ALGE-Timing OPTIc2 Manuel utilisateur

Version-E160712

Manual

with Software OPTIc2.NET

Manual

Photo Finish OPTIc2.NET

Page 2

Important Information

General

Before using your ALGE-TIMING device read the complete manual carefully. It is part of the device and

contains important information about installation, safety and its intended use. This manual cannot cov-

er all conceivable applications. For further information or in case of problems that are mentioned not at

all or not sufficiently detailed, please contact your ALGE-TIMING representative. You can find contact

details on our homepage www.alge-timing.com

Safety

Apart from the information of this manual all general safety and accident prevention regulations of the

legislator must be taken into account.

The device must only be used by trained persons. The setting-up and installation must only be exe-

cuted according to the manufacturer’s data.

Intended Use

The device must only be used for its intended applications. Technical modifications and any misuse

are prohibited because of the risks involved! ALGE-TIMING is not liable for damages that are caused by

improper use or incorrect operation.

Power supply

The stated voltage on the type plate must correspond to voltage of the power source. Check all con-

nections and plugs before usage. Damaged connection wires must be replaced immediately by an

authorized electrician. The device must only be connected to an electric supply that has been installed

by an electrician according to IEC 60364-1. Never touch the mains plug with wet hands! Never touch

live parts!

Cleaning

Please clean the outside of the device only with a smooth cloth. Detergents can cause damage. Never

submerge in water, never open or clean with wet cloth. The cleaning must not be carried out by hose

or high-pressure (risk of short circuits or other damage).

Liability Limitations

All technical information, data and information for installation and operation correspond to the latest

status at time of printing and are made in all conscience considering our past experience and

knowledge. Information, pictures and description do not entitle to base any claims. The manufacturer

is not liable for damage due to failure to observe the manual, improper use, incorrect repairs, technical

modifications, use of unauthorized spare parts. Translations are made in all conscience. We assume

no liability for translation mistakes, even if the translation is carried out by us or on our behalf.

Disposal

If a label is placed on the device showing a crossed out dustbin on wheels (see drawing), the

European directive 2002/96/EG applies for this device.

Please get informed about the applicable regulations for separate collection of electrical and

electronical waste in your country and do not dispose of the old devices as household waste.

Correct disposal of old equipment protects the environment and humans against negative

consequences!

Operating ranges and interferences

The ALGE WTN operates in 4.2 GHz frequency band, the same as WLAN. This is also used by other

services. The operating range as well as the operation may be disturbed by devices working at the

same or neighboring frequencies.

Manual

Photo Finish OPTIc2.NET

Page 3

Declaration of Conformity

We declare that the following products comply with the requirements of the listed standards.

We, ALGE-TIMING GmbH

Rotkreuzstrasse 39

A-6890 Lustenau

declare under our sole responsibility, that the photo finish camera of the type:

OPTIc2, OPTIc2o and OPTIc2n

is in conformity with the following standard(s) or other normative documents(s):

Safety: EN 60950-1:2006 + A11:2009

EMC: EN55022:2006+A1:2007

EN55024:1998+A1:2001+A2:2003

EN61000 3-2:2006 + A1:2009 + A2:2009

EN61000 3-3:2008

Additional Information:

The product herewith complies with the requirements of the Low Voltage Directive 73/23/EEC, also

the EMC Directive 2004/108EG and accordingly carries the CE-marking.

Lustenau, 10.02.2010 ALGE-TIMING GmbH

Albert Vetter

(General Manager)

Manual

Photo Finish OPTIc2.NET

Page 4

Table of Contents

1Introduction.................................................................................................................. 8

1.1 Models ..................................................................................................................................... 8

1.2 Components of the System ..................................................................................................... 8

1.3 System Requirements ............................................................................................................. 9

1.4 Accessory................................................................................................................................ 9

1.5 Function................................................................................................................................. 10

2Layout of the OPTIc2NET ...........................................................................................11

3Select Language of OPTIc2.NET Software ................................................................12

4Connection of the Camera..........................................................................................13

4.1 Camera connected to IEEE1394........................................................................................... 13

4.2 Camera connected to an optical cable.................................................................................. 13

4.3 Camera connected with Network cable................................................................................. 14

4.4 Camera connected at Distribution Box OCD2....................................................................... 14

4.5 Connection of two cameras................................................................................................... 15

