Amate Audio N26 Manuel utilisateur

User’s manual

October 2017

NITID N26_N36_N46 Oct 2017

2Amate Audio

Safety Instructions

1. All safety instructions must be read before using this device.

2. Keep and follow these instructions

3. Heed all warnings

4. The exclamation mark in the triangle indicates internal components which if

replaced can affect safety.

5. The lightning symbol within the triangle indicates the presence of dangerous

uninsulated voltages.

6. Only clean the device with a dry cloth.

7. Do not block any ventilation openings. Install in accordance with the

manufacturer’s instructions.

8. Do not install the device near heat sources such as radiators, heaters or other

heat-emitting elements.

9. Protect the power cord from being walked on or pinched, particularly at plugs,

convenience receptacles, and the point where they exit from the apparatus

10. The equipment must be repaired by qualified technical service personnel when:

A. The mains supply cable is damaged, or

B. Any object or liquid has damaged the device; or

C. The equipment does not function normally or correctly; or

D. The equipment has been exposed to the rain; or

E. The chassis is damaged

11. Disconnect the device in the case of electric storms or during long periods of

disuse.

12. WARNING – To reduce the risk of fire or electric shock, do not expose this

device to rain or moisture

13. The equipment shall not be exposed to dripping or splashing and no objects filled

with liquids, such as vases, shall be placed on the device.

14. For hanging and installation, use manufacturer recommended accessories only.

NITID N26_N36_N46 Oct 2017

3Amate Audio

1. INTRODUCTION

1.1. General

Amate Audio would like to thank you for your confidence in our NITID Series. We

suggest you to carefully read the following instructions in order to obtain the best

results in performance.

1.2. Features and presentation

N26

- Self-powered acoustic system

- XLR electronically balanced input & XLR parallel output

- AC PowerCon input and link

- 400 W Class-D amplifier for low-mid range

- 50 W Class-D amplifier for high range

- 24-bit AD/DA converters, 48 kHz sampling rate

- Self amplifier diagnostics: output power, temperature, clipping

- DSP Controls (delay, volume, PEQ, presets and limiter)

- 2 x 6" neodymium woofers with 1.5” voice coil and fibre cone

- 1" titanium diaphragm neodymium magnet tweeter

N36

- Self-powered acoustic system

- XLR electronically balanced input & XLR parallel output

- AC PowerCon input and link

- 500 W Class-D amplifier for low-mid range

- 100 W Class-D amplifier for high range

- 24-bit AD/DA converters, 48 kHz sampling rate

- Self amplifier diagnostics: output power, temperature, clipping

- DSP Controls (delay, volume, PEQ, presets and limiter)

- 3 x 6" neodymium woofers with 1.5” voice coil and fibre cone

- 1.4" PETP diaphragm ferrite magnet driver

- 50º to 100º (H) x 55º (V) asymmetrical dispersion horn

N46

- Self-powered acoustic system

- XLR electronically balanced input & XLR parallel output

- AC PowerCon input and link

- 600 W Class-D amplifier for low-mid range

- 100 W Class-D amplifier for high range

- 24-bit AD/DA converters, 48 kHz sampling rate

- Self amplifier diagnostics: output power, temperature, clipping

- DSP Controls (delay, volume, PEQ, presets and limiter)

- 4 x 6" neodymium woofers with 1.5” voice coil and fibre cone

- 1.75" PETP diaphragm neodymium magnet driver

- 50º to 100º (H) x 55º (V) asymmetrical dispersion horn

NITID N26_N36_N46 Oct 2017

4Amate Audio

1.3. Presets on N26, N36, N46

The N26, N36 and N46 include several manufacturer presets for different types of

applications.

FLAT

Flat response

NEARFIELD

-3dB mid

frequencies

(400Hz – 4 kHz)

LONGTHROW

+3dB high

frequencies

(only in N36

and N46)

SPEECH

HPF 100Hz

LPF 8 kHz

NITID N26_N36_N46 Oct 2017

5Amate Audio

XOVER

HPF 100Hz

2. CONNECTIONS

2.1. Connection Panel

The power and audio connections are located on the unique panel, shown in Fig. 1.

