Service Instructions

is a registered trademark of Maytag Corporation or its related companies and is used under license.

80% Single Stage Gas Furnaces

GMES80, AMES80, GCES80, ACES80, VMES80,

VCES80 & Accessories

This manual is to be used by qualied, professionally trained HVAC technicians only. Goodman does not assume any respon-

sibility for property damage or personal injury due to improper service procedures or services performed by an unqualied

person.The material in this manual does not supercede manufacturer’s installation and operation instructions.

NLY

PERSONNEL

THAT

HAVE

BEEN

TRAINED

INSTALL

ADJUST

SERVICE

REPAIR

(

HEREINAFTER

, “

SERVICE

”)

THE

EQUIPMENT

SPECIFIED

THIS

MANUAL

SHOULD

SERVICE

THE

EQUIPMENT

. T

MANUFACTURER

WILL

NOT

RESPONSIBLE

FOR

ANY

INJURY

PROPERTY

DAMAGE

ARISING

FROM

IMPROPER

SERVICE

PROCEDURES

. I

YOU

SERVICE

THIS

UNIT

YOU

ASSUME

RESPONSIBILITY

FOR

ANY

INJURY

PROPERTY

DAMAGE

WHICH

MAY

RESULT

. I

ADDITION

JURISDICTIONS

THAT

REQUIRE

ONE

LICENSES

SERVICE

THE

EQUIPMENT

SPECIFIED

THIS

MANUAL

ONLY

LICENSED

PERSONNEL

SHOULD

SERVICE

THE

EQUIPMENT

. I

MPROPER

INSTALLATION

ADJUSTMENT

SERVICING

REPAIR

THE

EQUIPMENT

SPECIFIED

THIS

MANUAL

ATTEMPTING

INSTALL

ADJUST

SERVICE

REPAIR

THE

EQUIPMENT

SPECIFIED

THIS

MANUAL

WITHOUT

PROPER

TRAINING

MAY

RESULT

PRODUCT

DAMAGE

PROPERTY

DAMAGE

PERSONAL

INJURY

DEATH

WARNING

PROP 65 WARNING

FOR CALIFORNIA CONSUMERS

Cancer and Reproductive Harm -

www.P65Warnings.ca.gov

0140M00517-A

IMPORTANT INFORMATION

Pride and workmanship go into every product to provide our customers with quality products. It is possible, however,

that during its lifetime a product may require service. Products should be serviced only by a qualied service technician

who is familiar with the safety procedures required in the repair and who is equipped with the proper tools, parts, testing

instruments and the appropriate service manual. REVIEW ALL SERVICE INFORMATION IN THE APPROPRIATE

SERVICE MANUAL BEFORE BEGINNING REPAIRS.

IMPORTANT NOTICES FOR CONSUMERS AND SERVICERS

RECOGNIZE SAFETY SYMBOLS, WORDS AND LABELS

WARNING

O PREVENT THE RISK OF PROPERTY DAMAGE, PERSONAL INJURY, OR DEATH,

DO NOT STORE COMBUSTIBLE MATERIALS OR USE GASOLINE OR OTHER

FLAMMABLE LIQUIDS OR VAPORS IN THE VICINITY OF THIS APPLIANCE.

TABLE OF CONTENTS

WARNING

HIGH

VOLTAGE

ISCONNECT

ALL

POWER BEFORE SERVICING OR

INSTALLING THIS UNIT.

ULTIPLE POWER SOURCES MAY

BE PRESENT.

AILURE TO DO SO MAY CAUSE PROPERTY

DAMAGE, PERSONAL INJURY OR DEATH.

IMPORTANT INFORMATION...........................2- 4

PRODUCT IDENTIFICATION .........................5 - 9

ACCESSORIES...........................................10 - 13

OPERATING INSTRUCTIONS....................14 - 16

PRODUCT DESIGN....................................17 - 34

SYSTEM OPERATION.......................................35

TROUBLESHOOTING ................................36 - 37

POLARIZATION & PHASING...........................38

MAINTENANCE ..........................................39 - 40

SERVICING.................................................41 - 55

SERVICING TABLE OF CONTENTS.................43

WIRING DIAGRAMS..........................................57

IMPORTANT INFORMATION

To locate an authorized servicer, please consult your telephone book or the dealer from whom you purchased this prod-

uct. For further assistance, please contact:

CONSUMER INFORMATION LINE

GOODMAN®BRAND PRODUCTS

TOLL FREE

1-877-254-4729 (U.S. only)

email us at:

[email protected]

fax us at: (731) 856-1821

(Not a technical assistance line for dealers.)

