Amica FC1534 Manuel utilisateur

Refrigerator

FC1534

IO-REF-0487/2

(07.2020)

OPERATING INSTRUCTIONS EN

- 2 -

EN- Table of contents

GUIDELINES CONCERNING THE SAFETY OF USE 4

INSTALLATION AND OPERATING CONDITIONS OF THE APPLIANCE 9

INSTALLATION BEFORE USING THE APPLIANCE FOR THE FIRST TIME 9

MINIMUM DISTANCES FROM THE HEAT SOURCES 9

MAINS CONNECTION 10

DISCONNECTING THE MAINS 10

CLIMATE RANGE 10

UNPACKING 11

DISPOSAL OF OLD APPLIANCE 12

CONTROLS 13

APPLIANCE CONTROLS 13

ADJUST TEMPERATURE INSIDE THE APPLIANCE 13

ADDITIONAL INFORMATION ON THE TEMPERATURE 14

LIGHTING 14

REPLACE THE LIGHT BULB 14

OPERATION AND FUNCTIONS 15

STORAGE OF FOOD IN THE FRIDGE-FREEZER 15

FREEZING FOOD** 15

USING THE REFRIGERATOR EFFICIENTLY 17

PRACTICAL EVERYDAY TIPS 17

UNDERSTANDING THE STARS 17

PRACTICAL TIPS 18

FOOD THAT SHOULD NOT BE STORED IN A REFRIGERATOR 18

DEFROSTING, WASHING AND MAINTENANCE 19

DEFROSTING THE FRIDGE*** 19

DEFROSTING THE FREEZER** 19

DEFROST THE FREEZER CHAMBER FOLLOWING STEPS:** 20

AUTOMATIC FRIDGE DEFROSTING**** 20

WASHING THE FRIDGE AND FREEZER CHAMBERS MANUALLY**** 20

TAKING OUT AND PUTTING IN THE SHELVES***** 20

TAKING OUT AND PUTTING IN THE DOOR SHELF***** 20

TROUBLE-SHOOTING 21

WARRANTY AND AFTER SALES SERVICE 23

WARRANTY 23

- 3 -

Dear customer,

From now on, your daily housework will be easier

than ever before. Your appliance is excepon-

ally easy to use and extremely ecient. Aer reading

these Operang Instrucons, operang the appliance

will be easy.

Before being packaged and leaving the manufacturer,

the appliance was thoroughly checked with regard to

safety and funconality.

Before using the appliance, please carefully read

these Operang Instrucons. By following these

instrucons carefully you will be able to avoid any

problems in using the appliance. It is important to

keep these Operang Instrucons and store them in a

safe place so that they can be consulted at any me.

Follow these instrucons carefully in order to avoid

possible accidents.

Sincerely,

- 4 -

GUIDELINES CONCERNING

THE SAFETY OF USE

• The appliance is intended for household use only.

• The manufacturer reserves the right to introduce

changes which do not aect the operation of the

appliance.

• Some provisions in this user manual are unied

for refrigerating products of dierent types (for a

refrigerator, refrigerator-freezer or freezer)

• The Manufacturer shall not be held liable for

damage arising from the failure to observe the

instructions contained in this manual.

• Keep this manual for future reference, or to pass

it over to the next user.

• This appliance is not intended for use by persons

(including children) with limited physical or men-

tal capabilities and persons who lack experience

or familiarity with the appliance.

• Do not allow children to use the appliance. Do

not allow them to play with the appliance. They

must not climb inside the drawers and swing on

the doors.

• The appliance operates properly at the ambient

temperature (see product che). Do not use it in

the cellar, unheated summer cottage during au-

tumn and winter.

• When placing, moving, lifting the appliance, do

not hold the door handles, do not pull the con-

denser at the rear part of the refrigerator and do

not touch the compressor unit.

• When transporting, moving or positioning the

fridge-freezer do not tilt it by more than 40°

from the vertical position. Should such a situa-

tion occur, the appliance should be switched on

after minimum 2 hours from its replacement in

the right position (g.2).

- 5 -

• Pull the plug out from the mains socket before

each maintenance activity. Do not pull on the

cord, but hold the body of the plug instead.

