Ameriwood HOME 8800335COM Manuel utilisateur

8800339COM

FireplaceTVStand

B348800000COM0

THISINSTRUCTIONBOOKLETCONTAINS

IMPORTANT

SAFETYINFORMATION.PLEASEREADANDKEEPFORFUTUREREFERENCE.

FollowAmeriwoodHome

Tube

You

DateofPurchase___/___/___

LotNumber:

DoNotReturnThisProduct!

Contactourcustomerserviceteamforhelpfirst.

Call:1‐800‐489‐3351(tollfree)

Monday‐Friday9am‐5pmCST

Visit:www.ameriwoodhome.com AssemblyDifficultyMeter

Easy Tough

WARNING

Thispieceoffurniturecanoverturnandcauseserious

injuries&ordeath.

Anchorthefurnituretoastudinthewall(ifthisisrequired).

Donotallowchildrentoclimbonfurniture

Keepheavieritemsonlowershelves.

8800335COM

ContactUs!

HelpfulHints

2

ameriwoodhome.com

DoNOTreturnthisproduct!

Contactourfriendlycustomerserviceteamfirstforhelp.

Callus!

1‐800‐489‐3351

Monday‐Friday

9am‐5pmCST

Visitameriwoodhome.comtoviewthe

limitedwarrantyvalidintheU.S.andCanada.

AssemblyTips

‐Openyouritemintheareayouplantokeepittoavoidexcessiveheavylifting.



‐Identify,sortandcountthepartsbeforeattemptingassembly.



‐Compressiondowelsarelightlytappedinwithahammer.



‐Slidesarelabeledwitha

(right)and

L

(left)forproperplacement.



‐MakesuretoalwaysfacethepointonthetopoftheCamLocktowardsthe

outeredge.



‐Useallthenailsprovidedforthebackpanelandspreadthemoutequally.



‐Backpanelmustbeusedtomakesureyourunitissturdy.



‐DoNOTuseharshchemicalsorabrasivecleanersonthisitem.



‐Neverpush,pull,ordragyourfurniture.

Tube

You

PEOPLENEEDEDFORASSEMBLY:1‐2

3

ameriwoodhome.com

BeforeYouStart



Quick

Tip

Assembly



CamLockFasteningSystem

ThisCamLockFasteningSystemwillbeusedthroughouttheassemblyprocess.

Readthrougheachstepcarefullyandfollowtheproperorder



Separateandcountallyourpartsandhardware

Partsarelabeledonthesurfaceoredgeofthepart



Giveyourselfenoughroomfortheassemblyprocess



Havethefollowingtools:FlatHeadScrewdriver,#2PhillipsHead

ScrewdriverandHammer

Caution:Ifusingapowerdrillorpowerscrewdriverforscrewing,

pleasebeawaretoslowdownandstopwhenscrewistight.

Failuretodosomayresultinstrippingthescrew.



PresspartstogethersoCAMBOLTinserts

intoedgehole.

PressCAMBOLTintohole. PressCAMLOCKintohole.

Endhole

Usingascrewdriver,turntheCAMLOCKclockwiseto

locktheCAMLOCKandCAMBOLTintotheirholes

andfasteningpartstogether.

Arrowtopointtowardsend

holeinedgeofpart.

4

ameriwoodhome.com

BeforeYouStart

Quick

Assembly

Tip

PleaseNote:

Youmayneedtolightlytapthewooddowelsintotheholesduring

yourassemblyprocess.

5

ameriwoodhome.com

BoardIdentification

Notactualsize

LeftPanel

38800335010

RightPanel

38800335020

LeftPartition

38800335030

RightPartition

38800335040

Divider(2)

38800335050

Top

38800335060

Bottom

38800335070

FixedShelf

38800335080

TVRail

38800335090

Kick

38800335100

Support

38800000110

CDE

FGH

IJK

6

ameriwoodhome.com

BoardIdentification

Notactualsize

Thispieceispaperboardconstruction.

Itisnotmadefromwood,butisrequired

fortheassemblyofyourunit.

SolidBack(2)

38800335120

BACK

PANEL

UpperBackPanel

K880033500

BACK

PANEL

7

ameriwoodhome.com

BoardIdentification

Notactualsize

LeftPanel

38800339010

RightPanel

38800339020

LeftPartition

38800339030

RightPartition

38800339040

Divider(2)

38800339050

Top

38800339060

Bottom

38800339070

FixedShelf

38800339080

TVRail

38800339090

Kick

38800339100

Support

38800000110

CDE

FGH

IJK

8

ameriwoodhome.com

BoardIdentification

Notactualsize

Thispieceispaperboardconstruction.

Itisnotmadefromwood,butisrequired

fortheassemblyofyourunit.

SolidBack(2)

38800339120

BACK

PANEL

UpperBackPanel

K880033900

BACK

PANEL

9

ameriwoodhome.com

PartList

ActualSize

NotActualSize

6 8

(x24)

#A22700

cam lock

(x24)

#A22710

cam bolt

(x12)

#A21660

wood dowel

(x8)

#A23030

confirmat screw

(x30)

#A21110

nail

(x11)

#A12120

#8X7/16"pan

(x14)

#A22760

quickloc

(x4)

#A11080

#6X7/16"flat

(x8)

#A80250

shelfsupport

(x2)

#A54270

connectingplate

(x4)

#A70310

grommet

(x2)

#H13250

glassshelf

Notethatyourunitmaycontainextrahardware

10 11 12

10

ameriwoodhome.com

PartList

#B64359

TVwarninglabel

(x1)

#A95070

fireplaceinsert

w/lightkit

13a

13b
