ALIBI ALI-NP7022RT Manuel utilisateur

ALI-NP7022RT 2.1 MP 25x Low Light

IP PTZ Camera Installation Guide

PLEASE READ THIS MANUAL BEFORE USING YOUR CAMERAS, and always follow the instructions for safety

and proper use. Save this manual for future reference.

ALI-NP7022RT_CM

180904

CAUTION

FCC Caution: To assure continued compliance, use only shielded interface cables when connecting to computer or

peripheral devices. Any changes or modications not expressly approved by the party responsible for compliance could

void the user’s authority to operate this equipment.

NOTE

This equipment has been tested and found to comply with the limits for a Class “A” digital device, pursuant to Part 15

of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the

equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio

communications.

LEGAL NOTICE

Observint Technologies (Observint) products are designed to meet safety and performance standards with the use of

specic Observint authorized accessories. Observint disclaims liability associated with the use of non-Observint

authorized accessories.

The recording, transmission, or broadcast of any person’s voice without their consent or a court order is strictly

prohibited by law.

Observint makes no representations concerning the legality of certain product applications such as the making,

transmission, or recording of video and / or audio signals of others without their knowledge and / or consent.

We encourage you to check and comply with all applicable local, state, and federal laws and regulations before

engaging in any form of surveillance or any transmission of radio frequencies.

ALIBI and the ALIBI logo are trademarks of Observint.

Microsoft, Windows, and Internet Explorer are either registered trademarks or trademarks of Microsoft Corporation in

the United States and / or other countries.

Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks

and names or their products. Observint disclaims any proprietary interest in trademarks and trade names other than

its own.

No part of this document may be reproduced or distributed in any form or by any means without the express written

permission of Observint, Inc.

11000 N. Mopac Expressway, Building 300, Austin, TX 78759

For Sales and Support, please contact your distributor.

iiiALI-NP7022RT IP PTZ Camera Installation Guide

SAFETY INSTRUCTIONS

Regulatory information

FCC information

FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the

FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated

in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used

in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment

in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his

own expense.

FCC conditions

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may cause undesired operation.

Preventive and Cautionary Tips

Before connecting and operating your cameras, please be advised of the following:

• Ensure environmental conditions meet factory specications.

• Major shocks or jolts to the unit as a result of dropping it may cause damage to the sensitive electronics within the unit.

• Use the device in conjunction with an UPS if possible.

Safety Instructions

These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss.

The precaution measure is divided into Warnings and Cautions:

• Warnings: Neglecting any of the warnings may cause serious injury or death.

• Cautions: Neglecting any of the cautions may cause injury or equipment damage.

Warnings

• All electronic operation should be strictly in compliance with the electrical safety regulations, re prevention regulations and

other related regulations in your local region.

• Do not connect several devices to one power adapter as adapter overload may cause high heat or re hazard.

• Please make sure that the power was disconnected before you wire, install or dismantle the camera.

• If smoke, odors or noise rise from the device, shut o the power immediately and unplug the power cable. Please contact the

service center for assistance.

• If the product does not work properly, please contact your dealer or the nearest service center. Never attempt to disassemble

the speed dome yourself. (We shall not assume any responsibility for problems caused by unauthorized repair or

maintenance.)

Cautions

• Do not drop the dome or subject it to physical shock, and do not expose it to high electromagnetism radiation. Avoid the

equipment installation on vibrations surface or places subject to shock (ignorance can cause equipment damage).

• Do not place the dome in extremely hot, cold, dusty or damp locations, otherwise re or electrical shock will occur. The

operating temperature should be -40 °F ~ 149 °F (-40 °C ~ 65 °C).

• The dome cover for indoor use shall be kept from rain and moisture.

• Exposing the equipment to direct sun light, low ventilation or heat source such as heater or radiator is forbidden (ignorance can

cause re danger).

• Do not aim the speed dome at the sun or extra bright places. A blooming or smear may occur otherwise (which is not a

malfunction however), and aecting the endurance of sensor at the same time.

• Please use the provided glove when open up the dome cover, avoid direct contact with the dome cover, because the acidic

sweat of the ngers may erode the surface coating of the dome cover.

• Please use a soft and dry cloth when clean inside and outside surfaces of the dome cover, do not use alkaline detergents.

• Please keep all packaging for future use. In case of a failure, use the original packaging to return the camera to the factory.

Transportation without the original packaging may result in damage to the camera and incur additional costs.

Read these instructions and keep them in a safe place for future reference.

• Please refer all work related to the installation of this product to qualied service personnel or system installers.

• Do not operate the camera outside of its specied temperature, humidity or power source ratings.

