USER MANUAL

DCP-SRX

100m 4K HDBaseT Daisy-Chain Scaling Receiver

2USER MANUAL

DCP-SRX

TABLE OF CONTENTS

IMPORTANT SAFETY INSTRUCTIONS ...................................................................03

1. INTRODUCTION.................................................................................................04

2. PACKING LIST ...................................................................................................05

3. SPECIFICATIONS...............................................................................................06

4. PANEL OVERVIEW.............................................................................................08

4.1 Front Panel.................................................................................................08

4.2 Rear Panel..................................................................................................08

5. SCALER SWITCH...............................................................................................09

6. APPLICATION & INSTALLATION........................................................................10

6.1 Typical Application .....................................................................................10

6.2 Installation & Connection ...........................................................................10

7. CEC & RS232 AUTO CONTROL .........................................................................13

8. SET-UP & CONTROL..........................................................................................15

8.1 Web UI .......................................................................................................15

8.1.1 Log Into Web UI ...............................................................................15

8.1.2 Control Through Web UI...................................................................16

8.1.2.1 Status ....................................................................................18

8.1.2.2 Conﬁguration.........................................................................18

8.1.2.3 Advanced...............................................................................23

8.1.2.4 Device List.............................................................................29

8.2 Telnet..........................................................................................................29

9. RESET................................................................................................................31

APPENDIX: API COMMAND SET............................................................................32

USER MANUAL

DCP-SRX

IMPORTANT SAFETY INSTRUCTIONS

NOTE: We reserve the right to change the content from time to time without

notice.

WARNINGS: To reduce the risk of ﬁre, electric shock or product damage, please

observe the following Safety Instructions while installing and operating the

product:

Do not expose this apparatus

to rain, moisture, dripping or

splashing. No objects ﬁlled with

liquids, such as vases, shall be

placed on the apparatus.

To prevent risk of electric

shock or ﬁre hazard due to

overheating, do not obstruct

the unit’s ventilation openings

with newspapers, tablecloths,

curtains, and similar items.

Do not install near any heat

sources such as radiators,

heat registers, stoves, or other

apparatus (including ampliﬁers)

that produce heat.

Do not place sources of naked

ﬂames, such as lighted candles,

on the unit.

Clean this apparatus only with

dry cloth.

Protect the power cord from

being walked on or pinched

particularly at plugs.

Refer all servicing to qualiﬁed

service personnel.

Unplug this apparatus during

lightning storms or when un-

used for long periods of time.

Only use attachments/accesso-

ries speciﬁed by the manufac-

turer.

Do not install or place this

unit in a bookcase, built-in

cabinet or in another conﬁned

space. Ensure the unit is well

ventilated.

4USER MANUAL

DCP-SRX

1. INTRODUCTION

DCP-SRX is a Scaling Receiver able to transmit 4K/Ultra HD signal over HDBaseT up to

100 meters and supports cascade connection of multiple A/V sources, displays or any

devices capable of HDBaseT transmission.

DCP-SRX accepts and outputs HDBaseT signal through its HDBT IN and HDBT OUT

ports. Its HDMI OUT supports up to 4K@60Hz scaling output and audio extraction and

can be connected to a local monitor or zone displays. With a built-in Ethernet Switch,

DCP-SRX allows Ethernet pass-through over HDBaseT for either LAN control or LAN

access.

DCP-SRX is embedded with a CEC controller and a RS232 controller, with its RS232 port

capable of RS232 serial communication over TCP/IP.

DCP-SRX is designed bearing user-friendliness in mind. For users with different levels

of A/V switching experience, DCP-SRX offers various control options, either the intuitive

Web UI or the Telnet controls for advanced users. A SCALER switch is available for

manual set-up of output scaling parameter. An extra USB connector is provided for

power charging mobile phones, tablets and the like. For applications in need of a Scaling

Receiver with great ease of control and versatility in connection, DCP-SRX is the choice.

DCP-SRX offers a future-ready Ultra HD A/V switching and distribution solution and is

ideal for collaboration or presentation in conference and education applications.

