LAN-1
Lan Cable Tester
Users Manual
LAN1_Rev001
© 2008 Amprobe Test Tools.
All rights reserved.
3
➊RJ45 jack for sourcing end
(OUT).
➋RJ45 jack for receiving end (IN).
➌
LED indicators for sourcing end
(OUT) Green.
➍LED indicators for receiving end
(IN). Red.
➎AUTO scan button.
➏TEST button for MANUal test.
➐POWER ON/OFF button.
➑BATTery TEST button.
➒HOLD button.
➓MANUal scan button.
Low BATTery indicator.
Remote Terminator LED
indicator for ground wire
Remote Terminator LED
indicators for data lines
Remote Terminator RJ45 jack
HOLD
MAN
AUTO
TEST
BATT
1
2
3
4
5
6
7
9
8
REMOTE
TERMINATOR
IN OUT
1 2 3 4 5 6 7 8 G
OUT
IN
1
2
3
4
5
6
7
8
GRD
10
12
14
13
11
4
LAN-1
Lan cable tester
CONTENTS
Symbols..................................................................................................................5
Unpacking and Inspection....................................................................................5
Introduction...........................................................................................................5
Operation ..............................................................................................................6
Loopback Test (cable with both ends in one location)..................................6
Remote Test (cable with both ends at different locations)...........................6
Hold ..................................................................................................................6
Test Examples ........................................................................................................7
Specifications.........................................................................................................7
Maintenance and Repair .....................................................................................8
Battery Replacement ............................................................................................8
5
SYMBOLS
Refer to the manual Do not dispose of this
product as unsorted
municipal waste.
Conforms to relevant
Australian standards. Complies with EU
directives
This equipment not
for connection to
public communications
networks, such as active
telephone systems.
Warning and Precautions
DO NOT use on live circuits. These voltage levels pose a potential shock•
hazard to the user.
To avoid electrical shock hazard, observe the proper safety precautions•
when working with voltages above 60 VDC or 30 VAC rms.
Never ground yourself when taking measurements.•
Do not operate the instrument in an explosive atmosphere.•
To reduce the risk of fire or electric shock, do not expose this product to•
rain or moisture.
UNPACKING AND INSPECTION
Your shipping carton should include:
1 LAN-1 Cable tester
1 Remote Terminator
1 9 volt battery
1 RJ45 to female BNC cable
1 RJ45 to male BNC cable
1 RJ45 to RJ45 cable
1 female BNC to female BNC connector
1 Users Manual
If any of the items are damaged or missing, return the complete package to
the place of purchase for an exchange.
INTRODUCTION
The LAN-1 Cable Tester is designed for testing opens, shorts and miswired
cable installations .
6
Testing capabilities are:
Test pin configuration for 10/100 base -T cable, 10 base-2 cable, RJ45•
modular cables, AT&T 258A cable, EIA / TIA 568A/568B cables and Token
Ring Cable etc.
Verify cable continuity, open, short or incorrectly wired.•
Test installed cable on wall plate or the patch panels by using the Remote•
Termination module.
Buzzer sound warning for error condition.•
OPERATION
Press1. button for power ON. If no cable is attached or cable is defective,
the buzzer will sound.
Press BATT to verify proper operating voltage. The BATT LED will not light2.
and LAN-1 will not operate correctly if battery is below 7 volts.
Green LEDs are the source indicators. Red LED’s are the test indicators.3.
Red LED’s ON indicate cable line continuity. Red LED’s OFF indicate open
cable lines.
Loopback Test (cable with both ends in one location)
Connect cable with RJ-45 terminations on both ends to IN and OUT test1.
sockets.
Press2. button for power ON. Press AUTO (default) or MAN button to
start scanning.
AUTO scanning will step through lines 1 to 8 and ground (if connected)3.
and repeats until stopped.
MAN scanning will go into manual mode and TEST will step through the4.
different lines.
Remote Test (cable with both ends at different locations)
Connect one cable end to OUT connector.1.
Connect REMOTE TERMINATOR to the other end of cable under test.2.
Press3. button for power ON. Press AUTO (default) or MAN button to
start scanning.
AUTO scanning will step through lines 1 to 8 and ground (if connected)4.
and repeat until stopped.
MAN scanning go into manual mode and TEST will step through the5.
different lines.
Line test results (Red LED’s) are shown on the Remote Terminator.6.
Hold
The HOLD button saves the displayed error condition and stops testing. Press
the HOLD button to return to normal operation.
7
TEST EXAMPLES
Continuity Green onooooooo
Pin 2 has continuity 1 2 3 4 5 6 7 8 G
Red onooooooo
Open Green onooooooo
Pin 2 is open 1 2 3 4 5 6 7 8 G
Red ooooooooo
Short Green onnoooooo
Pins 2 and 3 are shorted 1 2 3 4 5 6 7 8 G
Red onnoooooo
Miswire Green onooooooo
Pins 2 and 6 are miswired 1 2 3 4 5 6 7 8 G
Red ooooonooo
SPECIFICATIONS
General
Display: Red and Green LED’s
Battery: 9V, 006P or IEC 6F22 or NEDA 1604.
Low Battery Indicator: The LED indicator will not turn ON when
BATT button pushed
Battery Life: Approx 20 hours. (Alkaline battery)
Environment: Indoor operation, maximum altitude
- 2000 m (6561 ft.)
Temperature / Humidity:
Operation: 0 to 40°C (32 to 104°F), 10 to 70% RH.
Storage: -10 to 60°C (14 to 140°F), 10 to 90% RH.
Dimension: 130 x 64 x 38mm (5.1 x 2.2 x 1.5 in)
Weight: 1.26 kg (0.6 lb)
-EMC: EN61326-1 This product complies with requirements of the
following European Community Directives: 89/336/EEC (Electromagnetic
Compatibility) and 73/23/EEC (Low Voltage) as amended by 93/68/EEC (CE
Marking). However, electrical noise or intense electromagnetic fields in the
vicinity of the equipment may disturb the measurement circuit. Measuring
instruments will also respond to unwanted signals that may be present within
the measurement circuit. Users should exercise care and take appropriate
precautions to avoid misleading results when making measurements in the
presence of electronic interference.
Electrical
Maximum line length: ~300 meters
Connector types: RJ45, BNC
DO NOT use on live circuits.
MAINTENANCE AND REPAIR
If there appears to be a malfunction during the operation of the tester, the
following steps should be performed in order to isolate the cause of the
problem.
Press the BATTery button to check the battery. Replace the battery1.
immediately if the LED indicator will not turn ON.
Review the operating instructions for possible mistakes in operating2.
procedure.
Except for the replacement of the battery, repair of the meter should be
performed only by a Factory Authorized Service Center or by other qualified
instrument service personnel. The front panel and case can be cleaned with
a mild solution of detergent and water. Apply sparingly with a soft cloth and
allow to dry completely before using. Do not use aromatic hydrocarbons or
chlorinated solvents for cleaning.
BATTERY REPLACEMENT
1. Turn off the meter and slide out the battery cover. Replace the battery with
a NEDA type 1604 or equivalent 9V alkaline battery. Replace the cover.
2. Remove battery when the LAN-1 is not used for extended period.
OPEN
Battery Replacement
Back to the Amprobe LAN-1 LAN Tester
Visit us at www.TestEquipmentDepot.com