• The “cracking” sound, which the appliance may

emit is caused by the expansion and contraction

of parts as a result of temperature variations.

• For safety reasons do not repair the appliance

yourself. Repairs carried out by persons who do

not have the required qualications may result in

serious danger for the user of the appliance.

• Air the room in which the appliance is placed for

a few minutes (the size of the room for a product

containing isobuthane/R600a must be at least

4m3) to avoid damage to the cooling system.

• Do not refreeze partly thawed products.

• Do not store beverages in bottles and cans, espe-

cially carbonated beverages, in the freezer cham-

ber. The cans and the bottles may explode.

• Do not put frozen products, taken out directly

from the freezer (lollies, ice cubes, etc.) into your

mouth, their low temperature may cause severe

frostbite.

• Make sure you do not damage the cooling sys-

tem, by puncturing the refrigerant pipes in the

evaporator or breaking the pipes. The refrigerant

is ammable. If the refrigerant makes contact

with the eyes, rinse them with clean water and

call for medical assistance immediately.

• If the power wire gets broken, it should be re-

placed with a new one in a specialist repair shop.

• This appliance is intended for food storage, do

not use it for other purposes.

• When performing activities, such as cleaning,

maintenance or moving, the appliance must be

completely disconnected from power supply (by

pulling the plug out from the socket)

• This appliance can be used by children aged 8

years and older or by persons with physical, men-

- 6 -

tal or sensory handicaps, or by those who are

inexperienced or unfamiliar with the appliance,

provided they are supervised or have been in-

structed how to safely use the appliance and are

familiar with risks associated with the use of the

appliance. Ensure that children do not play with

the appliance. Cleaning and maintenance of the

appliance should not be performed by children

unless they are 8 years or older and are super-

vised by a competent person.

• In order to obtain more space in the freezer, you

can remove the drawers and place the food di-

rectly on the shelves. This has no eect on the

product mechanical properties and cooling per-

formance. Declared freezer capacity was calcu-

lated with the drawers removed.

WARNING: Risk of re / ammable

materials

• Children aged from 3 to 8 years are allowed to

load and unload refrigerating appliances.

To avoid contamination of food, please respect the

following instructions:

• Opening the door for long periods can cause a

signicant increase of the temperature in the

compartments of the appliance.

• Clean regularly surfaces that can come in contact

with food and accessible drainage systems.

• Store raw meat and sh in suitable containers in

the refrigerator, so that it is not in contact with or

drip onto other food.

• Two-star frozen-food compartments are suitable

for storing pre-frozen food, storing or making ice-

cream and making ice cubes.

• One-, two- and three-star compartments are not

suitable for the freezing of fresh food

- 7 -

Compartments

TYPE

Target storage

temp.[OC] Appropriate food

1 Fridge +2≤+8

Eggs, cooked food, packaged food, fruits and

vegetables, dairy products, cakes, drinks and

other foods are not suitable for freezing.

2Freezer

≤-18

Seafood (sh, shrimp, shellsh), freshwater

aquatic products and meat products

(recommended for 3 months, the longer the

storage time, the worse the taste and nutrition),

suitable for frozen fresh food.

3Freezer

≤-18

Seafood (sh, shrimp, shellsh), freshwater

aquatic products and meat products

(recommended for 3 months, the longer the

storage time, the worse the taste and nutrition),

are not suitable for frozen fresh food.

4Freezer

≤-12

Seafood (sh, shrimp, shellsh), freshwater

aquatic products and meat products

(recommended for 2 months, the longer the

storage time, the worse the taste and nutrition),

are not suitable for frozen fresh food

5Freezer

≤-6

Seafood (sh, shrimp, shellsh), freshwater

aquatic products and meat products

(recommended for 1 months, the longer the

storage time, the worse the taste and nutrition),

are not suitable for frozen fresh food.