5Camera Position..........................................................................................................16

5.1 Lens Angle............................................................................................................................. 17

5.2 Focusing the Camera ............................................................................................................ 18

5.2.1 Adjustment of Focus (Aperture)....................................................................................................... 18

5.2.2 Scan Rate........................................................................................................................................ 18

6Photo Finish for Different Sports...............................................................................19

6.1 Selection of the Type of Sport............................................................................................... 19

6.1.1 General............................................................................................................................................ 19

6.1.2 Track and Field with Anemometer................................................................................................... 19

6.1.3 Track and Field without Anemometer.............................................................................................. 19

6.1.4 Horse Race...................................................................................................................................... 19

6.1.5 Dog Race......................................................................................................................................... 20

6.1.6 Rowing / Canoe............................................................................................................................... 20

6.1.7 Cycling............................................................................................................................................. 20

6.2 Sports with Individual Starts.................................................................................................. 20

6.3 Track and Field (Athletics)..................................................................................................... 20

6.3.1 Zero Control for Athletics (Start Control).......................................................................................... 24

6.3.2 Evaluation for Athletics.................................................................................................................... 24

6.4 Horse Races.......................................................................................................................... 25

6.5 Dog Races............................................................................................................................. 25

6.6 Rowing or Canoe................................................................................................................... 25

6.7 Cycling Races........................................................................................................................ 25

7Setting of the Camera .................................................................................................27

7.1 Possible Camera Settings ..................................................................................................... 27

7.2 Sensor Adjustments .............................................................................................................. 28

7.3 Camera Configuration ........................................................................................................... 29

7.4 Motor Zoom Lens Adjustment ............................................................................................... 30

7.5 Electronic Gear Head Adjustment......................................................................................... 31

7.6 Image Adjustment.................................................................................................................. 32

8Software OPTIc2NET...................................................................................................33

8.1 Icon List ................................................................................................................................. 33

8.2 Footer .................................................................................................................................... 34

8.3 Menus of the Software........................................................................................................... 36

8.3.1 Menu <File>..................................................................................................................................... 36

8.3.2 Menu <TIMING>.............................................................................................................................. 37

8.3.3 Menu <Setup>................................................................................................................................. 38

8.3.4 Menu <Connection> ........................................................................................................................ 42

8.3.5 Menu <Sport>.................................................................................................................................. 43

8.3.6 Menu <Show>.................................................................................................................................. 43

8.3.7 Menu <Help>................................................................................................................................... 45

Manual

Photo Finish OPTIc2.NET

Page 5

9Evaluation Windows ...................................................................................................46

9.1 View 1.................................................................................................................................... 46

9.2 View 2.................................................................................................................................... 47

9.3 Overview................................................................................................................................ 47

10 Timing (Timing Window) .........................................................................................48

10.1 Tool Bar of the Timing Window: ............................................................................................ 50

10.2 Photo Finish Recording ......................................................................................................... 51

10.2.1 Manual Recording or ............................................................................. 51

10.2.2 Push Button Recording ............................................................................................................... 52

10.2.3 Sensor Recording (Photocell)...................................................................................................... 52

10.2.4 Motion Detection ......................................................................................................................... 52

11 Evaluation of Races.................................................................................................52

11.1 Time Window......................................................................................................................... 52

11.2 Manual Evaluation................................................................................................................. 53

11.3 Lane Evaluation..................................................................................................................... 53

11.4 BIB Evaluation....................................................................................................................... 54

11.5 We show three different lines on the photo finish picture...................................................... 54

11.5.1 Time Cursor................................................................................................................................. 55

11.5.2 Result Lines................................................................................................................................. 55

11.5.3 Time Jump Markers..................................................................................................................... 55

12 Heat List ...................................................................................................................56

12.1 Field Selector......................................................................................................................... 56

12.2 Class Mode .................................................................................................................... 57

12.2.1 Start Time of a Class................................................................................................................... 58

12.3 Insert Row(s) ........................................................................................................... 59

12.4 Delete .......................................................................................................................... 59

12.5 Import an Excel list ........................................................................................................ 59

12.6 Export an Excel list ....................................................................................................... 61

12.7 Import a List Layout ...................................................................................................... 61

