COOKTOP PARTS

For Model: AEP222VAW0

(White)

2−09 Litho in U.S.A. (JMJ) (psw) Part No. W10245886 Rev. A

20" ELECTRIC

FREESTANDING RANGE

STANDARD CLEAN OVEN

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 Literature

W10181328

Use & Care Guide

W10175654

Insallation

Instructions

W10181003

Tech Sheet

98007130 Safer Cooking Tips

98015589 Template, Anti−Tip

W10183393

Knob, Control (5)

W10168363

Support, Burner

W10187996

Panel, Manifold

W10206396

Bracket, Support

W10179656

Thermostat

W10175582

Cooktop

8 98006633 Screw (2)

9 98005578 Screw (5)

W10161199

Bracket, Cooktop

11 Bowl, Chrome

W10179653

8" (1)

W10179650

6" (3)

W10179657

Indicator, Lens

13 Switch, Infinite

W10179654

Left Front

W10179655

LR, RF & RR

14 Element, Surface

W10179646

8" (1)

W10179644

6" (3)

15 98005663 Screw (10)

W10185551

Indicator, Light

17 814399 Receptacle, Elmnt

W10190578

Foil, Panel

19 98005000 Screw (4)

20 98005642 Clip, Therm Bulb

W10159818

Shield, Control

22 98011571 Switch, Light

OVEN DOOR AND DRAWER PARTS

For Model: AEP222VAW0

(White)

W10245886

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 98010413 Liner, Door

2 98006716 Retainer,

Insulation (7)

3 98009515 Panel, Oven Door

W10198647

Seal, Oven Door

5 Retainer

98004564 Right

98004629 Left

6 98004993 Screw

W10137237

Insulation, Door

8 98008699 Screw

9 98004219 Screw

10 8533842 Screw

11 98006727 Screw

12 98009307 Door, Broil

W10208117

Bracket, Panel

14 98004650 Nut, Push

15 6610364 Clip, Door

16 98006633 Screw

W10216805

Washer (2)

18 98004947 Handle, Oven Door

19 98017873 Hinge, Oven Door

W10201296

Glass, Inner

W10168624

Glass, Outer

22 Insulation

W10110944

Right

W10110943

Left

23 98004979 Bumper

24 98012903 Insul., Retainer

(Bottom)

25 98004981 Insul., Retainer

(Top)

26 Clip, Glass

98004952 Retainer, LH

98004953 Retainer, RH

CHASSIS PARTS

For Model: AEP222VAW0

(White)

W10245886

CHASSIS PARTS

For Model: AEP222VAW0

(White)

W10245886

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

W10176276

Cover, Flue Box

W10185442

Counter Weight (3)

W10168363

Support, Burner

4 98012912 Support, Oven

5 Side, Oven

98004452 Right Side

98004451 Left Side

6 98004448 Top, Oven

7 98005502 Clip, Oven Botton

W10175662

Cover, Rear

9 98010061 Panel, Side

W10166296

Back, Main

11 98015099 Diverter, Heat

W10207167

Bumper, Cooktop

13 98007191 Shield, Heat

(Lower)

14 Leg, Leveler

W10153610

Front (2)

W10058460

Rear (2)

W10116396

Flue, Assembly

16 98013690 Spring, Torsion

(Flue Box)

W10170595

Seal, Door

W10208539

Box, Burner

19 98006752 Frame, Front

20 98016942 Rack, Oven

W10192836

Bottom, Oven

W10170571

Element, Broil

W10163272

Element, Bake

24 98006633 Screw

25 98003945 Baffle, Base

26 98003830 Rail, Base

27 98007126 Support, Foot

28 98004722 Clip, Cooktop

29 98010054 Support, Rear

30 98006634 Screw (5)

31 98009179 U−Nut

32 98008545 Screw (4)

33 98006632 Screw

34 98004219 Screw (6)

35 98015526 Screw (2)

36 98017387 Baffle, Side

37 98004973 Support, Element

W10181453

Block, Terminal

W10179708

Screw

W10204883

Nut, Terminal

Block

W10209692

Cover, Terminal

Block

W10208152

Cover, Main Rear

W10180177

Plate, Conduit

W10114530

Socket, Light

45 98004498 Bulb, Light

W10205700

Protector, Light

INSULATION

W10206735

Insulation, Wrap

W10137234

Insulation, Back

W10177346

Insulation, Bottom

W10207891

Insulation, Top

98004294 Wire Tie,

Insulation (2)

BACKGUARD PARTS

For Model: AEP222VAW0

(White)

W10245886

Illus. Part

No. No. DESCRIPTION

1 98009821 Trim, Top

2 Endcap

W10144828

Left

W10144829

Right

3 98015526 Screw (4)

W10145101

Support, Backguard

5 98009179 U − Nut

6 98006633 Screw

OPTIONAL PARTS (NOT INCLUDED)

For Model: AEP222VAW0

(White)

W10245886

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

Parts Not Illustrated and

Optional Parts (Not Included)

REFINISHING MATERIAL

242756 Touch−Up

Self−Clean (1/2PT)

INSULATION

261514 Insulation,

Fiberglass (1−1/2"

x 24" x 120")

240132 Insulation,

Fiberglass (2−1/2"

x 22" x 120")

PAINT, TOUCH−UP (1/2oz.)

72017 White

72032 Black

511873 White Porcelain

(2 oz.)

PAINT, PRESSURIZED SPRAY

(12 oz.)

350930 White

285006 Superior Black

206922 Primer (White)

PAINT, BULK (1 qt.)

799344 White (Uncut)

ACCESSORY PARTS

241430 Foil, Aluminum

Oven (18" x 25’)

98012220 Kit, Door Pin

Removal

ANTI−TIP KIT

98017833 Anti−Tip Kit

WIRING HARNESS PARTS

W10177729

Harness, Wire

(Surface To

Panel Assembly)

W10180175

Harness, Wire

(Oven Light

Switch)

6610473 Harness, Wire

(Ground)

W10177713

Wire, Infinite To

Term Block L1

(Black)

W10177714

Wire, Infinite To

Term Block L2

(Red)

W10177715

Wire, Term Block

To Thermostat L1

(Black)

W10177716

Wire, Thermostat

To Bake Element

(Blue)

W10177718

Wire, Thermostat

BR Bake Element

(Yellow)

W10177719

Wire, Tstat (4) To

Tstat (2) (Black)

W10177720

Wire, Infinite To

Indicator Light

(Black)

W10177722

Wire, Tstat (H)

To Oven Indicator

Light (Black)

W10177724

Wire, Infinite(L2)

To Surface

Indicator Light To

Oven (Red)

W10177726

Wire, Broiler

Element To

Thermostat (6) To

BK (Red)

W10177728

Wire, Term Block

To Tstat 5 (Red)

8534079 Screw, Ground

3391018 Cable Tie