Features

• HDMI OUT with built-in scaler (up to 4K@60Hz) and audio extraction

• HDBT IN and HDBT OUT for cascade connection of multiple A/V sources and

displays

• HDMI IN with HDCP 2.2 compatibility

• Transmits 4K@60Hz 4:2:0 up to 70m over Cat5e/Cat5 or up to 100m over Cat6a/

Cat7

• Built-in CEC and RS232 controller for smart control of display devices

• Daisy-chain Grouping for setting up separate groups with a system

• Intuitive WEB UI control and Telnet control for advanced users

• Built-in Ethernet Switch for LAN control or access

• Built-in USB charger provides power of 5V/1.5A

• Advanced signal re-locking and cable equalization for multiple daisy-chains

• Audio supports PCM 2 channels

USER MANUAL

DCP-SRX

2. PACKING LIST

 1 x DCP-SRX

 1 x Power Supply (12 DVC, 3A)

 2 x Phoenix Male Connectors (3.5 mm, 3 pins)

 2 x Mounting Brackets

 1 x User Manual (this manual)

6USER MANUAL

DCP-SRX

3. SPECIFICATIONS

Technical

Input Connections 1 x HDBaseT IN

Input Video Type HDBaseT

Input Resolution

• VESA

800 x 6008, 1024 x 7688, 1280 x 7688, 1280 x 8008, 1280 x 9608,

1280 x 10248, 1360 x 7688, 1366 x 7688, 1400 x 10508,1440 x 9008,

1600 x 9008, 1600 x 12008, 1680 x 10508, 1920 x 12008.

• SMPTE

720 x 480P7,8,720 x 576P8,1280 x 720P6,8,1920 x 1080I6,8,1920 x

1080P2,3,5,6,8,3840 x 2160P2,3,5,6,8, 4096 x 2160P2,3,5,6,8.

Note:

1. 1 = @ 23.98 Hz, 2 = @ 24 Hz, 3 = @ 25 Hz, 4 = @ 29.97 Hz, 5

= @ 30 Hz, 6 = @ 50 Hz, 7 = @ 59.94 Hz, 8 = @ 60 Hz;

2. HDMI 1.4 with 4k@50Hz/60Hz(chroma sub-sampling 4:2:0

8-bit only) for HDBaseT input.

Output 1 x HDMI OUT, 1 x HDBaseT OUT

Output Signal Type HDMI 2.0 with 4K, HDBaseT

Output Resolution

• HDMI

3840 x 2160P5,8,1920 x 12008,1920 x 1080P8,1280 x 10248, 1280 x

8008, 1280 x 720P8, 1024 x 7688, Auto Scaler.

• HDBaseT

1) VESA

800 x 6008, 1024 x 7688, 1280 x 7688, 1280 x 8008, 1280 x 9608,

1280 x 10248, 1360 x 7688, 1366 x 7688, 1400 x 10508,1440 x 9008,

1600 x 9008, 1600 x 12008, 1680 x 10508, 1920 x 12008.

2) SMPTE

720 x 480P7,8, 720 x 576P8,1280 x 720P6,8, 1920 x 1080I6,8, 1920 x

1080P2,3,5,6,8, 3840 x 2160P2,3,5,6,8, 4096 x 2160P2,3,5,6,8.

Note:

1. 1 = @ 23.98 Hz, 2 = @ 24 Hz, 3 = @ 25 Hz, 4 = @ 29.97 Hz, 5

= @ 30 Hz, 6 = @ 50 Hz, 7 = @ 59.94 Hz, 8 = @ 60 Hz;

2. HDMI 1.4 with 4k@50Hz/60Hz( chroma sub-sampling 4:2:0

8-bit only) for HDBaseT input.