The different parts of the panel are explained in detail in the following sections of the

manual.

Control:

A) LCD: Displays information about the system status. The main screen shows the

following information.

Current preset

Input Level

Output Level LF Channel

Output Level HF Channel

Amplifier temperature

ALC mode enabled/disabled

ECO mode enabled/disabled

Keypad locked/unlocked

B) KEYPAD: Allows the user to perform basic operations on the DSP such as Preset

selection, audio settings and user preferences. There are three keys available:

MENU key: OK key: Circular key:

To enter the menu the keypad must be unlocked by pressing simultaneously the

MENU and OK keys.

The central circle of the circular key will light up in blue when this key is active.

C) PROTECTION LED: This led lights up when the amplifier is in a protection

situation (such as temperature excess, overcurrent, or other situations that can

compromise the amplifier’s integrity). It will also light up when the amplifier is in

standby mode. This happens for a couple of seconds at start-up.

The Protection led will light off when the amplifier recovers from the abnormal

situation. Shall the Protection led keep up lighted on even after a system restart,

please contact an authorized service.

FLAT

NITID N26_N36_N46 Oct 2017

6Amate Audio

Fig. 1. N26, N36, N46 control and connection panel

D) LIMITER ON LED: The limiter led lights up to indicate that the amplifier is

delivering the maximum power set by the limiter circuit. The limiter prevents the

loudspeaker from receiving excessive or distorted signal. Continuous lightning of this

led indicates that the signal is being massively compressed. In this case, the input

level should be reduced in order to get a proper dynamic headroom.

NITID N26_N36_N46 Oct 2017

7Amate Audio

Model Specifications:

E) MODEL DATA: The basic data of the model is found here:

- Model reference

- Amplifier program power (Watts)

- Maximum Sound Pressure Level Continuous delivered by the system (dB SPL)

F) AUTHENTICATION QR CODE: This QR code is a smart label that ensures that

the product is an original Amate Audio product. To verify the authenticity, please

follow the instructions in the following link:

http://www.amateaudio.com/en/product-authentication/

Connections:

G) AC MAINS INPUT: Mains supply connection via PowerCon. Use the blue

connector for AC input.

Always use mains power cable supplied by manufacturer.

Never connect the NITID cabinets to an unearthed mains supply or by

using an unearthed mains cable.

H) AC LINK: Grey connector to feed other units in parallel. Linking up to 10 units is

possible, provided that a quality cable of a minimum section of 3x2.5mm2is used.

Connecting more than 10 units in parallel may lead to a voltage drop in the cable that

will reduce the equipment performance.

I) BALANCED INPUT/LINK:

XLR-3 Female balanced signal connector for signal input and XLR-3 Male connector

for parallel connection of various cabinets with the same input signal.

Please always use balanced microphone cable with the following pin

assignment:

1. Shield

2. (+) Live

3. (–) Return

2.2. Configurations

2.2.1. Parallel connection

Connect the signal (mixing desk output) to INPUT on the first unit. Use the LINK

output to transfer the INPUT signal to the second unit and thus sequentially for

further units. All of the units in this chain must be switched on.

For the mains connection use the cable with the blue PowerCon.

You can use the mains connection in parallel by using a cable with grey PowerCon

at one end and the blue PowerCon at the other end.

NITID N26_N36_N46 Oct 2017

8Amate Audio

Fig. 2. Parallel connection for N26, N36 and N46 cabinets (signal and mains)

Do not connect NITID series units using PowerCon without earth.

Do not connect more than ten units using the AC output link connector.

2.2.2. Parallel connection with other equipment

You can connect other NITID loudspeakers or subwoofers in parallel with N26,

N36 or N46. Please, follow the same parameters as explained in

Fig. 2.

3. MOUNTING AND PLACEMENT

For a proper installation of the acoustic cabinet systems, it is strongly recommended

to carefully read the following advices.

3.1. Placement When possible, cabinets should be

located in a high position, slightly

inclined to the audience. If the

loudspeakers are located too low,

the listeners at the end of the room

will not hear a good sound quality.

