Trouble Shooting
Visit our website at www.alemlube.com.au or www.alemlube.co.nz
NSW/ACT
TEL: (02) 9939 0711
FAX: (02) 9939 0411
QLD/PNG
TEL: (07) 3889 8480
FAX: (07) 3889 8490
VIC/TAS
TEL: (03) 8787 8288
FAX: (03) 8787 8266
WA
TEL: (08) 9209 3066
FAX: (08) 9209 3933
SA/NT
TEL: (08) 8241 7111
FAX: (08) 8241 7011
NZ
TEL: (09) 447 1007
FAX: (09) 447 1008
3
Problem Possible Causes Solutions
The pump doesn’t work 1. Insufcient air
2. Air obstruction
1. Increase air pressure
2. Clear air passage
3. Change voltage
1. The intake valve is closed
2. The intake valve is blocked
1. Open the intake valve
2. Clean the intake valve
A blockage in a hose, valve, or other device Release pressure & clean
Damage to Screw (5) or plate (8) Assess damage, repair or replace Screw (5)
or plate (8)
Insufcient oil supply Replace oil drums to ensure adequate oil supply
Leak of pneumatic device Damage to Piston (7) or gasket (9) or spring (10) Assess damage, repair or replace Piston (7)
or gasket (9) or spring (10)
The pump is unstable Insufcient oil supply Replace oil drums to ensure adequate oil supply
O-Ring (3) Seal (16) (26) (28) (34) damage Change Corresponding O-Ring or seal
Tube (36) damage Change tube (36)
The pump can work, but the
output ow is low
Piston (7) wear Change piston (7)
O-Ring (3) Seal (16) (26) (28) (34) damage O-Ring (3) Seal (16) (26) (28) (34) damage
A blockage in a hose, valve Release pressure & clean components
Oil leaks through the air exhaust Silencer is dirty or damaged Replace damaged elements
If the pump has anything wrong, please contact Alemlube. We do not recommend that the customer repairs
the pump themselves.
Storage & Maintenance
Pumps are delivered in appropriate carton boxes. Packaging material should be properly disposed.
Handling and storage of the new pump does not require any special procedures.
However after the pump has been used, empty the used oil in the suction tube into an appropriate container.
This is done by overturning the pump.
The dust in compressed air can slow down and even block the motor cylinder.
The following steps may prevent this from happening:
1. Let in 50 gram of Vaseline oil or other lubricator from the air inlet hole weekly, operate the pump for several
minutes after having been lubricated.
2. Turn on the pump for several minutes until moving parts are fully lubricated.
3. You may repeat the above operation if necessary.
4. The above steps should be carried out on a weekly basis.
For the pumps that are attached with compressed air treatment equipment, please empty the water retained
in the reservoir of the filter-purger frequently.
For the pumps that are attached with a lubricator, please pay close attention to the lubricator’s oil level and refill
with SAE 20, SAE 30 or antifreeze oil for extreme conditions when necessary.
NOTE: The user should perform only routine maintenance operations (such as filters, silencers, cleaning…)
with the pump in order not to damage it or compromise its safety. Contact Alemlube when the pump
needs further maintenance.
Oil Measure Filler Kit
OWNER’S TECHNICAL MANUAL
O300100