USER MANUAL

DCP-SRX

Control

Control Methods Telnet, Web UI

General

Operating Temperature

& RH 32°F ~ 113°F (0°C ~ 45°C), 10% ~ 90% (non-condensing)

Storage Temperature &

RH -4°F ~ 158°F (-20°C ~ 70°C), 10% ~ 90% (non-condensing)

ESD Protection

Human-body model:

• ±8kV (air-gap discharge)

• ±4kV (contact discharge)

Power Supply 12 VDC, 3A

Power Consumption 20.6 W (Maximum)

Dimensions (W x H x D) 223 mm x 27 mm x 196.2 mm

Weight 1.2 kg

Certiﬁcation CE, FCC

8USER MANUAL

DCP-SRX

4. PANEL OVERVIEW

4.1 Front Panel

1 2 3

Item Name Description

1 ID LED

Indicates the device to be controlled. The LED will ﬂash

when the ID button in the Web UI (Conﬁgure > Device) is

turned ON.

2 POWER LED Illuminates when the device is powered on.

3 USB connector Accepts a ﬂash driver for Scaler updating.

4.2 Rear Panel

1 2 3 45 6 7 8 9

Item Name Description

1 HDBT IN Connect to HDBT OUT of any HDBT transmitter or DCP-MTX

or another DCP-SRX.

2 RS232 Connects to a controllable device, e.g. projector, for RS232

pass-through control.

3 ETHERNET Connects to a LAN device, e.g. IP-based touch panel for LAN

control.

4 HDMI OUT Connects to an HDMI display device.

5 AUDIO OUT Connects to an audio system, e.g. ampliﬁer.

6 SCALER switch Uses a DIP switch for adjust output scaling.

7 HDBT OUT Connects to HDBT IN of any HDBT device or DCP-MTX.

8 RESET button Resets the device to factory default.

9 DC 12V Connects to the power adapter provided.

USER MANUAL

DCP-SRX

5. SCALER SWITCH

DCP-SRX installs a “SCALER” DIP switch at the rear panel for manual adjustment of

the scaling output.

By default, the SCALER switch is in “Auto Scaler” position (all switches are set to 0000

or upward). Users are allowed to set DCP-SRX to desired scaling output resolution by

using the SCALER switch.

11 2

ON DIP

3 4

Default:

Auto Scaler

DIP SWITCH SETTINGS SCALING OUTPUT RESOLUTION

0 0 0 0 Auto Scaler (Default)

0 0 0 1 Fix 1024 x 768@60Hz

0 0 1 0 Fix 1280 x 720@60Hz

0 0 1 1 Fix 1280 x 800@60Hz

0 1 0 0 Fix 1280 x 1024@60Hz

0 1 0 1 Fix 1920 x 1080@60Hz

0 1 1 0 Fix 1920 x 1200@60Hz

0 1 1 1 Fix 3840 x 2160@30Hz

1 0 0 0 Fix 3840 x 2160@60Hz

1 0 0 1 SCALER by WEB GUI or API control

Other settings Reserved for future use

10 USER MANUAL

DCP-SRX

6. APPLICATION & INSTALLATION

6.1 Typical Application

DCP-SRX is normally used with DCP-MTX 4K HDBaseT Daisy-Chain Presentation

Switcher and supports cascade connection of multiple DCP-SRXs and DCP devices.

To install multiple DCP-MTXs and DCP-SRXs, simply connecting HDBT OUT of DCP-

MTX/DCP-SRX to HDBT IN of next DCP-MTX/DCP-SRX, you will get a Chain Mode

connection. By connecting the last DCP device back to the ﬁrst through HDBT, you will

get a Ring Mode system. (see application example below).

DCP-MTX 1 DCP-MTX 2 DCP-SRX 1 DCP-SRX 2

SOURCE 1 SOURCE 2

DCP-MTX N

SOURCE N

DISPLAY 1 DISPLAY 2

HDBaseT HDBaseT HDBaseT HDBaseT

DCP-SRX N

DISPLAY N

HDBaseT

Chain Mode

DCP-MTX 1 DCP-MTX 2 DCP-SRX 1 DCP-SRX 2

SOURCE 1 SOURCE 2

DCP-MTX N

SOURCE N

DISPLAY 1 DISPLAY 2

HDBaseT HDBaseT HDBaseT

HDBaseT

DCP-SRX N

DISPLAY N

HDBaseT

Ring Mode

6.2 Installation & Connection

To create a Chain- or Ring-type connection of multiple DCP-MTXs, DCP-SRXs, sources

and displays, please refer to the instructions below and the “SYSTEM WIRING” chart:

