Alcatel GO FLIP V Manuel utilisateur

Para la versión en español, visite

verizonwireless.com/support

Meet your

phone.

About your phone

Camera

Headset

Connector

USB

Type-A/

Charger

Port

Camera

Button

Volume

①

②

③

④

⑤

⑥

⑦

⑧

2 3

Setting up your phone

Your device already has a NANO SIM card installed.

MicroSD cards (up to 32GB) may be purchased

separately.

NOTE: Power off the device before opening the back

cover to remove and/or insert the NANO SIM or

MicroSD card.

Step 1. With the device facing down, remove the back

cover from the bottom left corner. Use your fingernail to

carefully lift the cover away from the device body.

Step 2. Remove the battery using your fingernail to lift

from the top right corner.

①Left soft key •From Home Screen: view

notifications

•From open applications: create

a new event (Calendar) or text

(Messaging), take a photo

(Gallery), and more

②Messages key •Open the messages inbox from

any screen

③Call key •Make a call

•Access call log (from app list and

Home screen)

④Center soft

key

•Access app list (from Home

screen)

•Confirm an option (press the

middle of the key)

⑤Navigation key

(up, down, left,

right)

•Menu selection moves up, down

or right and left

•Different functions may be

assigned to each navigation

direction

⑥Right soft key •From Home Screen: view

shortcuts to turn on/off Wi-Fi,

sound settings, Airplane Mode,

and more

•From open applications: view

options or settings menus

⑦Back/clear key •Return to the previous screen,

options menu or close a dialog

box

⑧End/power key •Powers on/off the handset (long

press)

•End a call

•Return to Home screen (from

any app screen)

NOTE: Devices and software are constantly evolving—

the screen images and icons you see here are for

reference only.

4 5

Using your phone

Power on/off your phone

To power on your device, long press the End key.

To power off your device, long press the End key, then

press the Center Soft key to select “Power off”.

Voice Mail

Press the End/power key to wake up your device.

Setting up Voice Mail

1. Dial *86 and press the Call key

2. When you hear a greeting, press #

3. Follow the setup instructions

Checking Voice Mail from your device

1. Dial *86 and press the Call key

2. Follow the instructions

Checking Voice Mail from another device

1. Dial your wireless number

2. When you hear the greeting, press # to interrupt

3. Follow the instructions

To end a call, press the End/power key.

Step 3. To insert MicroSD card, push the MicroSD card

into the card slot with the gold-colored contacts facing

down.

To remove the MicroSD card, push down the plastic tab

and slide out the MicroSD card.

Step 4. Re-install the battery by aligning the gold

contact points of the battery with the gold contact

points of the device. It only fits one way. Press down to

snap in place.

Step 5. Carefully align the back cover with tabs and

press into place. It only fits one direction

Step 6. Charge your device by inserting the small end

of the charging cable into the charger port as shown,

then plug the AC adapter into a wall outlet.

Charge your device fully before turning it on and

starting the set up process.

Note: Do not conduct the set up process while the

device is charging.

6 7

Learning more

Visit http://us.alcatelmobile.com for more

information.

Download the User Guide from

www.verizonwireless.com/support.

Spanish User Guide can also be found from

www.verizonwireless.com/support.

Managing your account

My Verizon Mobile app

Manage your account, track your usage, edit

account information, pay your bill and more.

Customer service

Call 800.922.0204

Twitter @VZWSupport

Additional information

Your wireless device and third-party services

Verizon Wireless is the mobile carrier associated with

this wireless device, but many services and features

offered through this device are provided by or in

conjunction with third parties.

Verizon Wireless is not

responsible for your use of this device or any non-Verizon

Wireless applications, services and products,

including

any personal information you choose to use, submit

or share with others. Specific third-party terms and

conditions, terms of use and privacy policies apply.

Please review carefully all applicable terms, conditions

and policies prior to using this wireless device and any

associated application, product or service.

Hearing aid compatibility information

This device has been tested and rated for use with

hearing aids for some of the wireless technologies

that it uses. However, there may be some newer

technologies that have not been tested yet for use

with hearing aids. It is important to try the different

features of this device thoroughly and in different

locations, using your hearing aid or cochlear implant,

to determine if you hear any interfering noise. Ask your

service provider or the manufacturer of this device for

information on hearing aid compatibility. If you have

questions about return or exchange policies, ask your

service provider or device retailer.

English - CJB61UL01AAA

Printed in China
