Alpha Antenna ProMaster Manuel utilisateur

Page 1

AlphaAntenna



Model‐ProMaster



6‐160Meters



1KW



Portable/Base



AlphaProMasterAntenna



USER GUIDE

V1.2

July 11, 2013

Page 2

Introduction

Thank you for purchasing the Alpha ProMaster Antenna, a complete 1KW

deployment system including antenna system, tripod, & mount for Portable or

Temporary Emergency Deployment, Field Operations, Apartment/Condo

Residents, or HOA's.

The heavy duty whip plus the additional radiating elements provide you with a

total combined length of a ¼ wave 160 meter antenna system. The Alpha

ProMaster Antenna is engineered with an 6 ½ foot tripod that is made out of

aluminum, which is designed to be your counterpoise system and includes a

standard SO239 mount where for the Alpha Match, under which you simply

attach your coax.

Frequency Coverage - 6 through 160 Meters



Technical Specifications

Weight: 4 pounds

Configuration: Quad “L” configuration

Frequency Coverage: 1.8 to 55 MHz

Power Rating: 1KW PEP

Height: Approximately 17 Feet with tripod

Horizontal element/guy wire: Approximately 30 Feet each

Page 3

Installation Safety

WARNING: INSTALLATION OF THIS PRODUCT NEAR POWER LINES IS

DANGEROUS! FOR YOUR SAFETY, FOLLOW THE ENCLOSED

INSTALLATION DIRECTIONS. THOUGH THIS ANTENNA IS CONSTRUCTED

OF INSULATED WIRE, PROPER CARE MUST

BE TAKEN DURING INSTALLATION. INSTALLER ASSUMES ALL LIABILITY

FOR PROPERTY AND LIFE SAFETY.

YOU, YOUR ANTENNA, AND SAFETY

Each year, hundreds of people are killed, mutilated, or receive severe and

permanent injuries when attempting to install an antenna. In many of these

cases, the victim was aware of the danger of electrocution, but did not take

adequate steps to avoid the hazard. For your safety, and to help you achieve a

good installation, please READ and FOLLOW the safety precautions below.

THEY MAY SAVE YOUR LIFE!

1. If you are installing an antenna for the first time, please, for your own safety as

well as others, seek PROFESSIONAL ASSISTANCE.

2. Select your installation site with safety, as well as performance, in mind.

(Detailed information in Site Selection appears in a separate section of this

booklet.) REMEMBER: ELECTRIC POWER LINES AND PHONE LINES LOOK

ALIKE. FOR YOUR SAFETY, ASSUME THAT ANY OVERHEAD LINES CAN

KILL YOU.

3. Call your electric power company. Tell them your plans and ask them to come

take a look at your proposed installation. This is a small inconvenience,

considering YOUR LIFE IS AT STAKE.

4. Plan your installation procedure carefully and completely before you begin.

Successful raising of a mast or tower is largely a matter of coordination. Each

person should be assigned a specific task, and should know what to do and

when to do it. One person should be designated as the leader/coordinator of the

operation to call out instructions and watch for signs of trouble.

5. When installing your antenna, REMEMBER: DO NOT USE A METAL

LADDER. DO NOT WORK ON A WET OR WINDY DAY. DO DRESS

PROPERLY: shoes with rubber soles and heels, rubber gloves, long sleeved

shirt or jacket.

6. If the assembly starts to drop, get away from it and let it fall. Remember, the

antenna, mast, cable and metal guy wires are all excellent conductors of

electrical current. Even the slightest touch of any of these parts to a power line

completes an electrical path through the antenna and the installer – THAT’S

YOU!

7. If ANY PART of the antenna system should come in contact with a power line,

DON’T TOUCH IT OR TRY TO REMOVE IT YOURSELF. CALL YOUR LOCAL

POWER COMPANY. They will remove it safely. If an accident should occur with

the power lines, call for qualified emergency help IMMEDIATELY.

Page 4

Antenna Installation

Step 1 – On the tripod

loosen leg brace knob,

extend legs, and slightly

tighten leg brace knob

Step 2 – Mount tripod on a

flat stable surface

Step 3 – Fully extend the

horizontal wire elements

and secure them with the

included stakes

Step 4 – Assemble then

screw the whip into the

tripods mount

Step 5 – Attach the Alpha

Match to the bottom of the

tripods mount

Step 6 – Attach your coax to

the SO-239 on the Alpha

Match

NOTE – Additional Radials or Counterpoise wires should not be used with the

antenna system. All components of the antenna system are designed to exacting

standards for high performance, including the tripod, which is designed to be

your counterpoise system. We advise that you guy the antenna system with the

included radiating elements.

Page 5

SWR Performance

SWR results may vary; however, you can expect an SWR from 1.1:1 to 2.7:1 on

6-160 Meters when properly deployed. An additional antenna tuner may be used

to lower SWR is desired.

Page 6

Have Other Questions?



If you have questions about your antenna, please feel free to contact us.



Support



Email: [email protected]

Phone: 1‐888‐482‐3249

WEB: www.alphaantenna.com

Page 7

NOTES

Page 8

http://www.AlphaAntenna.com