1. Connect DCP-MTXs and DCP-SRXs through HDBT:

1) Connect HDBT OUT of the ﬁrst DCP-MTX to HDBT IN of the next (e.g. DCP-

MTX 1 to DCP-MTX 2);

2) Connect the rest DCP-MTXs through HDBT likewise.

3) Connect HDBT OUT of the ﬁrst DCP-SRX to HDBT IN of the next (e.g. DCP-

SRX 1 to DCP-SRX 2);

4) Connect the rest DCP-SRXs through HDBT likewise.

5) Connect HDBT OUT of the last DCP-MTX to HDBT IN of the ﬁrst DCP-SRX

Table des matières

Autres manuels AMX Récepteur

AMX

AMX MAX-AVM Manuel utilisateur

AMX

AMX AutoPatch Cat5 S-Video+Stereo TX Manuel utilisateur

AMX

AMX AXU-IR Manuel utilisateur

AMX

AMX AXD-IR Plus Manuel utilisateur

AMX

AMX DXLink Manuel utilisateur

AMX

AMX AVB-TX-DGX-HD15-SC Fiber Manuel utilisateur

AMX

AMX Mio Moderno MIO-IRRX Manuel utilisateur

AMX

AMX AXR-RF Manuel utilisateur

AMX

AMX AXC-TEMP Mode d’emploi

AMX

AMX Viewpoint AXR-RF Manuel utilisateur

AMX

AMX AXR-RF Manuel utilisateur

AMX

AMX AXR-IRSM Plus Manuel utilisateur

AMX

AMX UDM-RX02N Manuel utilisateur

AMX

AMX Sensors and Receivers IR Manuel utilisateur

AMX

AMX DX-TX Guide rapide de l'utilisateur

AMX

AMX AutoPatch CAT-5 RGBHV RX Manuel utilisateur

AMX

AMX Endeleo UDM-RX01 Manuel utilisateur

AMX

AMX Viewpoint AXR-RF Manuel utilisateur

AMX

AMX FG1010-37 Manuel utilisateur

AMX

AMX Endeleo Multi-Format Receiver UDM-RX01 Manuel utilisateur

AMX

AMX Mio Moderno MIO-IRRX Manuel utilisateur

AMX

AMX PMB-RF Manuel utilisateur

AMX

AMX DXF-TX-MMD Manuel utilisateur

AMX

AMX DUX-SRX Manuel utilisateur

Manuels Récepteur populaires d'autres marques

Garmin

Garmin GA 23 Manuel utilisateur

Aiphone

Aiphone PS-12F Manuel utilisateur

IMES

IMES TCS-01CA-PMI Manuel utilisateur

BWI Eagle

BWI Eagle AIR-EAGLE SR Manuel

AMIMON

AMIMON AMN12310 WHDI Manuel utilisateur

Dual

Dual DMCPA79BT Mode d'emploi

Sound Associates

Sound Associates SA652P Manuel utilisateur

Sherwood

Sherwood NewCastle R-772 Manuel utilisateur

Audio

Audio A10-RX Series Manuel utilisateur

AllSee

AllSee PushShare PSRV1.1 Manuel utilisateur

DEMAG

DEMAG DRC-DR D2 Manuel utilisateur

Teleco

Teleco TVRCL868A02 Manuel utilisateur

Bosch

Bosch RF3222E Manuel utilisateur

Kramer

Kramer 631R Manuel utilisateur

Xpress

Xpress xmc10 Manuel utilisateur

JVC

JVC KD-MR1BTS Manuel utilisateur

Omega Engineering

Omega Engineering UWTC-REC3 Manuel utilisateur

e-survey

e-survey E300 Pro Manuel utilisateur
