ALZA LN21LD07 Manuel utilisateur
Light Up A Color Life
Smart RGB led strip
USER MANUAL
LN21LD07
Product Feature：
Light up every side of your TV, Super Bright RGB light strip for 50-70 inch TV. can be applied outdoors with an adapter(not included)
[ IP65 TV Strip Lights ]
16 color changing with 4 modes: fade, flash, strobe, smooth, 10 brightness dimmable. Remote control(included) to set your favorite
color, mode and brightness. DIY atmospheric lighting. Perfect mood light to improve image clarity, relieve eye fatigue.
[ Remote Control ]
Super bright RGB ribbon light can be applied for Television, Computer, Laptop background lighting, Under Bed, Entertainment Center,
Room Decorations, Home Movie Theater etc.
[ Various Applications ]
5V USB powered, low heat and safe to touch. Self-adhesive back tape,simply install RGB ribbon light by taking off back cover and
sticking onto desired installation area.
※Adds a Subtle RGB Led Strip Lights to your monitor, Reducing Eye Fatigue and Increasing Perceived Image Clarity.
※Besides Customize your monitor, TV or furniture with colorful LED light strip color to fit your mood!
Vansky Multi Color RGB Bias Lighting is an ideal solution.
[ Secure & Easy Installation ]
Remote Control, RGB TV Backlight, No need for other accessories. Any issue, you can contact us for solution.
[ Package Content ]
DIY
Smart Switches Smart
Plugs Smart
Wall Switches Smart
Lighting
Smart
Home Security
Achieve Optimal Viewing Experience
Fit your mood
Before After
Use the High-brightness vibrant and sharp LEDs to light up or create festive lights on your monitor, TV, or furniture.
Choose from solid colors, strobes, or cycling colors to fit your mood! You can easily swap between colors and lighting
modes using the in-line remote on the Strip.
※20 kinds of dynamic models
※16 kinds of static colors
※5 speeds level(dynamic mode)
※ 5 brightenss levels(static mode)
RGB LED STRIP-2x50cm
Model: LN21LD07
LED QTY: 15LEDs x 2pcs
Material: FPCB
IP Rating: IP65
Input Voltage: DC 5V
Luminous Flux: >300Lm/m
Lifespan: >25000Hours
Beam Angle: 140°
Working Humidity: <95%
Working Temperature: -15℃~50℃
Smart Controller
Choose the length that best fits your TV to maximize eye relief and viewing quality. You can trim your TV backlight every
2 inches for the perfect fit, every time.
USE FOR DIFFERENT TV SIZE
17‘’ 19‘’ 20‘’ 22‘’ 24‘’ 27‘’
SPECIFICATION
Supply voltage: DC 5V
Connecting Mode: Common anode
Net weight: 60g
Output: Three CMOS drain- open output
Remote controller: Infrared, 24Keys
Remote controller battery: 3V(CR2025)
500mm
10mm
100mm
Function of Remote controller
Adopt lR remoter to control the led controller ,which has 24 buttons,the function of each button as the table below:
Power ON
Power OFF
Brightness + (Speed up)
Brightness - (Speed down)
3 base color jumpy
7 color jumpy change
All fade out&fade in
7 color fade change Remote controller
4
Max load current: 2A each color
Material: ABS V0
Dimension:
LED Strip(500mmx10mmx2.2mm) x 2pcs
Controller(50x35x21mm)
Remote Controller(85x52x7mm)
Controller
1USB
2
3RGB LED STRIP
1.DO NOT cut the led strip lights to make 90 degree,if you wanna the led strip have niece square edge,just bend it. Only
cut the led light strip when it is too long for your tv.
2.Clean the dust to ensure the back of your TV is free from dust before installation to avoid falling off.
3. TV Frosted back may not firmly stick.
4. For the USB port Electric current, If a small part TV may not supply reach to 1A, When insert it to the TV USB port and
don't turn on or flashes sometimes,You can simply use the 5V 1A Universal USB Wall Charger to power the led strip lights
instead.
5.The LED Light Strip can be turn on/off the same time with the TV' power on/off, but get few exceptions as different TV
version.
1. Clean the surface 2. Tear the backing tape
5. Adjust the controller
Operating instruction
Attention
3. Adhere it to the surface
4. Power on
Alza.cz a.s., Jankovcova 1522/53, 170 00 Praha 7,
Czech Republic www.alza.cz
Importer:
Manufacturer:
Guangzhou Linong Lighting Technology Co.,Ltd.
Keying Rd,Guangzhou Sci-Tech Industry Park, Baiyun
District,Guangzhou,China.
