USER MANUAL
DUX-SRX
100-METER 4K HDBASET SCALING RECEIVER
2USER MANUAL - DUX-SRX
100-METER 4K HDBASET SCALING RECEIVER
Table of Contents
IMPORTANT SAFETY INSTRUCTIONS...................................................................03
INTRODUCTION.....................................................................................................04
PACKING LIST .......................................................................................................05
SPECIFICATIONS ...................................................................................................06
CABLE SPECIFICATIONS........................................................................................07
PANEL OVERVIEW.................................................................................................08
INSTALL HARDWARE ............................................................................................10
OPERATE WITH IR .................................................................................................12
Control the Display...........................................................................................12
Control the Source ...........................................................................................13
OPERATE WITH RS232..........................................................................................14
RS232 Pinout...................................................................................................14
RS232 for API Command.................................................................................14
RS232 for Firmware Upgrading........................................................................15
RS232 for Serial Communication.....................................................................15
TROUBLESHOOTING .............................................................................................17
APPENDIX: API COMMAND...................................................................................18
3
USER MANUAL - DUX-SRX
100-METER 4K HDBASET SCALING RECEIVER
IMPORTANT SAFETY INSTRUCTIONS
NOTE:
We reserve the right to change the content from time to time without notice.
WARNINGS:
To reduce the risk of fire, electric shock or product damage, please observe
the following Safety Instructions while installing and operating the product:
Do not expose this apparatus
to rain, moisture, dripping or
splashing. No objects filled with
liquids, such as vases, shall be
placed on the apparatus.
To prevent risk of electric
shock or fire hazard due to
overheating, do not obstruct
the unit’s ventilation openings
with newspapers, tablecloths,
curtains, and similar items.
Do not install near any heat
sources such as radiators,
heat registers, stoves, or other
apparatus (including amplifiers)
that produce heat.
Do not place sources of naked
flames, such as lighted candles,
on the unit.
Clean this apparatus only with
dry cloth.
Protect the power cord from
being walked on or pinched
particularly at plugs.
Refer all servicing to qualified
service personnel.
Unplug this apparatus during
lightning storms or when un-
used for long periods of time.
Only use attachments/accesso-
ries specified by the manufac-
turer.
Do not install or place this
unit in a bookcase, built-in
cabinet or in another confined
space. Ensure the unit is well
ventilated.
4USER MANUAL - DUX-SRX
100-METER 4K HDBASET SCALING RECEIVER
INTRODUCTIONS
DUX-SRX is 100m HDBaseT Receiver with 4K@60Hz Scaler, transmits uncompressed
4K@60Hz UHD video, Ethernet, RS232 and IR up to 100m/328ft over a signal CatX cable
and supports analog and digital audio de-embedding for HDMI audio output.
DUX-SRX comes with an auto-scaler for HDMI scaling out which can be adjusted by API
command. In addition, the HDBaseT Receiver is capable of automatic display control
through CEC or RS232, volume adjustment, Ethernet routing and accepts third-party
control.
DUX-SRX HDBaseT Scaling Receiver is ideal for applications where high quality video
transmission and scaling is required. While working with a Matrix like DUX-8D, a
standalone AV switching and control system with video scaling will be created and will
meet requirements for classroom and huddle room applications.
Features
Capable of transmission:
Via Cat5e/6 cable:
- Up to 70m/230ft: 4K@30Hz YUV 4:4:4 24bit or 4K@60Hz YUV 4:2:0 24bit
- Up to 100m/328ft: 1080p@60Hz 36bit
Via Cat6a/7 cables:
- Up to 100m/328ft: 4K@30Hz YUV 4:4:4 24bit or 4K@60Hz YUV4:2:0 24bit
- Up to 100m/328ft: 1080p@60Hz 48bit
Supports analog and digital audio de-embedding for HDMI Audio Out.
Fully compliant with HDMI 1.4, and compatible with HDMI 2.0 (4K@60Hz, 4:2:0).
HDCP 2.2 compliant.
Bi-directional IR, RS232 and Ethernet pass-through over a CatX cable.
Default auto-scaler for HDMI Scaling Out or output resolution adjustment by API.
Built-in CEC controller for HDMI OUT.
Built-in RS232 controller for pre-loading or storage of RS232 commands of the
display device.
Automatic CEC and RS232 command to power on or standby the display by
detecting input signal status.
Seamless switching when using with a Matrix like DUX-8D.
NOTE: The actual signal transmission distance depends on signal resolution and cable
quality.
5
USER MANUAL - DUX-SRX
100-METER 4K HDBASET SCALING RECEIVER
PACKING LIST
1 x DUX-SRX
1 x Power Adapter (12 VDC, 3.0A)
1 x AC Cable
2 x Phoenix Male Connector (3.5 mm, 3-pin)
1 x IR Emitter
1 x IR Receiver
2 x Mounting Brackets
1 x User Manual
6USER MANUAL - DUX-SRX
100-METER 4K HDBASET SCALING RECEIVER
SPECIFICATIONS
Technical
Input 1 x HDBT IN
Input Signal Type HDBT
Input Resolution
• VESA:
800x6008, 1024x7688, 1280x7688, 1280x8008,
1280x9608, 1280x10248, 1360x7688, 1366x7688,
1440x9008, 1600x9008, 1600x12008, 1680x10508,
1920x12008
• SMPTE:
720x480P7,8, 720x576P6, 1280x720P6,7,8,
1920x1080P6,7,8, 3840x2160P2,3,5,6,8, 4096x2160P2,3,5,6,8
1 = @ 23.98 Hz, 2 = @ 24 Hz, 3 = @ 25 Hz,
4 = @ 29.97 Hz, 5 = @ 30 Hz, 6 = @ 50 Hz,
7 = @ 59.94 Hz, 8 = @ 60 Hz;
Input Video Level 0.5-1.2 V p-p
Output
1 x HDMI OUT
1 x S/PDIF OUT
1 x AUDIO OUT
Output Signal Type HDMI: TMDS
Audio Output S/PDIF OUT
L/R OUT
Audio Format S/PDIF OUT: PCM 2.0, Dolby 2.0, Dolby 5.1;
L/R OUT: PCM 2.0.
