American DJ Splitter Manuel utilisateur

Splitter

American DJ®User Instructions

SPECIFICATIONS: MODEL - Splitter™

Weight: 18lbs.

Size: 22.5"H x 6"W x 8.75"L

Lamp: ZB- EHJ 24v/250w

Fuse: 4A GMA

Voltage: 120V

Working Position: Any Safe position

Duty Cycle: 10 min. on 10 min. off

Cooling: Fan cooled

Optics: High quality glass lens

Reflective dichoric

mirror

Affordable Quality Lighting Products From American DJ® Los Angeles, CA. 90058

CCAAUUTTIIOONN!!RReeaaddiinnssttrruuccttiioonnssbbeeffoorreeiinnssttaalllliinnggoorrpplluuggggiinngguunniittiinn..

Operating Instructions:

Unit is ready to be hung or set on flat surface. After plugging unit in, the outer mirror dish will react to bass

sound via the internal microphone. The internal dichoric color wheel will also rotate to sound. Adjust the sensi-

tivity knob on the bottom of the unit for sound sensitivity. Focus the front lens so the beam patterns are in focus

for the height the fixture in mounted. Be sure not to obstruct the cooling vents and keep in a well ventilated

area. For best effect, periodically clean the front focus lens and mirror with a glass cleaner.

Caution! Never open unit when in use. Always disconnect main power before serving or replacing lamp.

Remember to always replace with the same lamp and fuses, unless otherwise specified by technician.

Lamp Replacement: Open the front cover by removing the two thumb screw. Pull lamp out and remove it

from socket. Remove and replace lamp.

The American DJ SplitterTM comes with a 90 day limited warranty. We recommend filling out the warranty registration card

that came with your fixture to validate your warranty. For service contact American DJ.TM

HALOGEN LAMP WARNING!

This fixture is fitted with a halogen

lamp which is highly susceptible

to damage if improperly han-

dled. Never touch lamp with bare

fingers as the oil from your hands

will shorten lamp life. Also, never

move fixture until lamp has had

ample time to cool. Remember,

lamps are not covered under

warranty conditions.

™
