Amica FK328.3F Manuel utilisateur

FK328.3F

FK328.3FX

FK338.6GWF

FK338.6GBF

EN INSTRUCTION MANUAL

14 15

15 16

CHANGING THE DIRECTION OF THE DOOR OPENING

1. Unplug the appliance.

2. Remove the bottom rail, gently pulling it towards you (item 1).

3. RemovethecapsCusingaatscrewdriver

4. Holding the refrigerator door, remove the hinge assembly (item 6), remove the door by lifting them

up parallel to the appliance body. Remove the pin from the upper hinge and screw it on the other

side of the hinge (item 6).

5. Remove the pin pads located in the refrigerator door lower strip (item 5). Remove the cap from the

middle hinge pin hole it the upper strip of the freezer door (item 9).

6. Remove the caps from the mounting holes for the middle hinge (item 8).

7. Holding the freezer door (item 3), remove the middle hinge (item 4), remove the door by lifting it up

parallel to the appliance body.

8. Unscrew the bottom hinge (item 7), remove the pin and insert it into the opposite hole (item 2).

Remove the bottom rail handle located on the other side of the refrigerator body.

9. Attach the lower hinge on the other side of the appliance body. Position the freezer door in such a

way so that the lower hinge pin is aligned with the appropriate hole in the door.

10. The remaining door installation steps should be performed analogically to the above.

12. Check the door position towards the body of the appliance. If the door is in the correct position, use

the caps to cover the holes in the body and doors and install the lower cover.

13. Remove the door handles and attach them on the other side of the refrigerator and freezer door. To

remove the handle, remove the screw caps (item A) and remove the screws. Move the handle to

the side (in the direction of the previous handle position) and gently pull it forward. Install the handle

analogically to its removal.

Remember about the pads located on the hinge pins. Reuse them when changing the direction of

opening the door.

The installation kit does not include a screwdriver or wrench.

Changing the direction of the door opening should by carried out by two persons.

Your appliance is exceptionally easy to use and extremely efcient. Before being packaged

and leaving the manufacturer, the appliance was thoroughly checked with regard to safety and

functionality.

Before using the appliance, please carefully read these Operating Instructions

DEAR CUSTOMER!

THANK YOU FOR PURCHASING AN AMICA APPLIANCE

The appliance is intended for household

use only.

The manufacturer reserves the right to

introduce changes which do not affect the

operation of the appliance.

Figures in this user manual are for illustra-

tivepurposesonly.Fullappliancettings

are listed in a relevant section.

CHANGING THE DIRECTION OF THE DOOR OPENING

GUIDELINES CONCERNING THE SAFETY OF USE

INSTALLATION AND OPERATING CONDITIONS OF THE APPLIANCE

OPERATION AND FUNCTIONS

USING THE REFRIGERATOR EFFICIENTLY

DEFROSTING, WASHING AND MAINTENANCE

TROUBLE-SHOOTING

ENVIRONMENTAL PROTECTION

CLIMATE RANGE

WARRANTY AND AFTER-SALE SERVICES

ITEMS OF EQUIPMENT

GUIDELINES CONCERNING THE SAFETY OF USE

Someprovisionsinthisusermanualareuniedforre-

frigerating products of different types (for a refrigerator,

refrigerator-freezer or freezer)

The Manufacturer shall not be held liable for damage

arising from the failure to observe the instructions con-

tained in this manual.

Keep this manual for future reference, or to pass it over

to the next user.

This appliance is not intended for use by persons (inc-

luding children) with limited physical or mental capabili-

ties and persons who lack experience or familiarity with

the appliance.

Do not allow una tte nde d children to use the applian-

ce. Do not allow them to play with the appliance. They

must not climb inside the drawers and swing on the do-

ors.

The appliance operates properly at the ambient tem-

perature(seeproductche).Donotuseitinthecellar,

unheated summer cottage during autumn and winter.

When placing, moving, lifting the appliance, do not hold

the door han- dles, do not pull the condenser at the rear

part of the refrigerator and do not touch the compressor

unit.

When transporting, moving or positioning the fridge-

-freezer do not tilt it by more than 40° from the vertical

position. Should such a situation occur, the appliance

should be switched on after minimum 2 hours from its

re-placementintherightposition(g.2).

Pull the plug out from the mains socket before each ma-

intenance activity. Do not pull on the cord, but hold the

body of the plug instead.

The “cracking” sound, which the appliance may emit is

caused by the expansion and contraction of parts as a

result of temperature variations.

For safety reasons do not repair the appliance yourself.

Repairs car- ried out by persons who do not have the

requiredqualicationsmayresultinseriousdangerfor

the user of the appliance.

GUIDELINES CONCERNING THE SAFETY OF USE

Air the room in which the appliance is placed for a few

minutes (the size of the room for a product containing

isobuthane/R600a must be at least 4m3) to avoid da-

mage to the cooling system.

Do not refreeze partly thawed products.

Do not store beverages in bottles and cans, especially

carbonated be- verages, in the freezer chamber. The

cans and the bottles may explode.

Do not put frozen products, taken out directly from the

freezer (lollies, ice cubes, etc.) into your mouth, their

low temperature may cause severe frost-bite.

Make sure you do not damage the cooling system, by

puncturing the refrigerant pipes in the evaporator or

breaking the pipes. The refrige- rant  is ammable. If

the refrigerant makes contact with the eyes, rinse them

with clean water and call for medical assistance imme-

diately.

If the power wire gets broken, it should be replaced with

a new one in a specialist repair shop.

This appliance is intended for food storage, do not use

it for other purposes.

When performing activities, such as cleaning, mainte-

nance or moving, the appliance must be completely di-

sconnected from power supply (by pulling the plug out

from the socket)

This appliance can be used by children aged 8 years

and older or by persons with physical, mental or sen-

sory handicaps, or by those who are inexperienced or

unfamiliar with the appliance, provided they are super-

vised or have been instructed how to safely use the ap-

pliance and are familiar with risks associated with the

use of the appliance. Ensure that children do not play

with the appliance. Cleaning and maintenance of the

appliance should not be performed by children unless

they are 8 years or older and are supervised by a com-

petent person.
