ALIGATOR Double Chamber System Manuel utilisateur

Aligator Owners Operator Manual

ALIGATOR MANUAL

For Swimming Pools

Congratulations, you are the owner of the most advanced swimming pool water

purification in the world. Used correctly, it will make your swimming a much

healthier exercise and a less costly one for many years to come.

This booklet should be used as a reference book, and as such, should be kept in a

water proof wallet in or near the pump room. It is designed to assist you to make the

very most out if your unit, and we have attempted to cover most eventualities you

may encounter with the operation of your pool. If in the unlikely event you do need

further assistance please do not hesitate to contact us at the address below.

Aligator Systems

243 Berechurch Hall Road

Colchester

Essex

CO2 9NP

(01206) 543485

Email: [email protected]

www.aligator.co.uk

Aligator Owners Operator Manual

CONTENTS

Part One

Aligator Control Unit

Principles of Operation

Power and Electrode Connections

LCD Displays

Programming Aligator

Part Two

Electrode Chamber

Replacement of Electrodes

Part Three

Pool Water Preparation

Chemical Correction Tables

Flocculants And Algaecides

Vacuuming and Backwashing

Chlorine Types

Chlorine Levels

Shock Treatment

Cyanuric Acid Levels

Test Kits

Winterisation of Outdoor Pools

Aligator Owners Operator Manual

PART ONE

Aligator Control Unit

Type ali-2

INTRODUCTION

PRINCIPLES OF OPERATION

The unit is managed, timed and controlled by a single chip microprocessor. Permanent

storage is provided by an industry standard Electrically Erasable Programmable Memory.

User control is provided by three simple push buttons, one for display mode change and the

other two for ON/OFF or UP/DOWN as appropriate. The display is a 20 character by 2 row

LCD display with backlight for operation in any location.

Power and electrode connections

The unit is designed to be connected to a permanent power supply 220/240 volts, via the

mains plug. The mains supply should not be timed or interrupted. The unit should be

mounted on the wall within 2 metres of the filter and pump.

The unit is designed to come on twice in a twenty four hour cycle for a time dependant on the

size of your pool. The user must thus set his pump operating time to suit the times in the table

shown under Pool Size Setting display below. Failure to do this will reduce the electrode

operating times and reduce the efficiency of the unit.

The control unit is connected to the electrodes via the grey four core cable. This cable has

four plugs. Two for the electrodes and two for the flow switch, both of which are situated in

the electrode chamber. Identification is simple as both pairs of plugs are distinctly different.

Polarity of either the electrodes or the flow switch is unimportant so the plugs can be fitted

either way.

The unit will operate as soon as power has been established to it and the Pool Size entered

into its computer. However, power to the electrodes will only operate when pump is on.

Electrode timing always starts when the pump starts unless the pump has been off for less

than 30 minutes e.g. for filter cleaning (or automatically after 12 hours if the pump is

continuous).

LCD DISPLAYS

On power-up the unit will display “Welcome to Aligator” for 10 seconds during which time

the electrodes will be off and the electrode current detection circuit will automatically zero

itself.

The first normal screen shown below is then displayed. Changing to other display modes is

achieved by pressing the MODE switch, each time the switch is pressed the screen advances

one display. This allows cycling right round all the screen operations. If the switch is not used

for more than 10 seconds then the unit reverts automatically to the default display (screen one)

electrode current display mode.

Aligator Owners Operator Manual

Electrode Current & Alarm

The first normal and default display is as follows:

Current: 82mA OK

Current Alarm: ON

Actual current into the electrodes will be displayed, dependant upon your pool setting.

Should the “OK” be replaced by “LOW” or “HIGH” the alarm will be activated, the red LED

will flash and the unit will “beep” this indicates that either the pool water balance or the

electrodes need attention.

The alarm can be switched off by pushing the bottom right hand button or back on by pushing

the top right hand button.

NOTE: Current Alarm reverts to ON at end of 12 hours

Pool Size Setting

The second display shows what pool size has been selected from the table below, i.e. the size

of your pool, for example:-

POOL Ltrs 9-27000

SIZE Gals 2-6000

The Top right hand button increases Pool Size from size 1 to 6.

The Bottom right hand button decreases Pool Size from size 6 to 1

The Alternative options are shown below for various pool sizes.

On Hours for 12 Hour period

LCD Display Size Summer Winter

9 – 27700’ Ltrs

2 – 6000’ Gals

27 – 50000’ Ltrs

6 – 110000’ Gals

50 – 70000’ Ltrs

11 – 160000’ Gals

70 – 100000’ Ltrs

16 – 22000’ Gals ****

100 – 50000’ Ltrs

22 – 340000’ Gals ****

150 – 200000’ Ltrs

34 – 45000’ Gals ****

NOTE: The large pool sizes noted above as **** requires the larger Aligator unit and cannot

operate with the normal domestic unit.

