Alcofind DA-7100 Manuel utilisateur
DA-7100
DA-7100DA-7100
Advanced fuel cell sensor
Personal & professional use alcohol tester
Breath Alcohol Tester
Instruction
Manual
Please read the user's manual carefully before use.
Important safety information
Before using the alcohol tester, read all instruction manual
carefully and practice the test.
Maintenance and calibration should be performed by experts.
Test should be performed after 20 minutes after eating, drinking
or smoking, if failure to wait 20 minutes may result in invalid
results or incorrect results.
Residual alcohol in the mouth can distort the measurement.
Aromatic drinks or mouth sprays containing alcohol can interfere
with measurements. In this case, wait for 20 minutes or rinse the
mouth with pure water.
Do not permit to blow cigarette smoke into the tester which may
damage the sensor.
Do not drink and drive, even small amount of alcohol can result
in driving impairment.
Recommended to use calibration service every 12 months or
after 500 times tests.
Do not use this device as a tool to determine "drink and drive".
The manufacturer and the sellers will not take any legal
responsibility for the test results.
When not used for a long time, keep the device after taking out the
batteries. In case of testing after long-term storage, there might
be high tolerance of test results for the first 3 tests.
Replace the batteries when the battery indicator icon reaches
empty for the accuracy reason.
In case the measured value is higher than 0.1%BAC and you try
again without interval, then warm up time might be delayed.
Perform a test within the operating temperature, which is
specified in the instruction manual.
Introduction
<Front> <Back>
Preparation
Install two AAA batteries in the battery compartment by paying attention
to the battery polarity.
Gently pull the cover down
Thank you for purchasing our breathalyzer, DA-7100 which is a
personal & professional use alcohol tester with extremely high-reliability.
It can be used for hospitals, schools, and many other segments.
It measures estimated B.A.C(Blood Alcohol Content) in human breath
by means of a fuel cell sensor which is high durable sensors and
providing accurate breath alcohol results.
Alcofind
2 x AAA batteries (1.5V Alkaline)
Contents
Name of each part
1. Mouthpiece
2. Mouthpiece slot
3. Display
4. Power & Start button
5. Battery cover
Digital breathalyzer
Alcofind DA-7100
2 (two) AAA sizebatteries
6 (six) mouthpieces
Carrying case
Hand strap
User's manual
Insert a mouthpiece into the port on the side of the alcohol tester.
Ensure whether it is securely fit or not.
A new mouthpieces is to be used for every person tested.
Insert a mouthpiece into
the port gently!
Do not permit to blow cigarette smoke into the tester.
Press the power button
The total of test performed will be displayed
briefly and start countdown.
number
When the countdown reaches zero with a double beep sound,
three dashes ( ) will be displayed and "START" will flash.
Take a deep breath and blow the mouthpiece for five seconds
until there is a double beep sound.
When the sampling was successful, LCD outer lines will be
turning along the edge of LCD as you can see the picture.
After a few seconds(depending on the alcohol level), the
estimated BAC(Blood Alcohol ) will be displayed.
The value will flash for several seconds.
If you want to test again, press the start button to restart the
countdown cycle.
Concentration
The tester automatically will be turned off after
15~20 seconds.
Wait at least 20 minutes after eating, drinking or smoking before measurement.
Performing the measurement
Display message & Problem-solving guide
Technical specifications
Empty battery : Warns when
battery is low. The unit can be
operated but recommended to change
new batteries for correct result!
Replace new batteries.
If the LCD displays "BAt",
the unit cannot operate.
Replace new batteries
immediately.
If the sampling volume is too
low or not sufficiently blow.
Press button again to
repeat the measurement.
If there is no breath sample blown
within 30 seconds, the LCD will
display "OUT".
If the unit is powered on outside of the
acceptable temperature range(0~40 C
or 32~104F) the unit will display it.
Press button to restart
the countdown cycle and
retest.
Repeat the test after the unit
has reached a temperature
within the operation range.
MESSAGE
Full battery
None required.
WHAT IT MEANS ACTION
0.00 ~ 0.50% BAC
0.00 ~ 5.00
0.00 ~ 2.50mg/l
+/- 0.005% BAC at 0.1% BAC at 25 C
+/- 0.05 at 1.0 at 25 C
+/- 0.025mg/l at 0.50mg/l at 25 C
Within 18 seconds at 0.05% BAC
Within 10 seconds at 0.05% BAC
Professional Fuel cell sensor
2 (two) AAA size alkaline batteries
Approx. 1000 tests
48mm x 120mm x 20mm
93g including batteries
every 12 months or after 500 tests
0 ~ 40 C
Warm up time
Response time
Sensor
Dimensions
Battery Life
Dimensions
Weight
Calibration
Operating temperature
(WxHxD)
Accuracy
Indication of B.A.C.
Warranty
The manufacturer warrants the product to be free from defects in
workmanship or material (excluding calibration) under normal use either
for 1(one) year from the date of purchase or 500 breath tests whichever
comes earlier.
The manufacturer's obligation under this warranty is limited to replacing,
adjusting or repairing the unit at manufacturer's option, if returned along
with proof of purchase.
For any defects due to natural disaster or customer's negligence, misuse,
reconstruction and repair by unau thorized person, reasonable cost shall be
charged for repair or part replacement.
For any questions, after-sales service, product calibration or to purchase
additional mouthpieces, please contact nearest distributor.
Manufacturer / Distributor :
Customer service