CONSUMER INFORMATION LINE

AMANA® BRAND PRODUCTS

TOLL FREE

1-877-254-4729 (U.S. only)

email us at: hac.consumer[email protected]

fax us at: (731) 856-1821

(Not a technical assistance line for dealers.)

Outside the U.S., call 1-713-861-2500.

(Not a technical assistance line for dealers.) Your telephone company will bill you for the call.

IMPORTANT INFORMATION

B10259-216

CO can cause serious illness including permanent brain

damage or death.

Advertencia especial para la instalación de calentadores ó manejadoras

de aire en áreas cerradas como estacionamientos ó cuartos de servicio.

B10259-216

El monóxido de carbono puede causar enfermedades severas

como daño cerebral permanente ó muerte.

Las emisiones de monóxido de carbono pueden circular a través

del aparato cuando se opera en cualquier modo.

B10259-216

RISQUE D'EMPOISONNEMENT AU MONOXYDE DE CARBONE

Cette ventilation est nécessaire pour éviter le danger d'intoxication

au CO pouvant survenir si un appareil produisant du monoxyde

de carbone continue de fonctionner au sein de la zone confinée.

is a registered trademark of Maytag Corporation or its related companies and is used under license.

PRODUCT IDENTIFICATION

The model and manufacturing number are used for positive identication of component parts used in manufacturing.

Please use these numbers when requesting service or parts information.

G M E S 8 0 0 6 0 3 A N A A

12 3 4 5 6 7 8 9 10 11 12 13

Brand Minor Revision

G - Goodman® A - Initial Release

V - GMC® B - 1st Revision

Configuration

M - Upflow/Horizontal Major Revision

D - Dedicated Downflow A - Initial Release

B - 1st Revision

S - PSC Motor Nox

E - Constant Torque Motor/Multi-Speed ECM N - Natural Gas

V - Variable Speed ECM X - Low NOx

Gas Vale / Motor Cabinet Width

S - Single Stage / Single Speed A - 14"

B - 17.5"

C - 21"

AFUE D - 24.5"

80 - 80% AFUE

Maximum CFM

3 - 1200 CFM

MBTU/h 4 - 1600 CFM

40 - 40,000 5 - 2000 CFM

60 - 60,000

80 - 80,000

100 - 100,000

120 - 120,000

PRODUCT IDENTIFICATION

The model and manufacturing number are used for positive identication of component parts used in manufacturing.

Please use these numbers when requesting service or parts information.

A D E S 8 0 0 6 0 3 B N A A

1 2 3 4 5 6 7 8 9 10 11 12 13 14

Brand Minor Revision

A- Amana® Brand A - Ini�al Release

B - 1st Revision

Conﬁgura�on

M - Upﬂow/Horizontal Major Revision

C - Downﬂow/Horizontal A - Ini�al Release

B - 1st Revision

Motor

V - Variable Speed/ComfortNet Nox

E - High Eﬃciency N - Natural Gas

S - Single SpeedX - Low NOx

Gas Valve Cabinet Width

M - Modula�ng A - 14"

C - 2 Stage B - 17.5"

S - Single Stage C - 21"

D - 24.5"

AFUE

97 - 97% AFUE Maximum CFM

80 - 80% AFUE 3 - 1200 CFM

4 - 1600 CFM

MBTU/h 5 - 2000 CFM

40 - 40,000

60 - 60,000

80 - 80,000

100 - 100,000

120 - 120,000

Amana® Brand Furnace Nomenclature (14 Digits)

PRODUCT IDENTIFICATION

MODEL # MFG. #80 % GAS FURNACES

AMES80

AMES800403AXAA

AMES800603AXAA

AMES800604BXAA

AMES800804BXAA

AMES800805CXAA

AMES801005CXAA

AMES801205DXAA

Amana®Brand 80% gas furnace, 33 3/8" tall, upflow, horizontal right of left installation positions.

