American DJ F-700 Manuel utilisateur

American DJ®

4295 Charter Street

Los Angeles Ca. 90058

www.americandj.com

Introduction:

Thank you for purchasing the F-700™ by American DJ®. The F-700™

has been tested at the factory and is ready to be used, there is no

assembly required. Please read the following instructions and safety

precautions before attempting any installation or using your new F-

700.™

Customer Support:

American DJ®provides a toll free customer support line, to provide set

up help and to answer any question should you encounter problems

during your set up or initial operation. You may also visit us on the web

at www.americandj.com for any comments or suggestions. For service

related issue please contact American DJ®. Service Hours are Monday

through Friday 9:00 a.m. to 5:00 p.m. Pacic Standard Time.

Voice: (800) 322-6337

Fax: (323) 582-2610

E-mail: [email protected]

Warning! To prevent or reduce the risk of electrical shock or re, do

not expose this unit to rain or moisture.

Caution! There are no user serviceable parts inside this unit. Do not

attempt any repairs yourself, doing so will void your manufactures war-

ranty. In the unlikely event your unit may require service please contact

your nearest American DJ dealer.

Do not discard the shipping cartoon in the trash. Please recycle when

ever possible.

Specications and improvements in the design of this unit and this

manual are subject to change without any prior written notice.

SAFETY ISSUES:

NEVER POINT OR AIM A F-700 TOWARDS PEOPLE OR THEIR

CLOTHING. THIS UNIT EMITS HOT VAPOR AND SHOULD BE

USED WITH THE SAME CARE THAT YOU WOULD OBSERVE

WHEN USING AN ELECTRIC KETTLE OR IRON.

IF THE POWER SUPPLY CORD IS DAMAGED, IT MUST BE

REPLACED BY MANUFACTURER OR ITS SERVICE AGENT

OR SIMILARLY QUALIFIED PERSON IN ORDER TO AVOID A

HAZARD.

F-700™ Introduction

©American DJ Supply®- www.americandj.com - F-700™ Instruction Manual Page 2

W/ ELECTRONIC

THERMOSTAT ETS

User Instructions

5/03

SPECIFICATIONS:

MODEL - F-700™

WEIGHT: 7.5 LBS.

DIMENSIONS: 13.5”(L) x 9”(W) x 6”(H)

FUSE: 7 A 250V

SUPPLY VOLTAGE: 110V

WARM UP TIME: 5 Minutes

TANK CAPACITY: 1 Quart

OUTPUT: 3,500 cubic feet per minute

FLUID TYPE: Water Base American DJ Fog Juice™

DUTY CYCLE: Not to exceed 6 hours plugged in.

HEAT EXCHANGER: 700 WATTS

WARRANTY: 90 Day Limited Warranty

To help prevent the unit from clogging, use American DJ®Clean

Machine™ liquid. Clean Machine is recommended when storing your

fogger for more than 1 week, or at least once a month as normal mainte-

nance under regular usage. Clean Machine removes particle build up in

the heater and gives longer life to the F-700. Clean Machine is like a tune

up for your F-700! Clean Machine is available in gallon or quart bottles.

F-700™ Operating Instructions

F-700™ Trouble Shooting

Plug the F-700™ into a standard 110V/120V supply. The unit will draw

up to 7A of power. Always be sure to maintain an adequate supply of

American DJ®Brand Fog Juice™ in the fluid reservoir. Running the F-700

dry will cause pump failure and or clogging. This is the largest cause of

failure in F-700s.

Connect the remote control to the rear of the F-700. When the power is

connected, the RED L.E.D. on the remote will begin to glow.

Once the machine has warmed up to normal operating temperature, the

L.E.D. on the remote will begin to glow. The glowing Green LED on the

remote indicates the unit is ready to emit fog.

To emit fog, press and hold the red button on the remote control. Fog

will continue to emit until the red remote button is released or the unit

has to recycle.

If fog does not come out, after holding the button down for 30 seconds,

check the fluid tank level and be sure there is fluid going through the

hose.

If you experience low output, pump noise, or no output at all, disconnect

immediately. Do not attempt to continue pushing the remote button as

this may damage unit. Check fluid level, the external fuse, remote con-

nection, and check power from wall. If all of the above appear to be okay,

and the unit fails to operate correctly, the unit will require service. Return

the machine to an American DJ® authorized dealer or service center.

We recommend you fill out the enclosed warranty card to validate your

purchase. All returned service items whether under warranty or not, must

be freight pre-paid and accompany an return authorization number (R.A.

#). If the unit is under warranty, you must provide a proof of purchase

invoice. Contact customer support for an R.A.#.

American DJ Supply World Headquarters:

4295 Charter Street Los Angeles, CA 90058 USA

Tel: 323-582-2650 Fax: 323-582-2610

Web: www.americandj.com E-mail: [email protected]

F-700™ Clean Machine

©American DJ Supply®- www.americandj.com - F-700™ Instruction Manual Page 3

Please Note: Specications and improvements in the design of

this unit and this manual are subject to change without any prior

written notice.