60- star

compartment -6≤0

Fresh pork, beef, sh, chicken, some packaged

processed foods, etc. (Recommended to eat

within the same day, preferably no more than

3 days). Partially encapsulated processed foods

(non-freezable foods)

7 Chill 2≤+3

Fresh/frozen pork, beef, chicken, freshwater

aquatic products, etc.(7 days below 0OC and above

0OC is recommended for consumption within that

day, preferably no more than 2 days). Seafood

(less than 0 for 15 days, it is not recommended to

store above 0OC)

8 Fresh Food 0≤+4

Fresh pork, beef, sh, chicken, cooked food,

etc. (Recommended to eat within the same day,

preferably no more than 3 days)

9 Wine +5≤+20 red wine,white wine,sparkling wine etc.

• Note: please store dierent foods according to

the compartments or target storage temperature

of your purchased products.

- 8 -

• If the refrigerating appliance is left empty for long

periods, switch o, defrost, clean, dry, and leave

the door open to prevent mould developing with-

in the appliance.

• Water dispenser cleaning (special for water dis-

penser products): Clean water tanks if they have

not been used for 48 h; ush the water system

connected to a water supply if water has not been

drawn for 5 days.

• Pursuant to Commission Regulation (EU)

2019/2019, the minimum availability period for

spare parts necessary to repair the appliance is 7

or 10 years depending on the type and purpose

of the spare part.

• The list of spare parts and the ordering procedure

are available on the websites of the manufactur-

er, importer or an authorized representative.

• For more information about the product, please

refer to the EU EPREL Product Database at https://

eprel.ec.europa.eu. For more information, please

use your mobile device to scan the QR code on

the energy label or enter the product model listed

on the energy label in the EPREL search engine

https://eprel.ec.europa.eu/

- 9 -

INSTALLATION AND OPER-

ATING CONDITIONS OF THE

APPLIANCE

This refrigeration appliance is not intended for use as a built-in appliance.

Installation before using the appliance for the rst time

• Take the product out of the package, remove the scotch tape protect-

ing the door and the equipment. Any remaining adhesive stains may

be removed with a mild washing agent.

• Do not throw away the polystyrene elements of the packaging. If it is

necessary to transport the fridge-freezer, pack it in the polystyrene

elements and lm as well as protect ing it with scotch tape

• Clean the interior surface of the fridge- freezer and the elements of

the equipment with a washing agent dissolved in lukewarm water,

then wipe it dry.

• Place the fridge-freezer on an even, at and stable surface, in dry,

aired and shaded room, far from the heat sources such as: oven,

hob, central heating radiators, central heating pipes, hot water in-

stallation, etc.

• On the exterior surface of the product may be a protective foil, this

foils should be removed.

• Make sure the appliance is placed in a horizontal position by screwing

in the 2 adjustable front legs (g. 3)

• To ensure that the door opens freely, the distance between the side

of the appliance (on door hinges side) and the wall is shown on gure

5.*

• Ensure adequate ventilation of the room and free air circulation from

all sides of the appliance (g. 6).*

Minimum distances from the heat sources

• from the electric gas and other ovens - 30 mm,

• from oil or coal red ovens - 300 mm,

• from built-in ovens - 50 mm

If there is no possibility of ensuring the above- mentioned distances,

provide an appropriate insulation board.

Warning:

• The rear wall of the refrigerator, in particular, the condenser and oth-

er elements of the cooling system must not contact other elements,

which may damage them, (e.g. central heating pipes and the water

supply pipes).

• It is forbidden to readjust or modify any parts of the unit. It is crucial

not to damage the capillary tube visible in the compressor recess.

The tube may not be bent, straightened or wound.

• If the capillary tube is damaged by the user the guarantee will be

void (g. 8).

• In some models the handle is put into the appliance, You should

screw it with Your own screwdriver,

- 10 -

Mains connection

• Prior to connection, it is recommended to set the temperature control

knob to an „OFF” or other position that disconnects the appliance

from the power supply (See page with the control description).

• This appliance should be connected to AC 220-240V 50Hz supply

socket. The socket must be tted properly, and must be supplied with

an earthing conduit and a 10A fuse.

• It is a legal requirement that the appliance is properly earthed. The

manufacturer will not be held liable for any damage or injury which

may result from the failure to full this requirement.

