Amano Amano TCX 21 Manuel utilisateur

AMANO®

TCX-21

Electronic Time Clock

Operation Manual

Thank you…

for purchasing another fine product from

Amano Cincinnati, Inc.

Important

Note that the government standard for DST is subject to change. Your

clock is factory-set for correct DST based upon when it was

manufactured, but any revision to DST begin or end dates may require

updating the system-set DST calendar.

If you live in Arizona, Hawaii, parts of Indiana, or any other area that

does not use Daylight Saving Time, refer to this document’s DST

settings instruction for details regarding disabling the DST function.

Do not return this clock to the retailer. If you have any questions or need

assistance, please call us toll free at:

1-800-253-9836

Proprietary Notice

This document contains proprietary information and such information

may not be reproduced in whole or part without the written permission

from Amano Cincinnati, Inc., 140 Harrison Ave., Roseland, New Jersey,

07068.

Amano Cincinnati, Inc. reserves the right to make equipment changes

and improvements, which may not be reflected in this document.

Portions of this document may have been updated to include the latest

hardware or firmware version, if applicable.

We recommend that this document be read in its entirety before any

attempt is made to operate the equipment.

Need Ribbons, Keys and Accessories?

Visit

www.amano.com

Call - (800)-253-9836

Amano TCX-21 Operation Manual 1

Specifications

Power Requirements: AC100V ± 10%, 50/60Hz

AC120V ± 10%, 60Hz

AC230V ± 10%, 50/60Hz

Ambient Temperature: -10°C to 45°C (14°F to 113°F)

Ambient Humidity: 10% to 90% (non-condensing)

Dimensions: 6 7/8” (175 mm) wide x 8 1/4” (210 mm) high x

6 1/4” (159 mm) deep

Weight: 3.196 Kg (7 lbs.)

Environment: Indoor use only; dust-free environment. Keep

out of direct sunlight.

External View

Print Button

Analog Clock

Print Window

LCD Display

Printer Platen

and Margin

ustment

Cover Lock

Amano TCX-21 Operation Manual 2

Removing the Cover & Packing Material

1. Turn the key clockwise to unlock the

cover.

2. Lift the cover up, then pull it towards

you to remove it.

3. Lift the printer block and remove the

spacer.

4. Remove the spacer between the

Ribbon Cartridge and the Printer

Carriage Tab.

5. Reinstall the cover of your unit.

Internal View

LCD Display

Program Buttons

Reset

Button

Analog

Clock

Ribbon

Cartridge

Card Stopper

Adjustment Screw

Printer Platen

Amano TCX-21 Operation Manual 3

Power Connection

Before connecting power, verify that the AC outlet voltage falls in the

range of 100-240 Volts AC and that the power cord and plug are

appropriate for your AC source. Plug the power cord into a properly

grounded 120 or 240 Volt wall outlet.

Wall Mounting

Note: Mounting screw locations should be marked on the wall. Do not insert a

drill bit through the mounting holes of the back plate when drilling holes.

1. Disconnect the power cord from the power source.

2. Unlock and remove the cover.

3. Locate the teardrop mounting hole and the two ¼" mounting holes in

the back plate.

4. Approximate the final location of the clock. Insert one #10 wood screw

or equivalent into the wall 1-1/2" (38 mm) from the top center location

of the clock.

5. Hang the clock on the screw using the teardrop mounting hole.

6. Secure the clock to the wall by inserting screws through the bottom

two mounting holes.

7. Reconnect the power cord to the power source.

8. Re-install the cover and secure.

Amano TCX-21 Operation Manual 4

Make a Test Print

1. Make sure that there is power to the TCX-21 (Refer to Page 3).

2. Insert a piece of paper, or time card into the TCX-21. The clock will

automatically print YEAR, MONTH, DATE and TIME with AM or PM.

3. If the imprint is satisfactory, the TCX-21 is ready for use.

4. If you wish to change the time and/or print style on the TCX-21, enter

the Program Mode to make changes to the print styles. The next

page gives instructions on programming the TCX-21 to fit your

needs.

Adjusting the Margin

1. Unlock and remove the

cover. Note – suggest

unplugging the clock

before performing

margin adjustment.

2. Locate the Card Stopper

Adjustment Screw on the

right side of the clock,

below the printer platen.

3. Position a piece of paper or

time card as desired.

4. Loosen the screw to move

the Card Stopper forward or

back. Tighten the screw as

needed. (See top

illustration.) The print

margin can be adjusted to a

maximum of 7/8” (22 mm).

