Amica AWC300 Guide de l'utilisateur
AWC150
AWC300
AWC600
Wine coolers
Use and maintenance
2
Contents:
3 Important
6 Before first use
7 Notes on use
8 Use and controls
8 Locking and unlocking the control panel
8 Switching the power on and o
9 Changing the temperature
9 Changing the temperature reading (°C/°F)
10 Optimal temperatures for dierent wines
10 Using the internal lighting
11 - 12 Temperature display (set and real)
13 Care and cleaning
13 Removing the shelves
14 Temperature alarm
14 Troubleshooting
16 Installaling the wine cooler
18 Installing the handle
18 Reversing the door
21 Fitting the plinth
23 Adjusting the plinth
24 Electrical information
26 Bottle storage
27 Climate range
3
Important
The CDA Group Ltd cannot be held responsible for injuries or losses
caused by incorrect use or installation of this product. Please note
that The CDA Group reserve the right to invalidate the guarantee
supplied with this product following incorrect installation or misuse of
the appliance or use in a commercial environment.
This appliance is not designed to be used by people (including
children) with reduced physical, sensorial or mental capacity, or
who lack experience or knowledge about it, unless they have had
supervision or instructions on how to use the appliance by someone
who is responsible for their safety.
Under no circumstances should any external covers be removed for
servicing or maintenance except by suitably qualified personnel.
Do not use the appliance if the plug, the mains cord or the appliance
itself is damaged. If the mains cord is damaged, you must have it
replaced by the manufacturer, or an authorised service centre or
similarly qualified persons in order to avoid a hazard.
Children should be supervised to ensure that they do not play with
the appliance. Keep the mains cord out of the reach of children. Do
not let the mains cord hang over the edge of the table or worktop on
which the appliance stands.
This refrigeration appliance is not intended for use as a built-in
appliance.
4
•Repairs carried out by unqualified persons may seriously
endanger the appliance user
•Pursuant to Commission Regulation (EU) 2019/2019, The
minimum availability period for spare parts necessary to
repair the appliance is 7 or 10 years depending on the type and
purpose of the spare part
•The list of spare parts and the ordering procedure are available
on the websites of the manufacturer, importer or an authorised
representative
• The minimum warranty period for the appliance oered by the
manufacturer, importer or authorized representative is given in
the warranty card
•The warranty shall be void if you make any independent
adaptations or alterations, tamper with seals or other appli-
ance safety devices or its parts or interfere with the appliance
contrary to operating instructions
For more information about the product, please refer to the EU
EPREL Product Database at https://eprel.ec.europea.eu.
Alternatively you can use your mobile device to scan the QR code
on the energy label or enter the product model listed on the
energy label in the EPREL search engine.
5
Appliance information:
Please enter the details on the appliance rating plate below for
reference, to assist Amica Customer Care in the event of a fault with
your appliance and to register your appliance for guarantee purposes.
Appliance Model
Serial Number
EU Declarations of Conformity:
This appliance has been designed, constructed and marketed in
compliance with safety requirements of EU Directive 2014/35/EU (Low
voltage) and requirements of Directive 2014/30/EU (EMC).
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE
PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2012/19/EU.
Please render the appliance unusable before disposal. This includes
removing the plug and breaking the door fixings to prevent children
being trapped inside the appliance during play, or any other risk of
injury.
At the end of its working life, the product must not be disposed of as
urban waste. It must be taken to a special local authority dierentiated
waste collection centre or to a dealer providing this service.
Disposing of a household appliance separately avoids possible
negative consequences for the environment and health deriving from
inappropriate disposal and enables the constituent materials to be
recovered to obtain significant savings in energy and resources. As a
reminder of the need to dispose of household appliances separately,
the product is marked with a crossed-out wheeled dustbin.
6
Before first use
You must allow the appliance to settle for at least twenty four
hours prior to switching the power on.
It is recommended that you remove all internal and external
packaging and clean the interior of the appliance prior to first use. We
recommend that you use a solution of bicarbonate of soda and warm
water and then thoroughly dry the interior.
