AmazonBasics B07MNBYN11 Manuel utilisateur

created by: Impala Services Ltd.Page size: A4

B07MNBYN11, B07MND862G, B07MGL8651

Classic Kitchen Cart with Cabinet

Charriot de Cuisine Classique avec Armoire

Klassischer Küchenwagen mit Schrank

Carrello da Cucina Classico con Mobile

Carrito de Cocina Clásico con Armario

クラシックキッチンカートキャビネット付

English �� 3

Français �� 11

Deutsch�� 19

Italiano�� 27

Español�� 35

日本語 �� 43

Welcome Guide • English

Contents:

Before getting started, ensure the package contains the following components:

Lx1

Mx1

Nx1

Ox2

Px1

Qx4

Rx8

Sx1

Tx4

Ux8

Vx12

Wx2

Xx2

Yx8

Zx1

You will need

Ax1

Bx1

Cx1

Dx1

Ex1

Fx1

Gx1

Hx1

I1 x1

I2 x1

Jx1

Kx1

IMPORTANT SAFEGUARDS

Read these instructions carefully and retain them for future use. If this product is passed to a third party, then

these instructions must be included.

When using the product, basic safety precautions should always be followed to reduce the risk of injury including the

following:

• Do not let children climb on or play with the product.

• Always use on a ﬁrm, level ground.

• Do not sit on the product.

• Check to ensure that all components and ﬁxings of this product are secure, do not use if you have any doubts about

its ﬁtness for purpose.

• To avoid scratching the ﬂoor, assemble the product on a soft surface such as a carpet.

Before First Use

• Check for transport damages.

Risk of suffocation! Keep any packaging materials away from children – these materials are a

potential source of danger, e.g. suffocation.

Assembly

Step 1:

• Attach the towel bar (L) to the right panel (D). Secure the connection with 2 screws (V). Rotate the hex key (Z)

clockwise.

• Attach the right panel (D) to the top panel (A). Secure the connection with 1 screw (V).

DANGER

Assembly

Step 2:

RY V

• Attach the lower back cross bar (I1), the lower front cross bar (J), the upper back cross bar (I2) and the upper front

cross bar (K) to the right panel (D). Secure each connection with 1 screw (V) and 1 short wood dowel (R).

Insert the screw covers (Y) after assembly step 4.

Step 3:

I1D

• Slide the back panel (G) into the grooves of the lower back cross bar (I1), upper back cross bar (I2) and the right

panel(D).

NOTICE

Assembly

Step 4:

• Attach the left panel (C) to the top panel (A), the lower back cross bar (I1), upper back cross bar (I2), upper front

cross bar (K) and the lower front cross bar (J). Secure the connection with 4 short wood dowels (R) and 5 screws(V).

Tighten all the screws after assembly step 4. Insert the screw covers (Y) on both side panels.

Step 5:

• Insert the 2 castors (W) and the 2 locking castors (X) into the holes at the bottom of the side panels (C/D).

NOTICE

Assembly

Step 6:

• Lift the product carefully and place it on its wheels.

• Fit the bottom panel (H) into the bottom frame of the product.

• Fit the shelf (B) into the corresponding supports on the inside of the side panels.

Step 7:

O U P N

Q O

• Assemble the drawer by combining the front panel (M), the 2 side panels (O), the back panel (N) and the bottom

board (P). Secure the connection with 8 screws (U).

• Attach 2 knobs (Q) to the front panel (M). Secure the connection with 2 screws (T).

Assembly

Step 8:

• Slide the drawer into the drawer compartment.

• Insert the long wood dowel (S) into the corresponding hole at the bottom of the top panel (A).

Step 9:

Q F T E

• Attach 1 knob (Q) to the left door (F) and to the right door (E). Secure each connection with 1 screw (T).

Assembly

Step 10:

• Attach the left door (F) and the right door (E) to the corresponding door hinges.

Cleaning and Maintenance

Cleaning

• To clean, wipe with a soft, slightly moist cloth.

• Never use corrosive detergents, wire brushes, abrasive scourers, metal or sharp utensils to clean the product.

Maintenance

• Check the components regularly to make sure all screws and bolts are tightened.

• Store in a cool and dry place away from children and pets, ideally in original packaging.

• Avoid any vibrations and shocks.

Speciﬁcations

Item number Dimensions (W x H x D) Weight Color

B07MNBYN11

approx. 68.3 x 86.4 x 44.1 cm (26.9 x 34 x 17.4in) approx. 19.8 kg (43.6 lbs)

Espresso

B07MND862G Rustic White

B07MGL8651 Rustic Gray

Warranty Information

To obtain a copy of the warranty for this product:

For US - Visit amazon.com/AmazonBasics/Warranty

For UK - Visit amazon.co.uk/basics-warranty

— or —

Contact Customer Service at 1-866-216-1072

Feedback

Love it? Hate it?

Let us know with a customer review.

AmazonBasics is committed to delivering customer-driven products that live up to your high standards. We encourage

you to write a review sharing your experiences with the product.

Please visit: amazon.com/review/review-your-purchases#

For further services:

Visit amazon.com/gp/help/customer/contact-us

— or —

Contact Customer Service at 1-866-216-1072