Amano TCX-21 Operation Manual 5

Program Mode Guide

Unlock and remove the cover. Locate the PROGRAM, CHANGE and

ENTER buttons on top of the clock.

The PROGRAM button is used to enter and exit the Program Mode.

Press the PROGRAM button at any time to exit the Program Mode. If a

program step is in the process of being changed when this button is

pushed, the new information will not be saved.

The CHANGE button is used to change the information on the display.

When you are reviewing the main programming menu, use the CHANGE

button to advance to the next programming step. When you are revising

a programming step, use the CHANGE button to change the blinking

information.

The ENTER button is used to accept the information shown on the

display and save it in memory.

The RESET button is located on the right-side of the clock. Pressing this

button will clear any jams or errors.

Entering the Program Mode

1. Unlock and remove the cover.

2. Press and hold the PROGRAM button to access the Main

Programming Menu. The Main Programming Menu consists of the

Following:

Menu Code Menu Function

P1 dAtE Sets the date

P2 Cloc

Sets the clock time

P3 dLStDisable/Enable Daylight Saving Time

P4 PrntSets the print style using Quick Print Set-Up Codes

P5 Othr Accesses Other Options Menu

Amano TCX-21 Operation Manual 6

3. When P1 dAtE flashes in the display, release the

PROGRAM button. To move to the next menu item,

press the CHANGE button.

Note: If no other button is pressed after five minutes, the clock will return to the

Normal Mode and the clock hands will reset.

Setting the Year, Month and Date

1. When the display flashes P1 dAtE, press the ENTER

button.

2. Press the CHANGE button until the correct year

appears, then press the ENTER button.

3. Press the CHANGE button until the correct month

appears, then press the ENTER button.

4. Press the CHANGE button until the correct date

appears, then press the ENTER button.

5. When the display flashes the correct year, month and

date, press the ENTER button.

6. When the display flashes P1 dAtE, press the CHANGE

button to move to Setting the Clock Time.

Setting the Clock Time

Note: Use a 24 hour and 60 minute format when setting the time.

For example, 2:00 PM = 14:00.

1. Press the PROGRAM button for two seconds.

2. Press the CHANGE button until the display flashes

P2 CLoc, then press the ENTER button.

3. Press the CHANGE button until the correct hour

appears, then press the ENTER button.

4. Press the CHANGE button until the correct minute

appears, then press the ENTER button.

5. When the display flashes the correct time, press the

ENTER button.

6. When the display flashes P2 CLoc, press the

CHANGE button to move to the Daylight Saving

Time On/Off Setting.

Amano TCX-21 Operation Manual 7

Disabling/Enabling Daylight Saving Time (DST)

Note: When this setting is set to ON, the clock’s time will automatically change

for DST. When this setting is set to OFF, the clock’s time will not change

for DST. The dates to begin and end DST are set in the Other Options

Menu (See page 8).

1. When the display flashes P3 dL St, press the ENTER

button.

2. Press the CHANGE button to alternate between On

and Off.

3. When the display flashes the correct setting, press

the ENTER button.

4. When the display flashes P3 dL St, press the

CHANGE button to move to the Quick Set-Up Code

setting.

The Quick Set-Up Code Setting

Note: If you do not wish to use one of the Quick Set-Up Code settings, you may

set an alternate style on the following page.

1. When the display flashes P4 Prnt, press the ENTER

button.

2. The display will flash the current setting. Press the

CHANGE button to scroll through each of the Quick

Set-Up Code Settings.

Code Print Style Print Direction

Pr-1 Day, 24Hr., 100th/Hr Right Side Print

Pr-2 Day, 12Hr., 60th/Hr. Right Side Print

Pr-3 Month, Date, 24Hr., 100th/Hr. Right Side Print

Pr-4 Month, Date, 12Hr., 60th/Hr. Right Side Print

Pr-5 2 Digit Year, Month, Date, 12Hr., 60th/Hr. Right Side Print

Pr-6 4 Digit Year, Month, Date, 12Hr., 60th/Hr. Right Side Print

Pr-7 4 Digit Year, Month, Date, 24Hr., 60th/Hr. Right Side Print

3. When the display flashes the correct setting, press the

ENTER button.

4. When the display flashes P4 Prnt, press the CHANGE

button to move to the Other Options menu.

Amano TCX-21 Operation Manual 8

Accessing the Other Options Menu

1. When the display flashes P5 Othr, press the ENTER

button.