The appliance may have an odour to it at first use. This will disappear
as the appliance cools.
Please note:
• The appliance will work continuously until it gets to the correct
temperature. Continuous noise from the compressor and
refrigeration system is normal.
• If the appliance is switched o, you should allow five minutes before
switching it on again to prevent the risk of unnecessary damage to
the compressor.
•The LED display may not show the selected temperature whilst the
appliance first gets to the correct temperature. This is normal, and
the display will be corrected automatically once the appliance has
run for a few hours.
• If the appliance does not have a freezer compartment ( ) it is
not suitable for freezing foodstus.
7
Use
• Only store wine in sealed containers.
• Do not overload the cabinet.
• Only open the door when necessary. Opening the door for long
periods can cause a significant increase in temperature of the
compartments of the appliance
• Do not cover the shelves with aluminium foil or anything else that
will prevent air from circulating around the cabinet.
• To prevent damage to the door seal, ensure the door is fully open
before removing the shelves.
•Do not pull the shelves beyond the anti-stop position (approximately
one third out) when fully loaded.
•This appliance is intended to be used exclusively for the storage of
wine.
•In the event of a power failure, leave the door closed as much
as possible to maintain the internal working temperature. Should
the power failure continue for a prolonged period, you should
take steps to protect the contents of the wine cooler against a
rise in temperature. The wine cooler will remember the selected
temperature settings and revert to these settings once the power is
restored.
This appliance is suitable for use in an extended temperature climate
(ST) and has a normal operating ambient temperature of 18-38°C.
Use of the appliance below 18°C may cause performance issues that
are not indicative of a fault. Normal operation will resume once the
appliance is within the specified range.
8
Use and controls
To lock/unlock the control panel - all models
•Press and hold the power button and the light button for
approximately 4 seconds.
•The control panel locks automatically after approximately 15
seconds of inactivity.
To switch the power on/o - all models
•Press and hold the power button for approximately 4 seconds to
switch the wine cooler on.
•Press and hold the power button for approximately 4 seconds
to switch the wine cooler o.
Key:
1 – Power button
2 – Light button
3 – "+" button
4 – "-" button
Fig. 1
34
12
Key:
1 – Power button
2 – Light button
3 - Temperature display
button
4 – "+" button
5 – "-" button
6 – Zone selection button
123456
AWC300
AWC600
AWC150
34
1 2
Key:
1 – Power button
2 – Light button
3 – "+" button
4 – "-" button
9
To change the temperature - all models
•Unlock the control panel, if necessary.
•Press the or buttons until the required temperature is shown
on the display.
•The display flashes when temperature adjustment is active or a
dierent temperature is being set.
•What the wine cooler display does next is dependent upon what
temperature display you have active (see pages 9-10).
To change the zone control - AWC600
•Unlock the control panel, if necessary.
• Press the button. The 'active' display will flash.
• The temperature ranges are 5-12°C for the upper zone (left display)
and 12-20°C for the lower zone (right display).
To change the temperature reading - AWC300 & AWC150
The temperature of the wine cooler ranges from 5-20°C.
You can change the temperature display reading from Fahrenheit to
Celsius, or Celsius to Fahrenheit. To do so:
•Ensure the control panel is locked.
• Press and hold the or buttons for approximately 4 seconds.
To change the temperature reading - AWC600
You can change the temperature display reading from Fahrenheit to
Celsius, or Celsius to Fahrenheit. To do so:
•Ensure the control panel is unlocked.
• Press the button.
10
Optimal temperature selection
Below is a table showing the recommended storage temperatures for
dierent types of wine. These are also the ideal drinking temperatures
for most types.
Wine Type
Red Wine 15 - 18ºC (59ºF-64ºF)
Dry ⁄ White Wine 9 - 14ºC (48ºF-57ºF)
Rosé Wine 10 - 11ºC (50ºF-52ºF)
Sparkling Wine 5 - 8ºC (41ºF-46ºF)
To use the internal light
•Unlock the control panel, as per page 8, if necessary.
•Press the light button to switch the light on or o.