Aligator Owners Operator Manual

Summer/Winter Setting

The third display is as shown below with ON/OFF as appropriate, timing effects are as

detailed below:

Summer Timing: OFF

Winter Timing: ON

The Top right hand button sets Summer ON and Winter OFF

The Bottom right hand button sets Winter On and Summer OFF

Language Setting

The fifth display is as shown below with language as selected:

Language: English

The top and bottom right hand buttons allow you to select a language.

English

French

Spanish

Elapsed Times Display

The sixth display is as shown below with Elapsed Hours as appropriate:

(NOTE: Elapsed times are

Electrodes Pump Total

000000 000000 000000

The hours shown are the total hours the electrodes have worked, the pump has worked and

finally the total hours the power has been connected to the unit.

Aligator Owners Operator Manual

PART TWO

ELECTRODE CHAMBER

The chamber must be fitted between the pump and the filter. The flow switch is

activated by the flow of water pushing it upwards; this indicates to the control unit that

the pump is operating. Once the flow ceases the flow switch falls by gravity back

between the electrodes. It is therefore of utmost importance that the chamber is fitted to

allow this action to take place.

Access to the chamber is by unscrewing the top flange and gradually easing out the top

transparent lid with a screw driver. A rubber “O” ring situated around the base of the lid

creates the seal. Once the lid is removed the electrodes can be replaced by releasing the 10mm

stainless steel bolts securing them through the lid. Make sure on replacing the electrodes, the

rubber seal is placed against the lid underface followed by the stainless steel threaded nut then

the electrode. Electrodes can be cleaned by simply removing the lid and wiping the electrodes

with a cloth. On replacing the lid, make sure the location lugs are in line before pushing the

lid into the chamber.

Electrodes

Electrodes are a composition of a number of metals. Under good pool management i.e.

keeping the balance of the water within range, the electrodes will last up to 12 months. The

correct wear pattern should be progressive reduction in the diameter until the electrode is

slightly more than the width of a pencil. At this point they should be replaced.

Replace the electrodes only with genuine Aligator Electrode Kits.

If other types are used the result will be a reduction in sanitation and possible staining of the

pool walls.

Aligator Owners Operator Manual

PART THREE

Water Preparation

Test Pool Water and bring to ideal levels:

*pH 7.0 to

7.4

*Alkalinity 90 to

150

*Chlorine 1.2 to

1.5ppm (start up)

*Chlorine 0.6 to

1.0ppm (Normal Operation)

*Cyanuric 40 to

60ppm (No Higher than 80ppm)

Please Note: IMPORTANT

Please Refer to Page 10 of this Handbook

DO NOT POUR CHLORINE GRANULES INTO THE SKIMMER IF YOUR POOL

IS FITTED WITH AN AUTOMATIC CHLORINATOR.

PLEASE REFER TO YOUR AGENT OR TO ALIGATOR FOR FURTHER

ASSISTANCE.

STABILISED CHLORINE MUST NOT UNDER ANY CIRCUMSTANCES BE

MIXED WITH UNSTABILISED CHLORINE.

Cyanuric

Is a stabilising compound used to stabilise chlorine against dissipation by sunlight. If the level

is above 80ppm it must be reduced by dumping water and adding fresh until you have

acquired the correct level. It is advisable not to use stabilised chlorine in indoor pools.

Chemical Tables for stabilising your pool water

WARNING: Do not mix chemicals together. Mixing chemicals causes Fire, Explosion

and Toxic fumes.

Aligator Owners Operator Manual

The chemical quantities are approximate. Use them as a guide until you have established the

correct amount for your pool.

To establish the size of your pool

Apply the following calculation. This will give you a reasonably accurate indication.

Measure in Meters/

Length x Width x Depth x 1000 = Volume in litres i.e. 10m x 5m x 1.5m x 1000 = 75000 ltrs

To convert to gallons multiply by 0.22. I.e. 750000 x 0.22 = 16500 Gals

pH CORRECTION

Correct Reading 7.0 to 7.4

High Reading Use Dry Acid (Sodium Bisulphate) to reduce pH Reading

pH Reading

Size of Pool 7.6 7.8 8.0 8.2

50000 litre 11000 gals 300 Gram 600 Gram 900 Gram 1.2 kg

75000 litre 16000 gals 600 Gram 900 Gram 1.2 kg 1.5 kg

100000 litre 22000 gals 900 Gram 1.2 kg 1.5 kg 1.8 kg

125000 litre 28000 gals 1.2 kg 1.5 kg 1.8 kg 2.1 kg

Application Method:

Set pump on FILTER. Mix dry acid in bucket of water, pour contents around the deep end of

the pool. Extreme care should be taken when handling Acid.

For low reading use Sodium Bi-Carbonate (Bi-Carb of Soda) to increase pH.

Size of Pool pH Reading 6.8

50000 litre 11000 gals

500 Gram

75000 litre 16000 gals

750 Gram

100000 litre 22000 gals

1.0 Kg

125000 litre 1.25 Kg

1.25 Kg

Application Method:

Set pump on Bypass/Circulate, pour Bi-Carb slowly down the leaftrap/skimmer.

Do not administer Bi-Carb with the pump set on filter.