2. The display will flash the first programming step in the

Other Options sub-menu [11 Prnt]. Press the

CHANGE button to advance through the menu selections.

Menu Code Menu Function

I1 Prnt

Set Print Style using Symbol or Print Style Codes

I2 LAn9

Sets the Language of the print out

I3 Prdr

Sets the Print Direction (left or right hand)

I4 APrt

Disable, enable, or configure the Auto print option

I5 2Er0

Disable/enable Leading Zero in print out

I6 bdLt

Set the date that Daylight Saving Time begins

I7 EdLt

Set the date that Daylight Saving Time ends

I8 dIA9

Accesses the Diagnostic Routine

Setting Up Alternate Print Styles

Note: If you do not wish to use one of the Quick Set-Up Code settings, you may

select from the Alternate Print Style sub-menu.

1. When the display flashes 11 Prnt, press the ENTER

button.

2. Press the CHANGE button to move from Code

setting to Symbol setting. If you select Code, you

must enter a Print Style Code from Table 1 on the

next page. If you select Symbol, you can “build” a

custom Print Style using Tables 2 and 3 on pages 11

and 12.

3. When the display flashes the correct setting, press

the ENTER button.

Selecting a Print Code

Note: Refer to Table 1 on the next page for Print Style Codes.

1. When the display flashes Pr COdE, press the ENTER

button.

2. Press the CHANGE button until the desired number

appears in the first position. Press the ENTER button.

3. Press the CHANGE button until the desired number

appears in the second position. Press the ENTER

button.

Autres manuels pour Amano TCX 21

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Amano Horloge

Amano

Amano PIX-25 Manuel utilisateur

Amano

Amano PIX-25 Mode d'emploi

Amano

Amano PIX-75 Manuel utilisateur

Amano

Amano PR600 Series Manuel utilisateur

Amano

Amano Time Partner TCX-11 Manuel utilisateur

Amano

Amano PIX-21 Manuel utilisateur

Amano

Amano EX3500N Manuel utilisateur

Amano

Amano 4700 Series Manuel utilisateur

Amano

Amano PIX-28 Manuel utilisateur

Amano

Amano PIX-55 Manuel utilisateur

Amano

Amano PIX-10 Manuel utilisateur

Amano

Amano MJR-8500 SERIES Manuel utilisateur

Amano

Amano TCX-22 Manuel utilisateur

Amano

Amano EX9000 series Manuel utilisateur

Amano

Amano EX7500 series Manuel utilisateur

Amano

Amano BX 2000 Manuel utilisateur

Amano

Amano EX-3500 Manuel utilisateur

Amano

Amano PIX-21 Manuel utilisateur

Amano

Amano MRX-35 Instruction manuelle

Amano

Amano MICRODER MR-7000 Series Manuel utilisateur

Amano

Amano PIX-75 Mode d'emploi

Amano

Amano EX9000 series Manuel utilisateur

Amano

Amano PIX-10 Manuel utilisateur

Amano

Amano PIX-15 Manuel utilisateur

Manuels Horloge populaires d'autres marques

Silicon Laboratories

Silicon Laboratories SI5324 Manuel utilisateur

Heathkit

Heathkit GC-1005 Manuel utilisateur

Oregon Scientific

Oregon Scientific PRYSMA RMR221P Manuel utilisateur

Andrew O'Malley

Andrew O'Malley DOTKLOK Manuel utilisateur

ALGE-Timing

ALGE-Timing ASC3 Manuel utilisateur

Bodet

Bodet Profil 960 Manuel utilisateur

Nixie Clock

Nixie Clock Divergence Meter Manuel utilisateur

La Crosse Technology

La Crosse Technology WS-8256-AL Manuel utilisateur

Mini Gadgets

Mini Gadgets MCPro Manuel utilisateur

Casio

Casio TMR-200 Manuel utilisateur

Progetti

Progetti ILTEMPOSTRINGE Manuel

BVItech

BVItech BV-101 Manuel utilisateur

Progetti

Progetti KALIMERO Manuel

La Crosse Technology

La Crosse Technology WT-3141b Manuel

La Crosse Technology

La Crosse Technology W86531 Manuel utilisateur

Sharp

Sharp SPC900 Manuel utilisateur

La Crosse Technology

La Crosse Technology 404-50447 Manuel utilisateur

Datexx

Datexx DF0063 Manuel utilisateur