Induced draft, two-tone gray cabinet and panels. Multi-speed PSC motor, 120 volt carbide mini Igniter

with integrated circuit board. Left or right side gas entry.

AMES80

AMES800403AXAB

AMES800603AXAB

AMES800604BXAB

AMES800804BXAB

AMES800805CXAB

AMES801005CXAB

AMES801205DXAB

Amana®Brand 80% gas furnace, 33 3/8" tall, upflow, horizontal right of left installation positions.

Induced draft, two-tone gray cabinet and panels. Multi-speed PSC motor, 120 volt carbide mini Igniter

with integrated circuit board. Left or right side gas entry.

AMES80

AMES800403AXAC

AMES800603AXAC

AMES800604BXAC

AMES800804BXAC

AMES800805CXAC

AMES801005CXAC

AMES801205DXAC

FIRST REVISIONS WITH PCBBF134 CONTROL BOARD (Beginning in 9/2015). Amana Brand 80%

gas furnace, 33 3/8" tall, upflow, horizontal right of left installation positions. Induced draft, Amana two

tone gray cabinet and panels. Multi-speed PSC motor, Left or right side gas entry.

AMES80 AMES800403AXAD

AMES800603AXAD

Amana®Brand 80% gas furnace, 33 3/8" tall, upflow, horizontal right of left installation positions.

Releases new Broad ocean Motor 0131F00041(1/3HP, 4SP, 6PL) aluminum winding motor.

MODEL # MFG. #80 % GAS FURNACES

ACES80

ACES8000403AXAA

ACES8000603AXAA

ACES8000804BXAA

ACES8001005CXAA

Amana®Brand 80% gas furnace, 33 3/8" tall, dedicated downflow installation. Induced draft, two-tone

gray cabinet and panels. Multi-speed PSC motor, 120 volt carbide mini Igniter with integrated circuit

board. Left or right side gas entry. Stainless steel heat exchanger.

ACES80

ACES8000403AXAB

ACES8000603AXAB

ACES8000804BXAB

ACES8001005CXAB

Amana®Brand 80% gas furnace, 33 3/8" tall, dedicated downflow installation. Induced draft, two-tone

gray cabinet and panels. Multi-speed PSC motor, 120 volt carbide mini Igniter with integrated circuit

board. Left or right side gas entry. Stainless steel heat exchanger.

ACES80

ACES800403AXAC

ACES800603AXAC

ACES800804BXAC

ACES801005CXAC

FIRST REVISIONS WITH PCBBF134 CONTROL BOARD (Beginning in 9/2015.) Amana Brand 80%

gas furnace, 33 3/8" tall, dedicated downflow installation, Induced draft, Amana two-tone gray cabinet

and panels. Multi-speed PSC motor. White--Rodgers gas valves. Left or right side gas entry.

ACES80 ACES8000403AXAD

ACES8000603AXAD

Amana®Brand 80% gas furnace, 33 3/8" tall, dedicated downflow, installation positions. Releases

new Broad ocean Motor 0131F00041(1/3HP, 4SP, 6PL) aluminum winding motor.

PRODUCT IDENTIFICATION

MODEL # MFG. #80 % GAS FURNACES

GMES80

GMES800403A*A*

GMES800603A*A*

GMES800604B*A*

GMES800804B*A*

GMES800805C*A*

GMES801005C*A*

GMES801205D*A*

Goodman®Brand 80% gas furnace, 33 3/8" tall, upflow, horizontal right of left installation positions.

Induced draft, Goodman gray cabinet and panels. Multi-speed PSC motor, 120 volt carbide mini

Igniter with integrated circuit board. Left or right side g

GMES80

GMES800403A*BA

GMES800603A*BA

GMES800604B*BA

GMES800804B*BA

GMES800805C*BA

GMES801005C*BA

GMES801205D*BA

Goodman®Brand 80% gas furnace, 33 3/8" tall, upflow, horizontal right of left installation positions.

Induced draft, Goodman gray cabinet and panels. Multi-speed PSC motor, 120 volt carbide mini

Igniter with integrated circuit board. Left or right side g

GMES80

GMES800403A*BB

GMES800603A*BB

GMES800604B*BB

GMES800804B*BB

GMES800805C*BB

GMES801005C*BB

Goodman®Brand 80% gas furnace, 33 3/8" tall, upflow, horizontal right of left installation positions.

