Anchor AN-Mini Manuel utilisateur

AN-MINI Speaker Monitor

Portable Speaker Monitor Speciﬁcations

Advancing Technology

The AN-Mini speaker monitor is the most powerful, smallest system in the market.

The AN-Mini is battery-operated so you can take it anywhere. Just switch it on and

you are ready for indoor or outdoor assemblies anywhere. You can also connect

your ipod, MP3 player or CD Player to the AN-Mini’s convenient Line In jack.

Anchor Audio, Inc. 888/444-6077

Portable Sound Systems • Torrance, California www.anchoraudio.com

S-ANMINI/0708

AN-MINI FEATURES

6-YEAR WARRANTY!

REACH CROWDS OF 50+

DELIVERS 109 dB OF CLEAR SOUND

BUILT-IN UHF WIRELESS RECEIVER AVAILABLE

LIGHTWEIGHT AT ONLY 2.5 POUNDS

LINE IN JACK FOR IPOD, MP3 & CD PLAYER

16 CHANNEL UHF DIVERSITY WIRELESS

BY ANCHOR AUDIO

OPERATES UP TO 12 HOURS

ON FULLY CHARGED BATTERIES

4.5” NEODYMIUM WOOFER & 30W AMPLIFIER

PHANTOM-POWERED INPUT FOR

ELECTRET-TYPE MICROPHONE

HANDHELD WIRED MICROPHONE AVAILABLE

OPTIONAL RECHARGEABLE KIT

MADE IN THE USA!

ACCESSORIES

MIC-50 Dynamic handheld wired microphone

SOFT-30 Soft case – custom colors available

SS-300 Speaker stand

RC-30 Battery charging kit

(FEATURES & SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE)

UHF WIRELESS

WH-6000 Wireless Handheld mic/transmitter

WB-6000 Wireless body-pack transmitter

w/ handsfree microphone. Mic options include:

Over-the-Ear/EM-60T, Lapel/LM-60,

Collar/CM-60, Headband/HBM-TA4F

AN-MINI TECHNICAL SPECIFICATIONS

Rated Power Output 30 Watts

Max SPL@Rated Power 109 dB @ 1 meter

Frequency Response 100Hz - 15KHz ±3dB

Speaker Type 4.5” Neodymium woofer

Battery Type 10 ‘AA’ alkaline

Dimensions

(HWD)

5.5 x 5.5 x 6.5” / 14 x 14 x 16.5 cm

Weight 2.5 pounds / 1.13 Kg

Output

Line line level, 3.5 mm

Inputs

Line line level, 3.5 mm

Powered Mic Lo-Z phantom power, 3.5 mm jack

Mic Lo-Z, 1/4” phone

RC-30 – Recharge Kit (optional)

Battery Type 10 ‘AA’ size, NiMH 2.5 Ah

Charger AC-30

AC-30 Input 120 VAC, 60Hz, 24 watt max

AC-30/220 Input 220 VAC, 50Hz, 24 watt max

Shipping Weight 2.1 pounds / 1.0 Kg

AN-MINI MODELS

AN-MINI AC/DC powered speaker monitor

AN-MINIU1 AN-MINI w/ 1 built-in wireless receiver

(AN-MINIU1 Control Panel Shown)