12.8 Export a List Layout ...................................................................................................... 61

12.9 Export the Result List ................................................................................................... 61

12.10 Export Selected Result Lists ................................................................................... 61

13 Meet Browser...........................................................................................................62

14 Synchronizing of the OPTIc2 ..................................................................................65

15 Integration of IDCam................................................................................................67

15.1 Adjustment of the IDCam ...................................................................................................... 68

15.1.1 OPTIc2-camera and IDCam are connected at the same PC....................................................... 68

15.1.2OPTIc2-camera and IDCam are connected at different PCs....................................................... 68

15.1.3 Offset between photo finish and IDCam...................................................................................... 69

15.2 Integration of the IDCam at the same PC ............................................................................. 69

16 Integration of a Timing or Transponder System....................................................70

16.1 Adjustment of the Interface ......................................................................................... 70

16.1.1 Race Result:................................................................................................................................ 72

16.1.2 Mylaps:........................................................................................................................................ 72

16.2 Transponder Mapping ................................................................................................... 73

16.3 Recording Using Data from External Devices....................................................................... 74

17 How to keep the OPTIc2 updated ...........................................................................75

Manual

Photo Finish OPTIc2.NET

Page 6

17.1 Direct links to download the updates..................................................................................... 75

17.2 Update of the OPTIc2 PC-Software ...................................................................................... 75

17.3 Update of the Camera ........................................................................................................... 75

18 Technical Data of the OPTIc2n ...............................................................................76

19 Accessories for Photo Finish .................................................................................78

19.1 IEEE 1394 PC-Interface........................................................................................................ 78

19.2 IEEE 1394 Cable and Connections....................................................................................... 79

19.3 Network Cable with RJ45 Plug.............................................................................................. 80

19.4 Optical Cable and Fiber Optic Adapter.................................................................................. 80

19.5 Lenses for the OPTIc2........................................................................................................... 81

19.6 Tripod and Gear Head........................................................................................................... 81

19.7 Distribution Box OCD2 .......................................................................................................... 82

19.7.1 Connections of the Distribution Box OCD2.................................................................................. 83

19.7.2 Examples for the Connection of the Camera............................................................................... 84

19.7.3 Technical Data of the Distribution Box OCD2.............................................................................. 86

Manual

Photo Finish OPTIc2.NET

Page 7

Model OPTIc2 Model OPTIc2o

Model OPTIc2n

1......IEEE 1394b 9-pol bilingual (2 x)

2......IEEE 1394a 6-pol

3......GOF (LC duplex glass optical fiber connector)

4......Socket for motor zoom

5......Socket for photocell (2 x)

6......Fuse for camera - F1 T1.6A

7......Input for external power supply (+9 to 36 VDC)

8......LED for OK status

9......Banana Socket – Data output for display board

10....Banana Socket – Finish Impulse

11....Banana Socket – Start Impulse (2 x)

12....Spirit level

13....Sight to aim the camera at the finish line

14....RJ45 socket for CAT5 cable

Manual

Photo Finish OPTIc2.NET

Page 8

1 Introduction

This manual can also be opened directly in the OPTIc2NET-software (pdf-file) by pressing

the key <F1> or if you go to the menu <HELP> and click on <F1 Open the user manual>.

The ALGE OPTIc2 system is an electronic photo finish system with integrated evaluation soft-

ware. The Line Scan Camera (CCD image sensor) scans every movement on the finish line,

records it on the hard disk of the PC and displays it on the PC screen. It is at any time possi-

ble to print the picture.

The photo finish system is built with latest technology. The camera has an improved CCD-

line scan sensor that is suited to take excellent pictures at all possible light conditions. The

system allows up to 3000 lines per second. A vertical resolution is possible of up to 1360

pixel at 16.8 million colors (24 bit).

1.1 Models

We offer three photo finish cameras. The standard model OPTIc2 has only standard Firewire

connections (IEEE1395), whereas the model OPTIc2o has additionally an optical Firewire

connection (for long distance between camera and PC).

OPTIc2:

The standard model has Firewire connections (IEEE 1394) to connect a PC.

The maximum cable length for such a cable is 10 m. ALGE offers longer cables

with integrated repeaters.