• Install the unit away from heat sources such as radiators, heat registers and stoves.

• Installation of the unit near consumer electronics devices, such as stereo receiver / ampliers and televisions, is permitted as

long as the air surrounding the terminal does not exceed the above mentioned temperature range.

• Handle the camera with care. Do not drop or shake, as this may damage it.

• Do not use strong or abrasive detergents when cleaning the surfaces of this product. When dirt is hard to remove, use a mild

detergent and wipe gently.

• Save your system conguration.

• Distributing, copying, disassembling, reverse compiling, reverse engineering, and exporting, in violation of export laws, the

software provided with this product is expressly prohibited.

vALI-NP7022RT IP PTZ Camera Installation Guide

TABLE OF CONTENTS

Table of Contents

SECTION 1 Overview ..........................................................................1

1.1 Features ............................................................................1

1.2 What’s in the box ....................................................................3

1.3 Accessories..........................................................................3

SECTION 2 Installation ........................................................................9

2.1 Remove the camera from the packaging.................................................9

2.2 Install an micro-SD card in the camera .................................................10

2.3 Camera wall mount installation .......................................................10

2.3.1 Connecting the cables...........................................................12

2.4 Ceiling mounting ...................................................................14

SECTION 3 Congure Network Access ...........................................................17

3.1 Install the Alibi CongTool ...........................................................17

3.2 Activate Inactive Alibi device..........................................................18

3.3 Modify Network Parameters ..........................................................19

SECTION 4

Remote login 22

4.1 Additional conguration steps ........................................................25

APPENDIX A Specications .....................................................................26

APPENDIX B Denitions........................................................................29

APPENDIX C Lightning and Surge Protection ......................................................31

APPENDIX D 24Vac Wire Gauge and Transmission Distance ..........................................32

NOTES

1ALI-NP7022RT IP PTZ Camera Installation Guide

SECTION 1: OVERVIEW

SECTION 1

Overview

Congratulations on purchasing your new ALIBI™ IP PTZ Low Light camera! This installation guide includes procedures for installing

and performing the initial setup of the camera.

The ALI-NP7022RT IP PTZ Camera can capture high quality images in very low light environment with its black anti-reective glass.

The black anti-reective glass increase the luminousness for an IR reach of up to nearly 655 feet. With the 25× optical zoom Day

/ Night lens, the camera oers more details over expansive areas. This camera also features a wide range of functions, including

intrusion detection, line crossing detection and audio exception, benetting users with great improvement on security eciency,

more importantly, with key events / objects being recorded for further forensic needs.

Mounting

bracket

coupling

Top cover

(drop cables inside)

Safety cable

Cover for SD card,

and Reset button

Dome drive

Lens

1.1 Features

Basic functions

• 1/1.9” progressive scan CMOS sensor, up to 1920 x 1080 resolution

• ONVIF (Open Network Video Interface Forum), CGI (Common Gateway Interface), PSIA (Physical Security Interoperability

Alliance), to ensure greater interoperability between dierent platforms and compatibility

• Min. Illumination

Color: 0.002 Lux @ (F1.5, AGC ON)

B/W: 0.0002 Lux @(F1.5, AGC ON)

0 Lux with IR

• 25× optical zoom, 16× digital zoom

• 655 foot IR range

• 24 Vac and Hi-PoE powering

• H.265+ / H.265 video compression

• IP66 compliant, IK10 compliant, TVS 6,000V Lightning Protection, Surge Protection and Voltage Transient Protection

• Smart video analysis features include Intrusion Detection, Line Crossing Detection, Region Entrance Detection, Region Exiting

Detection, Face Detection, Audio Exception Detection

• Recording: edge recording, support smart search in smart NVR

• Support low bit rate, ROI

• Auto iris, auto focus, auto white balance, backlight compensation and auto day & night switch

• Supports 8 privacy masks

PTZ function:

• 360° endless pan range and -20° ~ +90° tilt range

• Pan speed congurable, from 0.1° / s to 210° / s, Preset Speed: 280° / s

• Tilt speed congurable from 0.1° / s to 150° / s, Preset Speed: 250° / s

• 300 programmable presets; preset image freezing capability

• 8 patrols, up to 32 presets per patrol

• 4 pattern scans with up to 10 minutes per scan

Network function:

• H.264 / MJPEG video compression and the latest processing chip and platform

• Support Micro SD card local storage, up to 256GB

• Support up to 8 NAS storage; transmit videos from the SD card to the NAS after network recovery

• HTTPS encryption and IEEE 802.1X port-based network access control

• Support dual-stream; H.264 / MJPEG video compression; basic and advanced video conguration; real time video at 1080P

• Multiple network protocols supported: IPv4/IPv6, HTTP, HTTPS, 802.1X, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP,

RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE

• 1 audio input and 1 audio output

• Audio encryption G.711alaw / G.711ulaw / G.722.1 / G.726 / MP2L2 / PCM

• 2 alarm inputs and 1 alarm output, alarm linkage support preset, patrol, pattern, recording, relay output, upload center, etc.

