Amprobe 5XP-A Manuel utilisateur

Users Manual

5XP-A

15XP-B

35XP-A

Compact Digital

Multimeters

99 Washington Street

Melrose, MA 02176

Phone 781-665-1400

Toll Free 1-800-517-8431

Visit us at www.TestEquipmentDepot.com

Compact Digital Multimeters

2A MAX

FUSED

CAT 600V

CAT 1000V

CAT 300V

COM A

MAX

1000V

750V

Hz Temp

400

1000

35XP-A

RANGE NON

CONTACT

VOLTAGE

HOLD

auto-off

°C

OFF

°F

1832 400

1.) Display

Afﬁcheur

Display

Pantalla

2.) Feature Buttons

boutons de fonctions

funktionstasten

pulsanti delle funzioni

botones de función

3.) Function/Range Switch

commutateur de gamme/fonction.

funktion/bereich-schalter

selettore funzione/portata

selector de la función y del rango

4.) Test Lead Connections

branchements des cordons de test

messleitungsanschlÜsse

boccole per i cavetti

conexiones de los conductores de prueba

5.) Strap Clip

clip de bretelle

klemme

clip in velcro

clip para correa

6.) Battery/Fuse Cover

capot des fusibles/pile

batterie-/Sicherungsabdeckung

Sportello del vano portapile/fusibili

puerta de la batería y el fusible

5XP-A

15XP-B

35XP-A

Compact Digital Multimeters

Users Manual

• Manual de uso

• Mode d’emploi

• Bedienungshandbuch

• Manuale d’Uso

English

Limited Warranty and Limitation of Liability

Your Amprobe product will be free from defects in material

and workmanship for 1 year from the date of purchase. This

warranty does not cover fuses, disposable batteries or damage

from accident, neglect, misuse, alteration, contamination, or

abnormal conditions of operation or handling. Resellers are not

authorized to extend any other warranty on Amprobe’s behalf.

To obtain service during the warranty period, return the product

with proof of purchase to an authorized Amprobe Test Tools

Service Center or to an Amprobe dealer or distributor. See Repair

Section for details. THIS WARRANTY IS YOUR ONLY REMEDY.

ALL OTHER WARRANTIES - WHETHER EXPRESS, IMPLIED OR

STAUTORY - INCLUDING IMPLIED WARRANTIES OF FITNESS FOR

A PARTICULAR PURPOSE OR MERCHANTABILITY, ARE HEREBY

DISCLAIMED. MANUFACTURER SHALL NOT BE LIABLE FOR ANY

SPECIAL, INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES

OR LOSSES, ARISING FROM ANY CAUSE OR THEORY. Since some

states or countries do not allow the exclusion or limitation of an

implied warranty or of incidental or consequential damages, this

limitation of liability may not apply to you.

Repair

All test tools returned for warranty or non-warranty repair or

for calibration should be accompanied by the following: your

name, company’s name, address, telephone number, and proof of

purchase. Additionally, please include a brief description of the

problem or the service requested and include the test leads with

the meter. Non-warranty repair or replacement charges should be

remitted in the form of a check, a money order, credit card with

expiration date, or a purchase order made payable to Amprobe®

Test Tools.

In-Warranty Repairs and Replacement – All Countries

Please read the warranty statement and check your battery before

requesting repair. During the warranty period any defective test

tool can be returned to your Amprobe® Test Tools distributor

for an exchange for the same or like product.

Compact Digital Multimeters

CONTENTS

SAFETY INFORMATION ........................................................... 2

SYMBOLS USED IN THIS MANUAL ........................................ 3

MAKING MEASUREMENTS ..................................................... 3

Verify Instrument Operation.............................................. 3

Range Selection .................................................................. 4

Correcting an Overload (0o or -0o) Indication�.............. 4

Measuring DC Voltage (See Figure 1)................................ 4

Measuring AC Voltage (See Figure 2)................................ 5

Preparing for Current Measurements ............................... 5

Measuring DC Current (See Figure 3)................................5

Measuring AC Current (See Figure 4)................................6

Measuring Resistance (See Figure 5) ................................. 6

Testing for Continuity (See Figure 6)................................. 7

Testing Diodes See (See Figure 7) ......................................7

Measuring Capacitance (35XP-A only) (See Figure 8)....... 7

Measuring Temperature (35XP-A only) (See Figure 9) ..... 8

Measuring Frequency (35XP-A only) (See Figure 10)........ 8

Measuring NCV (Non-Contact Voltage) (See Figure 11)... 9

Testing Battery Voltage (5XP-A only) (See Figure 12) ......9

Testing Logic Levels (15XP-B only) (See Figure 13) ...........9

ADDITIONAL FEATURES .......................................................... 9

Input Test Lead Warning .................................................... 10

MIN MAX Measurements (Model 5XP-A only) ................. 10

Auto Power Off (Models 15XP-B and 35XP-A only) ........ 10

HOLD Measurements ......................................................... 11

PRODUCT MAINTENANCE ...................................................... 11

Cleaning ............................................................................. 11

Troubleshooting ................................................................. 11