OPTIc2n:

This model has in addition to the Firewire connections (IEEE1394) an optical

connection GOF (LC duplex glass optical fiber connector) and a connection for a

network cable with RJ45 plug. This allows transmitting data with a CAT7 cable

over a distance of up to 80 m.

OPTIc2o:

This model has in addition to the standard Firewire connections (IEEE1394) an

optical connection GOF (LC duplex glass optical fiber connector). This allows

transmitting data form the camera over a distance up to 300 m.

1.2 Components of the System

The OPTIc2, OPTIc2o and OPTIc2n include the following parts:

•Photo finish camera OPTIc2, OPTIc2o or OPTIc2n

•C-Mount adapter (between lens and camera)

•OPTIc2 USB stick with PC software and manual

Manual

Photo Finish OPTIc2.NET

Page 9

1.3 System Requirements

PC Requirements:

•Intel i5 Processor or faster

•Windows XP, Windows Vista, Window 7, Windows 8 and Windows 8.1 (32 or 64 Bit

Version)

•4 GB RAM (the higher the better)

•Hard disk with min. 250 GB (the faster the hard disk, the longer the recording time)

•Keyboard for PC

•Mouse for PC

•Graphic board with min. 128 MB RAM

•Monitor with min. 1024 x 768 resolution and true color

•OHCI compatible IEEE 1394 interface

•Color printer to print the pictures and result lists (color laser or ink jet)

1.4 Accessory

For the all OPTIc2 models we can offer several additional products. Please contact your

ALGE-dealer for further details:

•IEEE 1394 PCI card for inserting in the PC

•IEEE 1394 PC-card for notebooks

•Camera tripod TRIMAN for camera

•Gear head 410 for camera adjustment (3-dimensional camera adjustment)

•Zoom Lens Z75 (12.5 – 75 mm / F1.2)

•Motor Zoom MZ75 (12.5 - 75 mm / F1.8), remote control from PC

•Motor Zoom MZ160 (16 - 160 mm / F1.8 – 1400), remote control von PC

•Wide angle lens L8.5 (8.5 mm / F1.0)

•Weather protection case for camera

•Several IEEE1394 cable

•Adapter RJ45-1394 from IEEE1394 cable to network cable

•Adapter GLAS1394 from IEEE1394 cable to glass optical fiber cable

•Cables and cable reels with network cable

•Cables and cable reels with glass optical fiber cable

•Electronic Startgun e-Start with speaker system BANG

•Startmicrophone SM8

•Startgun STP with 9 mm or 6 mm blanks

•Speech Amplifier SV4/SM

•Headset HS3-2 or HS2-1

•Photocell PR1a-R (Distance: 1 to 25 m)

•Photocell PR1a-d (Distance: up to 150 m)

•3-fold Photocell RLS3c with tripod (for athletics)

•Push Button 020-02

•Numerical Display Boards (e. g. GAZ5 or D-LINE)

•Matrix Display Systems for stadiums

•Cable Reel with 2-core steel cable (extra strong military production); several lengths

•Anemometer Windspeed WS2

Manual

Photo Finish OPTIc2.NET

Page 10

1.5 Function

The line scan camera has not the usual aerial sensor (e.g. like a video camera), but a CCD-

line scan sensor. The photo finish camera does not record a complete picture at once, but

only one vertical line. The recording speed for this vertical line is adjustable until up to 3000

times per second. Each line is stored on the hard disk and is shown on the screen in chrono-

logical order. If something moves in front of the camera (e.g. an athlete) you receive a picture

of it. Each vertical line is allocated to a time.

The following example shows how a picture is recorded. If you use a scan rate of 1/1000

seconds it means that the finish line is scanned 1000 times per second. Each of these pic-

tures records a small piece of the object. If the speed is adjusted correctly, it shows the ob-

ject in the right size.

The next example shows the same object, but now crossing the finish line with a higher

speed and the same scan rate of 1/1000. The shape of the recorded picture depends on the

speed of the picture and the scan rate. Therefore, it is very important to record with the cor-

rect scan rate to get the realistic shape of the image. The image below shows the object

shortened if using the same scan rate as at a faster speed. Of course, the object is scanned

less often under such circumstances.

Part of the OPTIc2 is an electronic image processing system. The recorded picture is stored

on the hard disk of the PC (bitmap format) and can be printed anytime with a printer that

supports Windows.
