Alcatel GO FLIP 3 Manuel utilisateur

Welcome

Start Guide

P10000174 CJB665001AAA

TABLE OF CONTENTS

Phone Overview ................................................................. 1

My Carrier............................................................................ 3

SIM Card.............................................................................. 4

Battery.................................................................................. 6

Battery Management......................................................... 7

Power ................................................................................... 8

Home Screen...................................................................... 8

Calls....................................................................................11

Emergency call.................................................................13

Access Files ......................................................................14

Voicemail ..........................................................................14

Volume & Ringtone ..........................................................15

Contacts ............................................................................15

E-Mail..................................................................................17

Text Messaging ................................................................17

Web Browsing ..................................................................20

Bluetooth®.........................................................................20

Protect Your Phone..........................................................21

Caring For Your Phone....................................................23

Accessories.......................................................................23

Approved Firmware Versions.........................................24

Device Security.................................................................24

Additional Information.....................................................25

1 Year Limited Warranty..................................................25

Safety and use ..................................................................29

Safety tips..........................................................................44

Center Soft Key

Left Soft Key

Internal

Display

Call Key

Right Soft Key

End/Power Key

Navigation Key

(up, down, left, right)

PHONE OVERVIEW

Camera

Headset

Connector

External

Display

Charging

Port

Volume Key

Microphone

SIM CARD

The SIM (Subscriber Identity Module) card identifies your

phone to the wireless network. You cannot make or receive

phone calls without a properly installed SIM card unless its

an emergency call (911).

Insert/Remove the Nano SIM and microSD

Cards(1)

1. Detach the Nano SIM card from its packaging as shown

below.

Note: Nano SIM is smallest SIM size available on card.

(1) microSD Cards are sold separately.

MY CARRIER

This guide provides you with information you need to get

started.

For more information and additional support, please visit

https://t-mobile.com/support where you can:

•

your bill, upgrade your phone, and change your rate

plan.

•

Review your phone’s User Manual.

•

View the latest troubleshooting instructions in the

Support Forums or ask a question of your own.

Service or use is your agreement to T-Mobile’s Terms and

Conditions. T-Mobile requires Arbitration of Disputes

unless, for new customers, you opt-out within 30 days

or for existing customers, you previously opted-out.

Failure to activate service within 30 days from purchase

will also be considered acceptance. For details, see

T-Mobile’s Terms and Conditions at T-Mobile.com/terms-

conditions.

4. To insert a SIM or microSD card, push the SIM or

microSD card into the card slot with the gold-colored

contacts facing down. To remove the SIM or microSD

card, push down the plastic spring and pull the SIM or

microSD card out.

SIM card

SD card

BATTERY

To optimize battery performance, be sure to fully charge

your phone before using it for the first time.

Charge the Device

1. Insert the small end of the charging cable into the

charge port as shown.

2. Power off your phone, remove the back cover via the

notch at the bottom-left of the phone.

3. Remove the battery from the back of the phone.

POWER

To turn the power on/off, press and hold the End/Power

Key .

HOME SCREEN

Press the End/Power Key to get instant access to

the Home screen.

Status Bar

The Status bar appears at the top of your Home screen.

You will find icons indicating your phone’s status and new

notification alerts will also appear in the Status bar.

2. Connect charger to power outlet.

BATTERY MANAGEMENT

Optimize Battery Life

To optimize battery life, adjust your screen brightness and

display timeout.

1. From the Home screen, press the Center Soft Key ,

select Settings and then press the Navigation key

to select Personalization.

2. Press up or down on the Navigation key and select

Display.

3. Adjust Brightness and Screen Timeout to optimize

battery life.

109

App List

From the Home screen, press the Center Soft Key to

access the App list.

Change Home Screen Wallpaper

1. From the Home screen, press the Center Soft Key ,

select Settings and then press the Navigation Key

to select Personalization.

2. Press the Navigation Key and select Display ->

Wallpaper. Select the image location to browse from

Wallpaper, Gallery or Camera.

3. Select new image, press the Right Soft Key to

save. Exit out and new image will be displayed on the

Home screen.

Icon Status

Bluetooth®active

Wi-Fi®active

Vibrate

Network (full signal)

Network (roaming)

4G LTE data service

3G data service

Airplane mode

Alarm set

Battery (charging)

Battery (full charge)

Missed call

New mail

New message

1211

International Call

To dial an international call, press key twice to enter

“+”, then enter the international country prefix followed by

the full phone number and finally press the Call Key .