Induced draft, Goodman gray cabinet and panels. Multi-speed PSC motor, 120 volt carbide mini

Igniter with integrated circuit board. Left or rightside g

GMES80

GMES800403A*BC

GMES800603A*BC

GMES800604B*BC

GMES800804B*BC

GMES800805C*BC

GMES801005C*BC

GMES801205D*BB

Goodman®Brand 80% gas furnace, 33 3/8" tall, upflow, horizontal right of left installation positions.

Induced draft, Goodman gray cabinet and panels. Multi-speed PSC motor, 120 volt carbide mini

Igniter with integrated circuit board. Left or right side g

GMES80

GMES800403A*BD

GMES800603A*BD

GMES800604B*BD

GMES800804B*BD

GMES800805C*BD

GMES801005C*BD

GMES801205D*BC

FIRST REVISIONS WITH PCBBF134 CONTROL BOARD (Beginning in 9/2015). Goodman®Brand

80% gas furnace, 33 3/8" tall, upflow, horizontal right of left installation positions. Induced draft,

Goodman gray cabinet and panels. Multi-speed PSC motor, Left or right

GMES80

GMES800403ANBE

GMES800403AXBE

GMES800603ANBE

GMES800603AXBE

Goodman®Brand 80% gas furnace, 33 3/8" tall, upflow, horizontal right of left installation positions.

Releases new Broad ocean Motor 0131F00041(1/3HP, 4SP, 6PL) aluminum winding motor.

VMES80

VMES800403ANAA

VMES800603ANAA

VMES800604BNAA

VMES800804BNAA

VMES800805CNAA

VMES801005CNAA

Goodman®Brand 80% gas furnace, 33 3/8" tall, upflow, horizontal right of left installation positions.

VMES80

VMES800403AXAA

VMES800603AXAA

VMES800604BXAA

VMES800804BXAA

VMES800805CXAA

VMES801005CXAA

GMC®Brand 80% gas furnace.

PRODUCT IDENTIFICATION

MODEL # MFG. #80 % GAS FURNACES

GCES80

GCES800403A*AA

GCES800603A*AA

GCES800804B*AA

GCES801005C*AA

Goodman®Brand 80% gas furnace, 33 3/8" tall, dedicated downflow installation, Induced draft,

Goodman gray cabinet and panels. Multi-speed PSC motor, 120 volt carbide mini Igniter with

integrated circuit board. Left or right side gas entry. Aluminized steel heat exchangers.

GCES80

GCES800403A*BA

GCES800603A*BA

GCES800804B*BA

GCES801005C*BA

Goodman®Brand 80% gas furnace, 33 3/8" tall, dedicated downflow installation, Induced draft,

Goodman gray cabinet and panels. Multi-speed PSC motor, 120 volt carbide mini Igniter with

integrated circuit board. Left or right side gas entry. Aluminized steel heat exchangers.

GCES80

GCES800403A*BB

GCES800603A*BB

GCES800804B*BB

GCES801005C*BB

Goodman®Brand 80% gas furnace, 33 3/8" tall, dedicated downflow installation, Induced draft,

Goodman gray cabinet and panels. Multi-speed PSC motor, 120 volt carbide mini Igniter with

integrated circuit board. Left or right side gas entry. Aluminized steel heat exchangers.

GCES80

GCES800403A*BC

GCES800603A*BC

GCES800804B*BC

GCES801005C*BC

Goodman®Brand 80% gas furnace, 33 3/8" tall, dedicated downflow installation, Induced draft,

Goodman gray cabinet and panels. Multi-speed PSC motor, 120 volt carbide mini Igniter with

integrated circuit board. Left or right side gas entry. Aluminized steel heat exchangers.

GCES80

GCES800403ANBE

GCES800403AXBE

GCES800603ANBE

GCES800603AXBE

Goodman®Brand 80% gas furnace, 33 3/8" tall, dedicated downflow, installation positions. Releases

new Broad ocean Motor 0131F00041(1/3HP, 4SP, 6PL) aluminum winding motor.

VCES80 VCES800603AXAA

VCES800804BXAA

GMC®Brand 80% gas furnace.

