American DJ HMI 575TM Manuel utilisateur

American DJ® LOS ANGELES, CA. 90058

Model: Tempest ll/ HMI 575™

SPECIFICATIONS:

Lamp: ZB-HMI 575

Power: 240V 50Hz/60Hz

Optics: High Quality Glass Lenses

Ventilation: Fan Cooled

Working Position: Any

Weight: 59 lbs.

Size: 27.5” x 27.5” x 8.5”

HALOGEN LAMP WARNING!

This fixture is fitted with halogen lamps

which are highly susceptible to damage if

improperly handled. Never touch lamp

with bare fingers as the oil from your

hands will shorten lamp life. Also, never

move fixture until lamp has had ample

time to cool. Remember, lamps are not

covered under warranty conditions. Thank you for purchasing this

American DJ® product. For your

convenience this lighting effect has

been lamped and is ready to be used,

there is no assembly required.

Please read the following

instructions before installing or

using your new unit.

Operating Instructions:

Unit is ready to be hung or set on the ground. After

plugging in unit, the lights will react to the music via the

sound active internal microphone. Adjust the sound

activation knob on the back of the unit for desired music

sensitivity.

Product Description:

The Tempest ll/HMI 575™ features the ZB-HMI575,

discharge lamp! A centerpiece effect by American

DJ®, featuring 6 separate mirror units creating solid

and moonflower type beams that rotate and sweep

across a room. The Tempest ll/575™ has a low profile

design for clubs with low ceilings, producing 6 dichroic

colors plus white. Built-in programs; gives a mini

Terminator type effect. Programs can be selected by a

DMX 512 Controller.p Fan cooled. 30 ft. remote with

blackout feature.

To replace lamp; unscrew knobs on lamp

replacement hatch on the center front of the

fixture. Replace bulb; reassemble.

For service contact your American DJ® dealer.

Caution! Always disconnect from main

power before replacing lamps or servicing unit.

Remember to always replace with same lamps

and fuses.

American DJ®

Tempest ll/HMI575™

With master/slave capabilities!

User Instructions

American DJ® LOS ANGELES, CA. 90058 PG 2 OF 2

The Tempest ll ™ is now Linkable with Master / Slave capability! To use this function set the

MASTER unit Dipswitch #10 on. Then connect with the XLR Cable using the Female XLR to the

second unit input Male XLR , Turn all Dipswitches off on the SLAVE unit. and it will respond the same

as the MASTER unit.

In addition you can select the program you want by using a DMX 512 Controller. The values needed

are in Chart ONE below.The Tempest ll ™ uses 1 channel to control program selection. Please

select the starting address by using the dip switches.

CHART ONE

Value Result

0-7 Blackout

8-15 Program 1

16-23 Program 2

24-31 Program 3

32-39 Program 4

40-47 Program 5

48-55 Program 6

56-63 Program 7

64-71 Program 8

72-79 Program 9

80-87 Program 10

88-95 Program 11

96-103 Program 12

104-111 Program 13

112-119 Program 14

120-127 Program 15

128-135 Program 16

136-143 Program 17

144-151 Program 18

152-159 Program 19

160-167 Program 20

168-175 Program 21

176-183 Program 22

184-191 Program 23

192-199 Program 24

200-207 Program 25

208-215 Program 26

216-223 Program 27

224-231 Program 28

232-255 Random

Programs

DMX CHANNEL

1 2 3 54 7 9 1086

Each # above has an ADDRESS based on binary code.

#1 ADDRESS is 1

#2 “ “ 2

#3 “ “ 4

#4 “ “ 8

#5 “ “ 16

#6 “ “ 32

#7 “ “ 64

#8 “ “ 128

#9 “ “ 256

#10 is not used with DMX but to select Master / Slave

ALWAYS SET THE ADDRESS ONE LESS THAN THE

CHANNEL WANTED.

You set the ADDRESS wanted by COMBINING the

Dipswitches.

EXAMPLE:

Set ADDRESS at 0 to start at CHANNEL 1

( all Dipswitches OFF)

Set ADDRESS for 21 Set ADDRESS for 201

to start at CHANNEL 22 to start at CHANNEL 202

Dipswitches # 1 =1 Dipswitches # 1 = 1

3 = 4 4 = 8

5 = 16 7 = 64

= 21 8 = 128

= 201

1 4 16 64 256

2 8 32 128

TEMPEST II™ Instructions CONT.