Output Resolution
• VESA:
800x6008, 1024x7688, 1280x7688, 1280x8008,
1280x9608, 1280x10248, 1360x7688, 1366x7688,
1440x9008, 1600x9008, 1600x12008, 1680x10508,
1920x12008
• SMPTE:
1280x720P8, 1920x1080P8, 3840x2160P5,8
1 = @ 23.98 Hz, 2 = @ 24 Hz, 3 = @ 25 Hz,
4 = @ 29.97 Hz, 5 = @ 30 Hz, 6 = @ 50 Hz,
7 = @ 59.94 Hz, 8 = @ 60 Hz;
Video Impedance 100 Ω
Maximum Pixel Clock 594 MHz
7
USER MANUAL - DUX-SRX
100-METER 4K HDBASET SCALING RECEIVER
Control
Control Methods Telnet, RS232, IR
General
Operating Temperature / RH 32°F ~ 113°F (0°C ~ 45°C)
10% ~ 90%, non-condensing
Storage Temperature / RH -4°F ~ 140°F (-20°C ~ 70°C)
10% ~ 90%, non-condensing
Power Supply 12 VDC 3.0A
Power Consumption 16.4 W (Max.)
ESD Protection
Human-body model:
• ±8 kV (Air-gap discharge)
• ±4 kV (Contact discharge)
Dimension (W × H × D) 234.4 mm × 25 mm × 143 mm
Weight 0.9 kg
Certification CE, FCC
CABLE SPECIFICATIONS
To ensure best performance of DUX-SRX, please use stright-through Category cables
wired to T568B standard and a Transmitter device which also supports 100-meter
transmission.
Cable Type Range Supported Video
Cat5e/6
100m/328ft 1080p@60Hz 36bit
70m/230ft
1080p@60Hz 3D
4K@30Hz YUV4:4:4
4K@60Hz YUV4:2:0
Cat6a/7 100m/328ft
1080p@60Hz 36bit
1080p@60Hz 48bit
1080p@60Hz 3D
4K@30Hz YUV4:4:4
4K@60Hz YUV4:2:0
8USER MANUAL - DUX-SRX
100-METER 4K HDBASET SCALING RECEIVER
PANEL OVERVIEW
1 2 3 4 5
Item Name Description
1 POWER LED On: DUX-SRX is powered on.
Off: DUX-SRX is powered off.
2 SCALER LED Blinking: DUX-SRX is working properly.
Off: DUX-SRX is not working properly.
3 STATUS LED Blinking: DUX-SRX is working properly.
Off: DUX-SRX is not working properly.
4 HDCP LED
On: HDCP video is being transmitted.
Blinking: Non-HDCP video is being transmitted.
Off: No HDMI signal.
5 LINK LED
On: HDBT IN is linked.
Off / Blinking: HDBT IN is not linked and there is a link
error.
Front Panel
9
USER MANUAL - DUX-SRX
100-METER 4K HDBASET SCALING RECEIVER
1 2 3 4 5 6 7 8 9 10
Item Name Description
1 DC 12V Connects the Power Adapter provided.
2 ETHERNET 1 Connects to an Ethernet device.
3 ETHERNET 2 Connects to an Ethernet device.
4 HDBT IN Connects to an HDBT Transmitter device via a CatX cable.
5 IR IN Connects the IR Receiver provided.
6 IR OUT Connects the IR Emitter provided.
7 HDMI OUT Connects to an HDMI display device.
8 S/PDIF OUT Uses a coaxial port for S/PDIF digital audio output.
9 AUDIO OUT Uses a 3-pin Phoenix female port for L/R analog audio output.
10 RS232 For RS232 serial communication or firmware upgrading.
Rear Panel
10 USER MANUAL - DUX-SRX
100-METER 4K HDBASET SCALING RECEIVER
INSTALL HARDWARE
WARNING:
Before installation, disconnect the power supplies of all the devices.
Please use quality cables and accessories specified or provided by the
manufacturer.
During installation, connect and disconnect cables with caution.
To install DUX-SRX with an HDBT Transmitter (e.g. DUX-8D) (See Application
Example: System Wiring on Page 11):
1. Connect the HDBT Transmitter (e.g. DUX-8D) selected to input sources (e.g. HDMI
input sources from a Blu-ray Player, cable/satellite TV, media server, etc.).
2. Connect DUX-SRX’s HDBT IN to HDBT OUT of the HDBT Transmitter.
3. Connect DUX-SRX’s HDMI OUT to an HDMI output device (e.g. a projector).
4. If Audio Output is needed, connect DUX-SRX’s S/PDIF (for digital audio signal) or
L/R (for analog audio signal) connector.
5. Connect the included Power Adapter to DUX-SRX.
6. Power on all the devices and start operation.
NOTE:
1) 70m/230ft @4K or 100m/328ft @1080p are maximum transmission distances realizable
when DUX-SRX and other devices are in perfect conditions and the straight cable runs with no
electrical interference, bends, kinks, patch panels or wall outlets, etc. If any of these turns to be
an issue in your installation, transmission distance will be affected.
2) When all set, check the LED indicators of DUX-SRX. For LED indication, please refer to page
08.