ACCESSORIES

MODEL

NUMBER

EFR01

AFE180-60A

AMU /GMU

ASAS / GSAS

SBT14

SBT17

SBT21

LPT03

LPLP03

FTK04

TK-400

HANG21

MVK-01

MVK-02

Description

EFR External Filter Rack

Dual Fuel Board

Media Air Cleaners

Electronic Air Cleaner

Downflow Subbase

14"

Downflow Subbase

17.5"

Downflow Subbase

21"

Propane Gas

Conversion Kit

LP Low Pressure

Shut Off Kit

Twining Kit

High Altitude Orifices

W/Pressure Switch

Masonry Vent Kit

AMES800403AXAD

· · · ·

(1)

· · · ·

AMES800603AXAD

· · · ·

(1)

· · · ·

AMES800604BXAC

· · · ·

(1)

· · · ·

AMES800804BXAC

· · · ·

(1)

· · · ·

AMES800805CXAC

· · · ·

(1)

· · · ·

AMES801005CXAC

· · · ·

(1)

· · · ·

AMES801205DXAC

· · · ·

(1)

· · · ·

AMES801405DNBC

· · · ·

(1)

· · · ·

ACES800403AXAD

····

(1)

· · ·

ACES800603AXAC

····

(1)

· · ·

ACES800804BXAC

· · · ·

(1)

· · ·

ACES801005CXAC

·· · ·

(1)

· · ·

·approved for this model

AMANA®BRAND "S" Model Furnace Accessories

Models built with PCBBF134 Control Board Beginning in 9/2015

not approved for this model

(1) W/R & HW single stage valve

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Amana Four

Amana

Amana *CVC96 Manuel utilisateur

Amana

Amana M9C96 Series Manuel utilisateur

Amana

Amana GUI Manuel utilisateur

Amana

Amana AMVM97 Manuel utilisateur

Amana

Amana LPM-10 Manuel utilisateur

Amana

Amana GUC Series Manuel utilisateur

Amana

Amana GDH8 Manuel utilisateur

Amana

Amana MEC80 Series Manuel utilisateur

Amana

Amana GMS8 Mode d'emploi

Amana

Amana M8 Manuel utilisateur

Amana

Amana *MSS96 Series Manuel utilisateur

Amana

Amana GUIS Manuel utilisateur

Amana

Amana Energy Command EGWH100DA3 P6874502F Mode d'emploi

Amana

Amana GUIA070A30 Mode d'emploi

Amana

Amana GUCA Manuel utilisateur

Amana

Amana AMH8 33-3/8" Manuel utilisateur

Amana

Amana MVC96 BB Series Manuel utilisateur

Amana

Amana GMES9 Series Mode d’emploi

Amana

Amana GUC Series Manuel du propriétaire

Amana

Amana 40" Manuel

Amana

Amana AMVM96 Manuel utilisateur

Amana

Amana GUX-X Manuel utilisateur

Amana

Amana MES96 U Series Manuel utilisateur

Amana

Amana GMSS9 Series Mode d'emploi

Manuels Four populaires d'autres marques

Armstrong

Armstrong EG7H SERIES Manuel utilisateur

Payne

Payne PG92ESA Mode d’emploi

SUPREME

SUPREME FEM10-M2301CM-A Instructions de montage

Ingersoll-Rand

Ingersoll-Rand S9V2B080D4VSAC/D Instructions de montage

Johnson Controls

Johnson Controls TM9T Mode d’emploi

Fluke

Fluke 9118A Manuel utilisateur

Lennox

Lennox EL195UHE Elite Series Manuel d'installation et d'exploitation

Intertherm

Intertherm M7RL Series Manuel utilisateur

HDG

HDG Pelletmaster 15 Manuel utilisateur

Pinnacle

Pinnacle Aero Bella AB-716C-QH Manuel

Nortek

Nortek MG2S Series Manuel utilisateur

VERDER

VERDER CARBOLITE GERO ABF 8/28 Manuel

Goodman

Goodman GMV9 Manuel

SUPREME

SUPREME SUP10-M2301C Instructions de montage

Dettson

Dettson AMT400B34-SM1PMA Instructions de montage

Evcon

Evcon DGD 60 MBH Manuel utilisateur

Trane

Trane S8B1A026M2PSAB Instructions de montage

Hart Sceintific

Hart Sceintific 9113 Manuel utilisateur