SECTION 1: OVERVIEW

3ALI-NP7022RT IP PTZ Camera Installation Guide

SECTION 1: OVERVIEW

1.2 What’s in the box

Your camera includes:

• PTZ camera assembly

• Ethernet drop cable seal kit

• Hi-Power PoE injector

• Safety cable handle (red)

• Gloves

• Hex L-wrench

• Thread tape

• Quick installation guide (this document)

1.3 Accessories

The following accessories are available for the ALIBI ALI-NP7022RT camera. Mounting bracket detail is shown below.

Model Type

ALI-PTZCL Ceiling Mount Bracket

ALI-PTZCM Corner Mount PTZ Bracket

ALI-PTZPM Pole Mount PTZ Bracket

ALI-PTZWB Wall Mount Bracket

ALI-PTZWBJ Outdoor PTZ Wall Bracket with Junction Box

ALI-PTZCL: Ceiling Mount Bracket

The Ceiling Mount Bracket is suitable for outdoor ceiling mounting.

3.52"dia.

0.39"dia. (4)

2.24"

4.57"dia.

SECTION 1: OVERVIEW

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels ALIBI Caméra de sécurité

ALIBI

ALIBI ALI-NS8014VR Manuel utilisateur

ALIBI

ALIBI ALI-NS4036R Manuel utilisateur

ALIBI

ALIBI ALI-NP3012RH Manuel utilisateur

ALIBI

ALIBI ALI-NS4114R Manuel utilisateur

ALIBI

ALIBI ALI-TP7012RH Manuel utilisateur

ALIBI

ALIBI ALI-IPV3113R Manuel utilisateur

ALIBI

ALIBI ALI-TS2025R Manuel utilisateur

ALIBI

ALIBI ALI-CD1720PVF Manuel utilisateur

ALIBI

ALIBI ALI-TS4115R Manuel utilisateur

ALIBI

ALIBI ALI-NP1013VRH Manuel utilisateur

ALIBI

ALIBI ALI-NS2018VR Manuel utilisateur

ALIBI

ALIBI ALI-BC700G Manuel utilisateur

ALIBI

ALIBI ALI-NS1008HDMI Manuel utilisateur

ALIBI

ALIBI ALI-BC1720EC Manuel utilisateur

ALIBI

ALIBI ALI-TS1112R Manuel utilisateur

ALIBI

ALIBI ALI-NS8024VR Manuel utilisateur

ALIBI

ALIBI ALI-NS4022R Manuel utilisateur

ALIBI

ALIBI ALI-TP4013R 3MP HD-TVI 260' IR Manuel utilisateur

ALIBI

ALIBI ALI-NS1044VR Manuel utilisateur

ALIBI

ALIBI ALI-PTZ30XR Manuel utilisateur

ALIBI

ALIBI ALI-NS4114L Manuel utilisateur

ALIBI

ALIBI ALI-NS1012VRP Manuel utilisateur

ALIBI

ALIBI ALI-TS2018VR Manuel utilisateur

ALIBI

ALIBI ALI-TP3005L Manuel utilisateur

Manuels Caméra de sécurité populaires d'autres marques

Okina USA

Okina USA SIR36-870VF650LP Manuel utilisateur

Divio

Divio NDR155PA Manuel utilisateur

Canon

Canon VB-C500D Manuel utilisateur

Easy Access

Easy Access EasyGuard Manuel utilisateur

Vivotek

Vivotek FD9389-EHV-v2 Manuel utilisateur

TUYA

TUYA COSMO W2 Manuel utilisateur

Eusso

Eusso UNC7500-IR Guide de configuration

urmet domus

urmet domus 1096/204 Manuel utilisateur

VC VC20 series Manuel utilisateur

Axis

Axis Q1614 Manuel utilisateur

ieGeek

ieGeek DD201 Manuel utilisateur

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manuel utilisateur

Vicon

Vicon V662-D-1 Mode d'emploi

Grundig

Grundig GCH-K0274P Manuel utilisateur

Lorex

Lorex VANTAGE LBC7032 Manuel utilisateur

4xem

4xem WPT Manuel utilisateur

Samsung

Samsung SCV-3082 Manuel utilisateur

Vitek

Vitek VTC-C544 Manuel utilisateur
