AWIPH90
WiFiPhone
AWIPH90 is a versatile 802.11b/g WiFi Surveillance Phone. It provides high voice quality with
various codes including iLBC. AWIPH90 can also communicate with Skype users through
Atonics eLink software. Additionally, equipped with MPEG4/JPEG decoder, AWIPH90 can be
used as a handhold IP surveillance terminal.
Feature
zSupport Wireless Access Protocol – 802.11b/g
zDirect Sequence with data rates at 1, 2, 5.5, 11, 6, 9, 12, 18, 24, 36, 48, 54Mbps
zSupport Site Survey --- scan available APs in handset’s environment
zImplementing IETF RFC-3261SIP Protocols
zITU-T ,iLBC, G.729, G.723 and G.711 Voice compression coder-decoder compliant
zVAD (Voice Activity Detection) /CNG (Comfort Noise Generation) Silence
zCompression – Annex B of G.723
zEcho Canceller , Instant Message , Support IP Camera (ISMA)
zSupport both DHCP and static IP
zInternet Protocol Support: IP, TCP, UDP, ARP, HTTP 1.0, DHCP, DNS
zRechargeable Batteries – Li-ion
zPhone keypad and graphic LCD display
zPhone Configuration through handset LCD setup and web
zTime protocol support (SNTP).
zSkype connection (through Atonics proprietary SIP/Skype Gateway)
Hardware
zSupport 8Mbytes flash memory.
zWiFi SoC built in 802.11b/g MAC, two external chips only for WLAN.
zSupport 16MBbytes SDRAM
z170x220 color LCM with backlight control
zIncluding Li-ion battery charger controller for automatic charging
zGPIO based matrix keypad without glue logics
zIncluding drivers for vibrator and buzzer control
zConnect receiver (speaker) and microphone to AT76C902 chip directly, no extra amplifier needed.
zSeparate several system power block for optimal power management
ATONICS INC.
htt
p
://www.atonics.com.tw
Specification
General
Complete system solution using Linux operation system
Handset dimensions: 125mm x 45mm x 22 mm
Wireless
Wireless Protocol: IEEE 802.11b / g
Data rate: 1, 2, 5.5 and 11 Mbps~54Mbps
Frequency band: 2.400 ~ 2.497
Operating rang: Out-door up to 300m, In-door up to 75m
Channel: FCC Ch1 ~ 11, ETSI Ch1~13, Japan Ch1~14
Output Power: 14+-1 dBm
Sensitivity: -82dBm@11Mbps
Site Survey: Scan available APs in hand set’s
environment
VoIP Protocol Support
IETF RFC-3261 SIP Protocols
SDP (RFC-2327)
RTP (RFC-1889)
Support outbound proxy for NAT Traversal
STUN for NAT Pass-Through
QoS:ToS/Diff Serv
RFC-2833 Out-of-Band DTMF Relay
RFC-4028 Session Timer
RFC-3323/3325 SIP Privacy
Instant Message
Voice
ITU-T iLBC, G.729, G.723 and G.711 Voice compression
coder-decoder compliant
VAD/CNG Silence Compression
G.168 Echo Canceller
G.711 μ-Law or A-Law compliant
Arbitrary Tone Generation
DTMF Generation
Acoustic Echo Cancellation
Adaptive, low delay jitter buffer for voice data.
Security
WEP 64-bit and 128-bit
WPA/WPA2-PSK(TKIP,AES)
WPA-EAP : EAP-TLS, EAP-TTLS, EAP-PEAP
Multiple AP Profile
WMM QoS , WMM Power Save
Phone Function Support
CallerID
Keypad lock
Re-dial
Call hold/Un Hold/Transfer/ Forward/Waiting
Missed Call Indicator
Battery and signal level metering
Time protocol support (SNTP)
Phone books, call history for friendly usage
Phone Books support for editing/deleting personal data
API to support user application development.
Configurable GPIOs for specific purposes such as LCD
backlight, buzzer, charger and so on.
Talking time 3-4 hours
Standby time: (battery capacity: 700 mA/hr)
Register time ≧600 sec, up to 130 hours
Register time = 60 sec, up to 105 hours
Register time = 30 sec, up to 90 hours
No Register , > 110 hours
Polyphony Ring Tone
Speed Dial
Speaker Volume Control
USB Charge
Support ISMA IP Camera
Management
Auto-provisioning
WEB Configuration
HTTP Firmware Update
