

Hardware Option Retrofits

The following hardware options can be retrofitted.

The MG3710A must be returned to the Anritsu plant for hardware retrofitting.

Name Option No. Additional Information Reference Steps

Options for both 1stRF and 2ndRF

Rubidium Reference Oscillator MG3710A-101 Not simultaneously with Opt. 002/102 3

High Stability Reference Oscillator MG3710A-102 Not simultaneously with Opt. 001/101 3

2ndary HDD MG3710A-111 10

Universal Input/Output MG3710A-117 8

BER Test Function MG3710A-121 9

OS Upgrade to Windows 7 MG3710A-313 Cannot applied to MG3710A with Opt. 029 (Windows 7) 10

1stRF Options

Analog IQ Input/Output MG3710A-118 7

High Power Extension for 1stRF MG3710A-141 4

Low Power Extension for 1stRF MG3710A-142 4

Reverse Power Protection for 1stRF MG3710A-143 4

ARB Memory Upgrade 256 Msample for 1stRF MG3710A-145 Not simultaneously with Opt. 046/146 5

ARB Memory Upgrade 1024 Msample for 1stRF MG3710A-146 Not simultaneously with Opt. 045/145 5

Combination of Baseband Signal for 1stRF MG3710A-148 6

AWGN for 1stRF MG3710A-149 6

2ndRF Options

2ndRF 100 kHz to 2.7 GHz MG3710A-162 Cannot be installed if 2ndRF option not installed 2

2ndRF 100 kHz to 4 GHz MG3710A-164 Cannot be installed if 2ndRF option not installed 2

2ndRF 100 kHz to 6 GHz MG3710A-166 Cannot be installed if 2ndRF option not installed 2

High Power Extension for 2ndRF MG3710A-171 4

Low Power Extension for 2ndRF MG3710A-172 4

Reverse Power Protection for 2ndRF MG3710A-173 4

ARB Memory Upgrade 256 Msample for 2ndRF MG3710A-175 Not simultaneously with Opt. 076/176 5

ARB Memory Upgrade 1024 Msample for 2ndRF MG3710A-176 Not simultaneously with Opt. 075/175 5

Combination of Baseband Signal for 2ndRF MG3710A-178 6

AWGN for 2ndRF MG3710A-179 6

Retrot to Current MG3710A

Autres manuels pour MG3710A

Table des matières

Autres manuels Anritsu Équipement d'enregistrement

Anritsu

Anritsu MD1230A-06 Manuel utilisateur

Manuels Équipement d'enregistrement populaires d'autres marques

KV2 Audio

KV2 Audio 500 Series Manuel utilisateur

Robotics Technologies

Robotics Technologies microBus-Cam II Manuel utilisateur

Seca

Seca 460 Manuel utilisateur

Cognex

Cognex MVS-8000 Series Manuel utilisateur

Mect

Mect MPNC006 Series Manuel utilisateur

Bad Caf

Bad Caf THE LEASH Manuel utilisateur

Strymon

Strymon NIGHTSKY Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric 16CH DIGITAL RECORDER DX-TL5000U Manuel utilisateur

Tews Technologies

Tews Technologies TPMC465 Manuel utilisateur

Honeywell

Honeywell Excel 50 Manuel utilisateur

SeaLevel

SeaLevel COMM+8.LPCI Manuel utilisateur

Arturia

Arturia AUDIOFUSE STUDIO Manuel utilisateur

Rukra

Rukra RK-1240 Manuel utilisateur

Samson

Samson SCOM Manuel utilisateur

Dynacord

Dynacord DPS260 Manuel utilisateur

Nice

Nice Core Manuel utilisateur

Pyle Pro

Pyle Pro PSS8 Manuel utilisateur

RF-System

RF-System TinyGate Manuel d'utilisation et d'entretien