Battery and Fuse Replacement (See Figure 14) ................ 12

SPECIFICATIONS ...................................................................... 12

Test Equipment Depot - 800.517.8431 -

99 Washington Street Melrose, MA 02176

TestEquipmentDepot.com

2A MAX

FUSED

CAT

600V

1000V

CAT

COM A

MAX

1000V

750V

200mA MAX

FUSED

BATT 1.5V

BATT 9V

CAT 600V

CAT 1000V

CAT 300V

VCOM mA

MAX

1000V

750V

LOGIC

15XP-B

RANGE NON

CONTACT

VOLTAGE

HOLD

5XP-A

MIN MAX NON

CONTACT

VOLTAGE

HOLD

1000750 200200

2020

200

20k

200k

20M

200m

20m

200 A

auto-off

OFF

200

20m

1.5V 9V

200

BATT

35XP-A

15XP-A5XP-A

2A MAX

FUSED

CAT 600V

CAT 1000V

CAT 300V

COM A

MAX

1000V

750V

HzTemp

400

1000

RANGE NON

CONTACT

VOLTAGE

HOLD

auto-off

°C

OFF

°F

1832 400

35XP-A

SAFETY INFORMATION

• The XP Series Digital Multimeters conform to

EN610101,Rev-2; CAT I 1000 V,CAT II 600 V, CAT III 300

V(5XP-A,35XP-A), CAT II 1000 V, CAT III 600 V(15XP-B), class

2 and pollution deg.2; CSA 22.2 -1010-1.

• This instrument is EN61010-1 certied for Installation

Category I (1000V). It may only be used to make

measurements on energy limited circuits within

equipment and not directly connected to mains.

• This instrument is EN61010-1 certied for Installation

Category II (600 V). It is recommended for use with local

level power distribution, appliances, portable equipment,

etc, where only smaller transient overvoltages may occur,

and not for primary supply lines, overhead lines and cable

systems.

• This instrument is EN61010-1 certied for Installation

Category III ( 300 V). It is recommended for use in

distribution level and ﬁxed installations, as well as lesser

installations, and not for primary supply lines, overhead

lines and cable systems.

• Do not exceed the maximum overload limits per function

(see speciﬁcations) nor the limits marked on the instrument

itself. Never apply more than 1000 V dc/750 V ac rms

between the test lead and earth ground.

• Inspect the DMM, test leads and accessories before every

use. Do not use any damaged part.

•Never ground yourself when taking measurements. Do not

touch exposed circuit elements or test probe tips.

• Do not operate the instrument in an explosive atmosphere.

• Exercise extreme caution when: measuring voltage >20 V

// current >10 mA // AC power line with inductive loads //

AC power line during electrical storms // current, when the

fuse blows in a circuit with open circuit voltage >1000 V //

servicing CRT equipment.

• Always measure current in series with the load – NEVER

ACROSS a voltage source. Check fuse ﬁrst. Never replace a

fuse with one of a different rating.

• Remove test leads before opening the case.

SYMBOLS USED IN THIS MANUAL

Battery �Refer to the manual

Double insulated Dangerous Voltage

Direct Current Earth Ground

Alternating Current Audible tone

IFuse Canadian Standards

Association

PComplies with EU

directives Non-contact Voltage

MAKING MEASUREMENTS

Verify Instrument Operation

Before attempting to make a measurement, verify that

the instrument is operational and the battery is good. If

the instrument is not operational, have it repaired before

attempting to make a measurement.

Range Selection

In addition to autoranging (Models 15XP-B and 35XP-A only)

you can manually select and lock a range by pressing the

RANGE button. RANGE appears on the display to indicate

that manual ranging is active and the range is locked. When

appropriate, each subsequent press of the range button

steps the meter to the next higher range. When the highest

range is reached the next press returns the meter to the

lowest range. To return to autoranging press the RANGE

button. If RANGE still shows on the display, autoranging is

not available for the selected function.Use autorange for

all initial measurements. Then, when appropriate, use the

RANGE button to select and lock a range.

�Warning

To avoid electrical shock while manual ranging, use

the display annunciators to identify the actual range

selected.

Correcting an Overload (0o or -0o)

Indication�

An 0o or -0o indication may appear on the display to indicate

that an overload condition exists. For voltage and current

measurements, an overload should be immediately corrected

by selecting a higher range. If the highest range setting does

not eliminate the overload, interrupt the measurement until

the problem is identiﬁed and eliminated. The 0o indication

is normal for some functions; for example,resistance,

continuity, and diode test.

Measuring DC Voltage (See Figure 1)

1. Set the Function Switch to .

2. Select the desired RANGE. The default DC voltage

range is 2 V on the 15XP-B and 4 V on the 35XP-A.

3. Connect the test leads: Red to V , Black to COM.

4. Connect the test probes to the circuit test points.

5. Read the display, and, if necessary, correct any

overload (0o) conditions.

Measuring DC Voltage (See Figure 2)

1. Set the Function Switch to .

2. Select the desired RANGE. The default AC voltage

range is 2 V on the 15XP-B and 4 V on the 35XP-A.

