AmpliVox S1204 Manuel utilisateur

AUDIO COMPANION WIRELESS POWERED SPEAKER

PORTABLE MULTI-MEDIA STEREO SPEAKER/AMPLIFIER

MODEL S1204

SET UP:

INSTALL POWER SUPPLY

The Battery pack is standard. Optional Power Supplies may be substituted. Model S1460, International

AC Adapter (110/220V, 50/60Hz). Model S1452, 12 Volt DC adapter (automotive cigarette lighter plug-

in). Model S1465, NiCad battery Pack.

TO INSTALL OR REPLACE BATTERIES

Loosen four thumbscrews and remove battery door from back of speaker. Remove battery holder from

amplifier. Insert 10 new Alkaline “D” cell batteries, observing polarity, or replace with S1465 NiCad

battery pack. Carefully replace battery holder. Reposition battery door and fasten four thumbscrews.

Do not mix battery types or attempt to recharge alkaline batteries - equipment damage, safety hazard or

fire could result. Remove batteries if the amplifier is not going to be used for extended periods of time

to prevent leakage.

TO OPERATE:

Turn amplifier on (large rocker switch located on the front of the amplifier). The red light will go on,

showing that power is available. The S1204 will operate only with a Kima wireless speaker transmitter

model S1670. Make sure that the S1670 Kima wireless speaker transmitter is turned on and a signal

source is plugged into its Audio input jack. Adjust the Kima transmitter volume control for maximum. A

temporary burst of noise is heard while the receiver built into the S1204 speaker acquires the desired

signal from the S1670. Rotate WIRELESS control or if using cabled Line input the VOLUME and

TONE control knobs to obtain desired loudness level throughout the coverage area.

NOTE: The frequencies used by the S1204 and the Kima wireless speaker transmitter model

S1670 are not on clear channels and may be used by other devices. If the unit receives

interference, turn the Wireless control completely down, and a cable must be used from the

signal source to the S1204 Line input.

ON-OFF

When power switch is in the ON position, the red light will be on.

DC IN

Connection for optional power adapter:

•S1460 International AC Adapter/Recharger (110/220V, 50/60Hz)

•S1452 12 Volt DC (automotive cigarette lighter) Adapter

AUXILIARY

To add pre-recorded music or sound effects during your presentation, just plug your CD player, tape

player or computer sound card into the LINE IN jack. Separate VOLUME and TONE control knobs let

you balance the program source with the live microphones.

LINE OUTPUT

To tape record your speech or program, connect the LINE OUT on the amplifier (using cable with

standard 3.5mm plug) to the input on a tape recorder. Additional S1202 powered companion speakers

may also be connected to the LINE OUT jack.

INTERNAL SPEAKERS

The internal speakers are wired for stereo, LEFT and RIGHT channel information is reproduced by the

appropriate speaker inside the unit.

EXTERNAL SPEAKERS

Two separately amplified speaker jacks allow you to use one or two S1201 speakers for additional sound

power.

PROBLEM SOLVING

Feedback is the howl or screech often heard in sound reinforcement systems. It is caused by sound from

the loudspeaker returning to the microphone. AmpliVox systems utilize proven acoustical principles to

minimize this; however, there is no way to completely eliminate feedback under conditions of high

amplification. If feedback occurs check the following:

1. User’s hand covering the head of the microphone. [Hold microphone under head slots.]

2. Sound can easily re-enter microphone. Keep loudspeaker turned toward audience. Note: sound can be

reflected from a hard surface back through the microphone. [Turn speaker.]

3. User holding microphone in a reflecting position. [Turn microphone.]

4. Volume setting too high at main unit. [Reduce microphone channel volume or if using Kima wireless

companion speaker option, that the transmit level is properly adjusted; compensate by speaking

louder or closer to the microphone.]

NO SOUND

Make sure amplifier POWER switch is turned on and red LED is lit. If switch is on and LED is not lit,

check to see that batteries are properly connected and at full charge. If using optional power adapter,

check to see that front panel connector is properly seated, and verify that the power source is live. If

using the Kima wireless speaker transmitter model S1670, make sure a signal source (CD player, cassette,

MP3 player, line output from another sound system, etc.) is plugged into the AUDIO IN jack, and that

the transmitter is turned on, the volume turned to maximum and has 4 fresh “AAA” Alkaline batteries

installed or the external power transformer is plugged in and working.

NOTE: There will be a short noise burst from the S1204 speaker every time the S1670 Kima

wireless transmitter is turned on or off. This is a normal function of the built in receiver acquiring the

desired signal. To avoid undesirable operation it is recommended that the Kima transmitter be turned on

first before the S1204, and that the S1204 be turned off first before the Kima transmitter to avoid

unwanted loud noise bursts. If for any reason the Kima transmitter frequency is changed from position

‘A’ as shipped from the factory, the S1204 must be turned off and then back on for the receiver to acquire

the proper signal.

IF YOU HAVE ANY QUESTIONS OR PROBLEMS PLEASE CALL OUR CUSTOMER

SERVICE DEPARTMENT AT 1-800-267-5486