Fig. 3. Flying placement

NITID N26_N36_N46 Oct 2017

9Amate Audio

3.2. N26, N36, N46 with subwoofer

All models are equipped with a 35 mm socket for

mounting the speaker on a subwoofer. Be careful not

to use this system on non-flat surfaces as it may

become unstable.

Fig. 4. N36 with subwoofer

3.3. 3.3. Asymmetrical and rotatable horns

The N36 and N46 incorporate an asymmetrical dispersion horn which will optimise

coverage.

To rotate the horn, unscrew the frontal grille, and then, unscrew the four fixing

screws of the horn. Rotate it 180 degrees taking care of the wires. Screw the horn

again and finally place the frontal grille in its right position.

Good coverage of audiences often is a conflicting combination of:

wide coverage for the closest audience (short throw)

narrow coverage for distant areas (long throw)

The asymmetrical dispersion horn coverage varies from "short throw" to "long throw"

along the vertical axis (keeping a constant vertical directivity). In conclusion,

directivity feature of (50º to 100º(H), 55º(V)) can be seen as if the horn itself had

"two" horizontal directivities, which depend on the distance. For short distances the

horn should be used with its "wide" dispersion (100º). For long distances the horn

should be used with its "narrow" dispersion (50º). We suggest you to pay attention

to the following examples.

NITID N26_N36_N46 Oct 2017

10 Amate Audio

100º

50º

LONG THROW

SHORT THROW

50º

100º

Nearfield

100º

SHORT THROW

50º

LONG THROW

50º

100º

Nearfield

3.3.1. Vertical-Positioned Cabinets (Flown and aiming to the audience)

We need wide coverage (100º) for the closest listeners and narrow coverage for the

distant audience.

Fig. 5. Vertical position

3.3.2. Horizontal-Positioned Cabinets (Flown and aiming to the audience)

We need wide coverage (100º) for the closest listeners and narrow coverage for the

distant audience.

Fig. 6. Horizontal position

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Amate Audio Système de haut-parleurs

Amate Audio

Amate Audio X-15LTP Manuel utilisateur

Amate Audio

Amate Audio DSP206 Manuel utilisateur

Amate Audio

Amate Audio X12CLA Manuel utilisateur

Amate Audio

Amate Audio LMS608 Manuel utilisateur

Amate Audio

Amate Audio KEY Series Manuel utilisateur

Amate Audio

Amate Audio xcellence X12CLD Manuel utilisateur

Amate Audio

Amate Audio XCELLENCE XW118 Manuel utilisateur

Amate Audio

Amate Audio Xcellence X102FD Manuel utilisateur

Amate Audio

Amate Audio LMS206 Manuel utilisateur

Amate Audio

Amate Audio DSP608 Manuel utilisateur

Amate Audio

Amate Audio X14T Manuel utilisateur

Manuels Système de haut-parleurs populaires d'autres marques

JVC

JVC CA-MXK5R Manuel utilisateur

LG NB4532B Manuel utilisateur

JVC

JVC CA-FSH100 Manuel utilisateur

5Core

5Core Pro Series Manuel utilisateur

EAW

EAW MQV1394e Manuel utilisateur

Lynx

Lynx GXR-LA10A Manuel utilisateur

iLive

iLive ITB066B Manuel utilisateur

RDX

RDX QuickStation 4 Manuel utilisateur

Electro-Voice

Electro-Voice S-122 Manuel utilisateur

Sven

Sven SPS-619 GOLD Manuel utilisateur

Pioneer

Pioneer CS-7070 Manuel utilisateur

EAW

EAW UB82e Manuel utilisateur

Sondpex

Sondpex Active Speaker System and Digital Music... Manuel utilisateur

JVC

JVC NX-PN7 Manuel utilisateur

Marshall Amplification

Marshall Amplification AR-DM61-BT Manuel utilisateur

Yamaha

Yamaha NX-A01 - Speaker Sys Manuel utilisateur

SE Audiotechnik

SE Audiotechnik I-LINE Manuel utilisateur

Gemini

Gemini WRX-843 Series Manuel utilisateur