Aligator Owners Operator Manual

ALKALINITY CORRECTION

Correct Reading 90 to 140ppm

Use Dry Acid (Sodium Bisulphate) to decrease

Test Reading of Alkalinity

Size of Pool 250 220 200 180

50000 litre 11000 gals 2kg 1kg 750g 500g

75000 litre 16000 gals 4kg 3kg 2kg 1kg

100000 litre 22000 gals 6kg 5kg 4kg 3kg

125000 litre 28000 gals 8kg 7kg 6kg 5kg

Application Method:

Mix small amounts in a bucket of water and pour around the deep end of pool with the pump

set on filter. Do not mix more than 1kg at a time in an average size bucket. Care is needed as

the acid id very corrosive and any spillage should be diluted with water without delay.

Use Bi-Carb of Soda to Increase

Test Reading of Alkalinity

Size of Pool 80 60 40 30

50000 litre 11000 gals 2kg 3kg 4kg 5kg

75000 litre 16000 gals 3kg 4kg 5kg 6kg

100000 litre 22000 gals 4kg 5kg 6kg 7kg

125000 litre 28000 gals 5kg 6kg 7kg 8kg

Application Method:

Set pump multiport on RECIRCULATE ONLY, pour slowly and directly into the

leaftrap/skimmer. Leave pump on RECIRCULATE ONLY until all traces of the chemical

have entered the pool.

DO NOT ATTEMPT TO PUT BI-CARB INTO THE SKIMMER WITH THE PUMP

ON FILTER.

When correcting the stabilisation of the pool using the above chemicals, test after 24

hours and readjust as necessary.

Aligator Owners Operator Manual

IMPORTANT: When adding large amounts of acid to decrease the Alkalinity, the pH

will be reduced to a very low level. The pH will slowly increase over the next ten days as

the Alkalinity is reducing. This is normal and will not harm your pool, it is however not

recommended to swim in water below 6.5.

Flocculants and Algaecides

Neither of these substances are needed with Aligator. Aligator will kill all known algae and

through its own unique magnetic field, remove most unwanted solids from the water. With

stubborn algae ALI-CIDE may be used.

Vacuuming and Backwashing

During the first two weeks, frequent vacuuming and backwashing must be done to clear away

the residue of solids being solidified by the action of the Aligator. This action makes the

water crystal clear. After a period, depending on how contaminated the water was before the

Aligator was fitted, the vacuuming and backwashing may be resumed at the normal

frequency. Visual inspection of the bottom of the pool showing no solids present indicates

this situation. A frequent vacuuming and backwashing policy however, is absolutely essential

for the good management of your pool.

Chlorine and Cyanuric/Cyanurates

There are Four (4) main donors of Chlorine.

Two are hypo-chlorites, Liquid and Granular, commonly called Chlorine.

Two are known as Stabilised Chlorine, (Granular or Tablet) these are Cyanuric and

Cyanurate.

Their Chemical names are very long so our description will suffice for this booklet.

Stabilised Chlorine is used to minimise the loss of Chlorine in sunlight and therefore is to b

recommended in outdoor pools.

Chlorine (Non Stabilised) is used in indoor pools with artificial lighting.

Stabilised Chlorine in tablet form. We recommend the slow dissolving (200g) tablet

(dissolves in 5 to 7 days) in outdoor pools and also indoor pools where sunlight penetrates the

water.

IMPORTANT: Whenever Stabilised chlorine is used, the Cyanuric Acid level must be

monitored and kept below 80ppm.

(See paragraph headed Cyanuric/Stabilised Chlorine for more information).

DO NOT MIX STABILISED CHLORINE WITH NON STABILISED

CHLORINE EXPLOSION MAY RESULT.

Ce manuel convient aux modèles suivants

Table des matières

Manuels Équipement d'éclairage populaires d'autres marques

Brizo

Brizo 8SP-MU-4 Manuel utilisateur

LUCE&LIGHT

LUCE&LIGHT BROM 1.0 Manuel utilisateur

IKEA

IKEA BJÖRKSPIREA Manuel utilisateur

Laserworld

Laserworld Evolution Series ES-400RGB Manuel utilisateur

Alien

Alien RG STAR Manuel utilisateur

EuroLite

EuroLite LED B-40 Manuel utilisateur

Qazqa

Qazqa Suplux SL 3 Black 103062 Manuel utilisateur

Commercial Electric

Commercial Electric 54568141 Manuel utilisateur

CREE LIGHTING

CREE LIGHTING 304 Series Manuel utilisateur

Goobay

Goobay 49867 Manuel utilisateur

ECOMAN ITALIA

ECOMAN ITALIA LED T8 Manuel utilisateur

Alkalite

Alkalite Krypton KT-81 Manuel utilisateur

Clas Ohlson

Clas Ohlson GU10 Manuel utilisateur

DTS

DTS DELTA 10 F Manuel utilisateur

ring

ring Solar Steplight Manuel utilisateur

One Stop Gardens

One Stop Gardens 57696 Instructions de montage

Chauvet DJ

Chauvet DJ COREpar UV120 ILS Manuel utilisateur

SIREM

SIREM Swimeo A2 Manuel utilisateur
