Altec Lansing SLC408 CEILING SPEAKER Manuel utilisateur

For the past twenty-five years, Altec Lansing’s CD408 has been one of the

most highly specified and installed professional-grade ceiling speaker in the

world. With the model SLC408-16T, Altec Lansing introduces the king of all

premium 8” Duplex high fidelity ceiling speakers in a preassembled, quick-

mount package.

The SLC408-16T features a sensitivity rating of 98 dB SPL and a 16 watt

premium grade transformer. This means that our 4 watt tap delivers output

equal to the 30 watt tap from a ceiling speaker rated at 89 dB SPL. At the

16 watt tap, the SLC408-16T generates 110 dB SPL (@ 1 m). In a high ceiling

installation, no other 8” Duplex®ceiling speaker performs better than the

SLC408-16T.

When clients demand the absolute best in high fidelity, intelligibility and

efficiency, choose the industry’s premier eight-inch Duplex®ceiling speaker.

The SLC408-16T has no competition. It’s simply the best.

Simply the

Best

www.altecpro.com

SLC408-16T HIGH OUTPUT, HIGH EFFICIENCY

PREASSEMBLED CEILING SPEAKER SYSTEM

• HIGH EFFICIENCY CD408-16T 8” / 200 MM 32 W DUPLEX®COMPONENT INSTALLED

IN A ROUND, METAL ENCLOSURE. THREE DOGLEG ARMS SWING OUT AND

ANCHOR THE ENCLOSURE TO THE METAL TILE BRIDGE AS YOU SCREW-

TIGHTEN THE ASSEMBLY.

• A FIVE POSITION SWITCH LOCATED ON THE FRONT BAFFLE ALLOWS

SELECTION OF THE 16 W, 8 W, 4 W, 2 W OR 8 ΩTAPS.

• ALTEC’S PREMIUM 16 W 70 V/100 V TRANSFORMER HAS A BROADBAND

INSERTION LOSS RATING OF < .6 DB FROM 50 HZ – 15 KHZ.

• AN OFF-WHITE MATTE FINISH METAL DECORA GRILLE FITS SNUGLY INTO

THREE SLOTTED HOLES IN THE FRONT BAFFLE.

• THE METAL ENCLOSURE HAS A STRAIN RELIEF TAB ON THE TOP TO MEET

EARTHQUAKE REQUIREMENTS.

• A MOUNTING CONNECTOR ON THE TOP OF THE ENCLOSURE ALLOWS FOR EASY

MATING TO FLEX OR METAL CONDUIT.

• YOUR INSTALLERS WILL APPRECIATE THE METAL TILE BRIDGE, WHICH SERVES AS A

TEMPLATE FOR CUTTING THE PROPER SIZE HOLE IN THE CEILING TILE.

• SHIPS IN PAIRS

PROFESSIONAl

SLC408 SELL SHEET R01

SLC408-16T HIGH OUTPUT, HIGH EFFICIENCY PREASSEMBLED CEILING SPEAKER SYSTEM

With broadband sensitivity of 98 dB SPL and a peak

of 104 dB SPL at 2 kHz (the intelligibility

frequency), the SLC408-16T is your best choice for

high ceiling applications. The +10 dB to +12 dB

sensitivity advantage lets you use the 4 watt tap to

generate the same output as the competition’s 30

watt tap, allowing you to downsize the amplifier

channel on each zone of ceiling speakers.

Technical Specifications

FREQUENCY RESPONSE: 82 Hz – 16 kHz (+/- 5dB)

USABLE LOW FREQUENCY LIMIT: 66 Hz (@ -10dB)

SENSITIVITY: 98 dB SPL @ 1 W / 1 m

POWER HANDLING: 32 W AES, 128 W peak

PEAK OUTPUT: 119 dB SPL @ 128 W, 110 dB SPL @ 16 W transformer limited

IMPEDANCE: Nominal – 8 Ω, Minimum – 7.8 Ω

CROSSOVER FREQUENCY: 2,500 Hz

TRANSFORMER: 16 W 70 V / 100 V premium transformer with taps @ 16 W, 8 W,

4 W & 2 W rated at < .6 dB insertion loss from 50 Hz – 15 kHz

FINISH: Enclosure Black Painted Steel with internal damping material

Grille Matte White Decora Round Metal Grille

DIMENSIONS: Enclosure 9.25" diameter x 7.85" deep (235 mm x 199.4 mm)

Grille 12.75" diameter (323.9 mm)

NET WEIGHT: With grille mounted, each 9.8 lbs. / 4.45 kg

SHIPPING WEIGHT: Per Pair 34.3 lbs. / 15.56 kg

1000 W. Wilshire Blvd., Suite 362, Oklahoma City, OK 73116 U.S.A.

Tel. 405-848-3108 / Fax. 405-848-3217 / [email protected] /

www.altecpro.com

Visit www.altecpro.com to download the data sheet on the SLC308-8T (PDF

format), authorized EASE®measurements and A&E Specifications (DOC file).

PROFESSIONAl
