Amped Wireless AP1200EX Manuel utilisateur

User’s GuideUser’s Guide

AP1200EX

HIGH POWERTM AC1200

PRO WI-FI®ACCESS POINT

CONTENTS

INTRODUCTION .................................................. 2

GETTING STARTED .............................................. 3

MOUNTING INSTRUCTIONS ................................ 7

PLUG AND PLAY SETUP GUIDE ........................ 10

ADDITIONAL SETTINGS ..................................... 12

5GHz WI-FI SETTINGS ........................................ 21

Basic Settings (5.0GHz) ........................................ 21

Guest Networks (5.0GHz) .................................... 23

Advanced Settings (5.0GHz) ................................ 24

Wireless Coverage Controls (5.0GHz).................. 25

Access Schedule (5.0GHz).................................... 25

Wi-Fi Protected Setup –WPS (5.0GHz)................ 27

2.4GHz WI-FI SETTINGS ..................................... 28

Basic Settings (2.4GHz) ........................................ 28

Guest Networks (2.4GHz) .................................... 30

Advanced Settings (2.4GHz) ................................ 31

Airtime Allocation (2.4GHz) ................................. 32

Wireless Coverage Controls (2.4GHz).................. 33

Access Schedule (2.4GHz) ....................................34

Wi-Fi Protected Setup –WPS (2.4GHz)................35

WDS SETTINGS...................................................36

WDS Settings........................................................36

ANTENNA SETTINGS ..........................................38

Antenna Settings..................................................38

NETWORK SETTINGS..........................................39

MANAGEMENT FEATURES .................................40

Management: System Clock ................................41

Management: System Logs..................................42

Management: Upgrade Firmware........................43

Management: Save/Reload Settings....................45

Management: Password Settings ........................46

TECHNICAL SPECIFICATION ................................47

DEFAULT SETTINGS............................................48

TROUBLESHOOTING & SUPPORT INFO...............49

LEGAL NOTICES AND DISCLAIMERS ....................66

INTRODUCTION

Thank you for purchasing the High Power AC1200 Pro Wi-Fi Access Point. At Amped Wireless we strive to

provide you with the highest quality products through innovation and advanced technology. We pride

ourselves on delivering products that outperform the competition and go beyond your expectations. If you

have any questions, please feel free to contact us. We’d love to hear from you and thank you for your

support!

Email: [email protected]

Call: 888-573-8820

Web: www.ampedwireless.com

GETTING STARTED

Package Contents

Check to make sure you have all the contents within your package:

High Power AC1200 Pro Wi-Fi Access Point

30 ft Power over Ethernet Cable

Power over Ethernet Adapter

Standard Ethernet Cable

Power Cable

Metal Desktop Stand

Metal Pole Mounting Clamp

Plastic Pole Mounting Tie

Setup Guide

LED Indicators

a) Power: When lit, the power is on.

c) POE: Shows the connection status of the

Network port on the PoE Adapter

e) LAN: Shows the connection status and data

activity of your local network (network

devices connected to the Pro Access Point).

f) 2.4GHz Wireless Activity: Blinks rapidly when 2.4GHz wireless data traffic is passing through the Pro

Access Point.

h) 5.0GHz Wireless Activity: Blinks rapidly when 5.0GHz wireless data traffic is passing through the Pro

Access Point.

External Antenna: When lit, the external antenna port is active,and the internal antenna is bypassed.

Inside Panel

a) Optional External Antenna Port: RJ-SMA antenna

connector. Compatible with all antennas with RP-SMA

connectors. Upgradable to high gain antennas for more

range. See the External Antenna configuration section for

setup procedures.

b) PoE Port: Power over Ethernet capable RJ-45 port used

to connect the Pro Access Point to the included PoE

Adapter for power and data connectivity.

c) LAN Port: RJ-45 port used to connect additional network

devices to the Pro Access Point.

d) Reset Button: Hold down the reset button for over 5 seconds to reset the Pro Access Point to default

settings.

Power over Ethernet (PoE) Adapter

a) Power Adapter Port: Connect the included power adapter to

the PoE adapter port for powering the Pro Access Point.

b) AP Port: Connect a PoE cable between the PoE Adapter’s AP

port and the PoE port on the Pro Access Point to provide power

and data to the Pro Access Point.

c) Network Port: Connects to an available port on a network

switch or router’s LAN port.

d) Power: Power cable port is located on the back of the adapter

MOUNTING INSTRUCTIONS

Desktop Mounting (Indoor)

a) Place the stand in an optimum location.

b) Secure the AP1200EX onto the desktop mount

by sliding it down onto the L shaped desktop

mount.

c) Position the cables so that they are neatly

tucked and not obstructing the stand

Wall Mounting

a) Place the AP1200EX against the wall, use a

pencil and mark two locations through the

mounting holeson the wall.

b) Remove the AP1200EX and securely drill two

screws where you’ve marked on the wall.

Leave some space between the screw head

and the wall so the AP1200EX can be slide

mounted onto the screws.

c) Mount the AP1200EX onto the secured screws

and adjust the screws if needed to secure the

Access Point to the wall.

Pole Mounting

a) Place the AP1200EX against the pole.

b) Use the included hose clamp or plastic tie and

secure it through the smaller hole located on

the bottom of the mounting bracket. Use a

screw driver to tighten the clamp until the

adapter is securely mounted to the pole.