• Do not use adapters, multiple sockets and two-wire extension leads.

If it is necessary to use the extension lead, it must be equipped with

a protection ring and a single socket and must have a VDE/GS safety

certicate.

• If an extension lead is used (with a protection ring and safety certif-

icate), its socket must be located at a safe distance, away from the

sinks, and must not be in a place where it could be ooded by water

or waste water.

• See the type plate at the lower part of the internal wall of the appli-

ance for detailed specications**.

Disconnecting the mains

Make sure the appliance can be easily disconnected from the mains,

either by pulling the plug out of the mains socket, or by switching the

two-pole switch o (g. 9).

Climate range

The information about the climate range of the appliance is provided

on the rated plate. It indicates at which ambient temperature (that is,

room temperature, in which the appliance is working) the operation of

the appliance is optimal (proper).

Climate class Allowable ambient temperature

SN Extended Temperate

This refrigeration appliance is intended for use

at an ambient temperature ranging between

10°C and 32°C

N Temperate

This refrigeration appliance is intended for use

at an ambient temperature ranging between

16 °C and 32°C

ST Subtropical

This refrigeration appliance is intended for use

at an ambient temperature ranging between

16 °C and 38 °C

T Tropical

This refrigeration appliance is intended for use

at an ambient temperature ranging between

16 °C and 43 °C

* Only free-standing appliances

** According to the model

Table des matières

Autres manuels Amica Réfrigérateur

Amica

Amica EKGC16186 Manuel utilisateur

Amica

Amica EKSS 362 220 Manuel utilisateur

Amica

Amica VJ 852.4 AW Manuel utilisateur

Amica

Amica EKGC 16169 Manuel utilisateur

Amica

Amica BC2763/2 Manuel utilisateur

Amica

Amica VC 1613 AS Manuel utilisateur

Amica

Amica FK321.6GWDF Manuel utilisateur

Amica

Amica BK313.3 Manuel utilisateur

Amica

Amica FK345 3 AA Series Manuel utilisateur

Amica

Amica KGCL 387 115 E Manuel utilisateur

Amica

Amica FK350HSW? FK350HSX? FK320HSW? FK320HSX Manuel utilisateur

Amica

Amica AR7252W Manuel utilisateur

Amica

Amica KGCN 389 100 S Manuel utilisateur

Amica

Amica KGCN 387 110 S Manuel utilisateur

Amica

Amica AR1112R Manuel utilisateur

Amica

Amica VKS15780E Manuel utilisateur

Amica

Amica BK316.3FA Manuel utilisateur

Amica

Amica VKS15122W Manuel utilisateur

Amica

Amica FK265.3 AA Manuel utilisateur

Amica

Amica KGCR 387 100 Series Manuel utilisateur

Amica

Amica DT374010W Manuel utilisateur

Amica

Amica FD226.3AA Manuel utilisateur

Amica

Amica VKS15416W Manuel utilisateur

Amica

Amica EKGC 16155 Manuel utilisateur

Manuels Réfrigérateur populaires d'autres marques

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manuel utilisateur

Sharp

Sharp SJ-BA31IEXW2-EU Manuel utilisateur

CORBERO

CORBERO CC2300MCW Manuel utilisateur

KitchenAid

KitchenAid 2205264 Manuel utilisateur

Stengel

Stengel KU 1101 A++ Manuel utilisateur

NEFF

NEFF KI181 Series Manuel utilisateur

Hoshizaki

Hoshizaki Reach-In Manuel utilisateur

Amana

Amana ASD2524VES00 Manuel utilisateur

BOMANN

BOMANN KGC 213 Manuel utilisateur

Danby

Danby DAR044A1SLDD Instructions de montage

Samsung

Samsung RF323TE Manuel utilisateur

Beko

Beko CSA31022 Manuel utilisateur

IKEA

IKEA FROSTIG C 185 E Manuel utilisateur

Electrolux

Electrolux ER 6821 D Manuel utilisateur

True

True TS-28 Manuel utilisateur

Frigidaire

Frigidaire FSC23R5DW9 Manuel utilisateur

Beko

Beko LSP4579W Manuel utilisateur