3. Connect the test leads: Red to V , Black to COM.

4. Connect the test probes to the circuit test points.

5. Read the display, and, if necessary, correct any

overload (0o) conditions.

Preparing for Current Measurements

• Turn off circuit power before connecting the test probes.

• Allow the meter to cool between measurements, if current

measurements approach or exceeds 2 amps.

• A warning tone sounds if you connect a test lead to a

current input while a current function is not selected.

• Open circuit voltage at the measurement point must not

exceed 1000V.

• Always measure current in series with the load. Never

measure current across a voltage source.

Measuring DC Current (See Figure 3)

1. Set the Function Switch to a current function, μA, mA,

or A.

2. Select the desired RANGE (5XP-A only).

3. Connect the test leads: Red to mA or A, Black to COM.

4. Turn off power to the circuit being measured.

5. Open the test circuit (X) to establish

measurement points.

6. Connect the test probes in series with the load (to the

measurement points).

7. Turn on power to the circuit being measured.

8. Read the display, and, if necessary, correct any

overload (0o or -0o) conditions.

Measuring AC Current (See Figure 4)

1. Set the Function Switch to a current function and

range, μA, mA, or A.

2. Select the desired RANGE (5XP-A only).

3. Connect the test leads: Red to mA or A, Black to COM.

4. Turn off power to the circuit being measured.

5. Open the test circuit (X) to establish

measurement points.

6. Connect the test probes in series with the load (to the

measurement points).

7. Turn on power to the circuit being measured.

8. Read the display, and, if necessary, correct any

overload (0o) conditions.

Measuring Resistance (See Figure 5)

1. Set the Function Switch to .

2. Select the desired RANGE (5XP-A, 15XP-B).

3. Connect the test leads: Red toV , Black to COM.

4. Turn off power to the circuit being measured. Never

measure resistance across

a voltage source or on a powered circuit.

5. Discharge any capacitors that may inﬂuence the

reading.

6. Connect the test probes across the resistance.

Autres manuels pour 5XP-A

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Amprobe Multimètre

Amprobe

Amprobe Hexagon 60 Manuel utilisateur

Amprobe

Amprobe AC75B Manuel utilisateur

Amprobe

Amprobe 33XR-A Manuel utilisateur

Amprobe

Amprobe AM-140-A Manuel utilisateur

Amprobe

Amprobe AC71B Manuel utilisateur

Amprobe

Amprobe ACD-11 Manuel utilisateur

Amprobe

Amprobe ACDC-400 Manuel utilisateur

Amprobe

Amprobe AM50 Manuel utilisateur

Amprobe

Amprobe AM555 Manuel utilisateur

Amprobe

Amprobe ACD-6 Pro Manuel utilisateur

Amprobe

Amprobe ACD-10 TRMS-PLUS Manuel utilisateur

Amprobe

Amprobe AM-540 Manuel utilisateur

Amprobe

Amprobe 30XR-A Manuel utilisateur

Amprobe

Amprobe ac68C Manuel utilisateur

Amprobe

Amprobe AM-1E Manuel utilisateur

Amprobe

Amprobe 34XR-A Manuel utilisateur

Amprobe

Amprobe DM78B Manuel utilisateur

Amprobe

Amprobe ACD-14-PRO Manuel utilisateur

Amprobe

Amprobe AM535 Manuel utilisateur

Amprobe

Amprobe 37XR-A Manuel utilisateur

Amprobe

Amprobe 34XR-A Manuel utilisateur

Amprobe

Amprobe AM-100 Manuel utilisateur

Amprobe

Amprobe 38XR-A Manuel utilisateur

Amprobe

Amprobe PMM-2 Manuel utilisateur

Manuels Multimètre populaires d'autres marques

Agilent Technologies

Agilent Technologies 34420A Manuel utilisateur

Fluke

Fluke 83 Manuel utilisateur

Hameg

Hameg HM 8012 Manuel utilisateur

Mastech

Mastech MY70 Manuel utilisateur

Steren

Steren MUL-300 Manuel utilisateur

Somogyi Elektronic

Somogyi Elektronic home SMA 92 Manuel utilisateur

Gossen MetraWatt

Gossen MetraWatt METRAmax 6 Manuel utilisateur

PeakTech

PeakTech 4000 Manuel d'utilisation et d'entretien

YOKOGAWA

YOKOGAWA 90050B Manuel utilisateur

Gossen MetraWatt

Gossen MetraWatt METRALINE DMM16 Manuel utilisateur

Fluke

Fluke 8846A Manuel d'utilisation et d'entretien

Tempo Communications

Tempo Communications MM200 Manuel utilisateur

Elenco Electronics

Elenco Electronics CM-1555 Manuel utilisateur

Mastech

Mastech MS8238C Manuel utilisateur

SDAR

SDAR 830A, 830B, 830D, 830C Manuel utilisateur

RS PRO

RS PRO RS-9519BT Manuel utilisateur

BGS technic

BGS technic 8890 Manuel utilisateur

Morris

Morris 57074 Manuel utilisateur
