Algas SDI Direct Fired F6-ASME Manuel
Operations&Maintenance
Manual
151 South Michigan Street, Seattle, Washington, USA 98108
Tel: 206-789-5410 Fax: 206-789-5414 Web: www.algas-sdi.com
This manual covers units built after August 2009 After S/N: 09160185
FILE: MANUAL PN 54000 rev 09-23-2019
...Innovative liquid vaporizing and gas mixing solutions
LP-Gas Vaporizer: 160H - 800H
2019.09.2
6
16:24:07
-07'00'
WARNING
Read the OPERATION MANUAL before operating this equipment.
■ NOTE: Algas-SDI reserves the right to use alternate manufacturers’
components as vendor delivery applicability dictates. Literature
contained in the Operation Manual has been supplied by
vendors. Please check to be sure supplied data matches your
configuration. Contact Algas-SDI if any questions exist.
■ This equipment uses LPG-a flammable fuel, handled under pressure.
Inherent hazards exist and a thorough understanding of the equipment
is required to allow safe operation and maintenance.
■ Allow only a TRAINED and FULLY QUALIFIED PERSON to service this
equipment.
■ Any time a component must be replaced, use the same type, model,
etc. DO NOT SUBSTITUTE! The consequence from such actions are
unpredictable and may lead to dire consequences. When components
are replaced with components not approved for use in our UL listed
equipment, the UL listing becomes void for that unit.
Warranty,CopyrightsandApprovals
WARRANTY
Algas-SDI International, LLC (ASDI) warrants that the equipment is free of
defects in materials and workmanship under normal use and service. ASDI
agrees to repair or replace, at our option, without charge f.o.b. factory, any part
which has proven defective to the satisfaction of Algas-SDI International, LLC
within one (1) year from the date of the original installation or within 18 months
from the date of shipment, whichever is earlier. Equipment, which in the opinion
of ASDI, has been damaged by improper installation or operation, or has been
abused or tampered with in any way, will not be accepted for return under
warranty.
Algas-SDI International, LLC will not accept back charges for work performed by
others upon or in conjunction with ASDI equipment, unless prior authorization is
given by means of an Algas-SDI International, LLC purchase order. Algas-SDI
International, LLC will not be liable by reason of shutdown, non-operation or
increased expense of operation of other equipment, or any other loss or damage
of any nature, whether direct or consequential, arising from any cause
whatsoever.
Algas-SDI International, LLC makes NO other warranty of any kind, whatsoever
expressed or implied; and all warranties of merchantability and fitness for a
particular purpose are hereby disclaimed by Algas-SDI International, LLC and
excluded from these terms of sale. No person has any authority to bind Algas-
SDI International, LLC to any representation or warranty other than this warranty.
COPYRIGHT
Copyright 2019 by Algas-SDI International, LLC, Seattle, Washington 98108. All
rights reserved. No part of this manual may be reproduced or copied in any form
or by any means, photographic, electronic, or mechanical, without the prior
express written consent from Algas-SDI International, LLC, Seattle, Washington,
USA.
APPROVALS
This page left intentionally blank
IMPORTANT WARRANTY NOTICE:
The Algas-SDI warranty period for equipment is 18 months after
shipment from our facility or 12 months after installation. See our
warranty statement at the beginning of this manual for the complete
text. A warranty registration card has been provided with this manual
so that you may register the date of installation for warranty purposes.
If you do not return the warranty registration card, the warranty term will
be 12 months after the equipment has been shipped to you, the end
user. If you do not install it immediately, your warranty may expire
earlier than necessary. The warranty registration also gives us
information to contact you if we need to send you important information
about the equipment later on.
Please register your equipment.
SymbolsandConventions
Special symbols are used to denote hazardous or important information. You
should familiarize yourself with their meaning and take special notice of the
indicated information.
Please read the following explanations thoroughly.
GENERALWARNINGORCAUTION
Indicates hazards or unsafe practices which can result in damage to
the equipment or cause personal injury. Use care and follow the
instructions given.
FLAMMABLEGASHAZARD
Indicates a potential hazard which can result in severe personal
injury or death. Use extreme care and follow the instructions given.
ELECTRICALDISCONNECTREQUIRED
Indicates a potentially dangerous situation which can result in
severe personal injury or death or damage to equipment. Use great
care and follow the instruction given.
PARTSANDPRICES
For parts and prices contact your Algas-SDI distributor.
ASDICONTACTNUMBERS
If you have questions, need help with your equipment, or want
information on other products, contact your distributor or
Algas-SDI at:
Telephone:206.789.5410
Facsimile: 206.789.5414
Internet: http://www.algas-sdi.com
TableofContents
Options
Auto Re-igniter
Contaminant Separator / Filtaire
Economy Kit
Inlet and Outlet Hand Valves
Pipeaway Adapter
1st Stage Regulator
1. Introduction
Description/Overview 1
Figure 1 – Direct Fired Vaporizer System - Basic Features 1
How the vaporizer works 2
Direct fired vaporizer specifications 3
2. Installation
General 4
Unpacking and Initial Assembly 4
Unpacking 4
Initial Assembly 4
Table 1 – Distance from Vaporizer 4
Figure 2 – Vaporizer Dimensions 5
Figure 3 – Installation – 160H vaporizers 5
Vapor Distribution Line 6
Table 3 – Recommended Vapor Distribution Line Size 6
Liquid Inlet 6
Vapor Bypass Line (Optional) 7
Burner Supply Line (Optional) 7
Liquid Pump (Optional) 7
Economy Installation (Optional) 7
Figure 4 – Economy Option 8
Contaminant Separator – Filtaire (Optional) 8
Figure 5 – Filtaire Operation 9
Leak Test 9
Check Regulator Pressures 10
3. Operation
Direct Fired Vaporizer start up procedure 11
Figure 6– Temperature control dial in “RUN” position 11
Figure 7 – Pilot button pressed down and ignitor switch on 12
Direct Fired Vaporizer setpoint adjustment 12
Figure 8 – Rotating temperature control dial counter-clockwise to desired setpoint 12
Direct Fired Vaporizer shutdown procedure 13
Figure 9 – Vaporizer shut down procedure 13
Direct fired vaporizer purge procedure 14
Automatic Re-Ignition Operation 14
Economy Operation 14
4. Maintenance
Service and Maintenance 15
Table 3 – Initial Installation & Operation InspectionsError! Reference source not found.15
Table 4 – Annual Maintenance RequirementsError! Reference source not found. 16
Direct fired vaporizer maintenance checklist 18
Replacing Reignitor Battery 19
Figure 10 – Opening the battery access door 19
Figure 11 – Replacing the battery 20
Adjusting the Regulator 21
Figure 12 – Regulator adjustment 21
Liquid inlet valve maintenance 22
Capacity control valve maintenance 23
5. Troubleshooting
Pilot 25
Main Burner Will Not Ignite 25
If Vapor Pressure Drops 25
Troubleshooting Tree #1: Pilot Will Not Light 26
Troubleshooting Tree #2: Pilot Lights But Will Not Hold 27
Troubleshooting Tree #3: Main Burner Will Not Light 28
Troubleshooting Tree #4: Vapor Service Pressure Drops 29
AppendixA:TechnicalInformation
Table 6 – Repair Kits and Other Available Replacement Parts 160H
Liquid inlet valve pin gasket installation procedure
Thermowell leak test procedure
This page left intentionally blank