Emergency Call

If your phone has network coverage, dial emergency

number and press the Call Key to make an emergency

call. This works even without a SIM card.

Answer or Decline a Call

When you receive a call:

•

Press the Left Soft Key or Call Key to

answer;

•

Press the Right Soft Key or End/Power Key

to decline.

CALLS

Make a Call

Dial the desired number and press the Call Key to

place the call, or press the Right Soft Key to select a

contact from Contacts, and then press up or down on the

Navigation Key to select the desired contact and press

the Call Key . If you make a mistake, you can delete

the incorrect digits by pressing the End/Power Key .

To hang up the call, press the End/Power Key .

Press the Right Soft Key to select more options.

The number you entered can be saved to Contacts by

pressing the Right Soft Key while on the dial screen

and select Create new contact.

1413

ACCESS FILES

To access media files and photos saved on your handset

or to transfer files from your handset’s SD card to your

computer, follow these steps:

Connect Device to PC

1. Enable USB Storage in Settings -> Storage -> USB

Storage.

2. Use micro-USB connector to connect your phone to

your computer.

3. Use your computer’s operating system to find phone to

access files or SD card.

This phone is compatible with Windows®XP, Windows®

7, Windows®Vista, Windows®8, Windows® 10, Linux and

Mac OS®.

VOICEMAIL

Set Up Voicemail

1. Press and hold to call voicemail.

2. Follow the prompts to set up your voicemail account.

To mute the ringtone volume of an incoming call, press

the Volume Key.

EMERGENCY CALL

Although all phones are equipped with 9-1-1 emergency

calling capabilities, this phone may or may not permit its

location to be approximated during a 9-1-1 call.*

*Availability of this feature depends on upgrades to the (a) wireless

network and (b) 9-1-1 calling system that are required to be

installed by the local 9-1-1 response agency or public safety

answering point (PSAP); these upgrades may not be available

everywhere within our wireless coverage area or your roaming

area. This approximation of the phone’s location and the transmittal

of location information are subject to emergency situations,

transmission limits, network problems/limitations, interconnecting

carrier problems, your phone, buildings/tunnels, signal strength

and atmospheric/topographical conditions, and may be curtailed,

interrupted, dropped, or refused. The phone’s approximate

location is transmitted to the local 9-1-1 response agency or PSAP

while the call is in progress; this approximation is intended solely

to aid the PSAP in dispatching emergency assistance or to limit

the search area for emergency services personnel. You should

not rely solely on a mobile phone for essential communications

(such as a medical or other emergency). Please see T-Mobile’s

Terms and Conditions, and Privacy Policy for additional service

restrictions and details.

1615

3. Enter contact’s name and other contact information.

You can use your voice to enter information, simply

press and hold the Center Soft Key to activate the

Google Assistant.

4. When finished, press the Center Soft Key to save.

Add a Contact from Call History Log

1. Access your call history log by pressing the Call Key

from the Home screen.

2. Press the Navigation Key to select the number you

want to save to contacts on the call history screen.

3. Press the Right Soft Key to open the Options

menu.

4. Press the Navigation Key to select Create new

contact or Add to existing contact.

5. Enter contact’s information and press the Center Soft

Key to save.

Make a Call from Contact List

1. From the Home screen, press the Center Soft Key

and select Contacts .

2. Press the Navigation Key to select the contact

and press the Center Soft Key , dialing will start

immediately.

VOLUME & RINGTONE

Adjust In-call Volume

While on a call, press the Volume Up/Down Key to adjust

volume.

Adjust Ringtone and Volume

1. From the Home screen, press the Center Soft Key

, select Settings , and then press the Navigation

Key to select Personalization.

2. Press the Navigation Key to select Sound.

3. Select Tones -> Ringtones to choose the desired

ringtone.

4. Select Volume option to adjust volume for Media,

Ringtones, or Alarm.

CONTACTS

Create a New Contact

1. From the Home screen, press the Right Soft Key , or

press the Center Soft Key and select Contacts .

2. Press the Left Soft Key to create a new contact.

Autres manuels pour GO FLIP 3

Table des matières

Autres manuels Alcatel Téléphone portable

Alcatel

Alcatel OT-710A Manuel utilisateur

Alcatel

Alcatel OT-S215A Manuel utilisateur

Alcatel

Alcatel One Touch 132 Manuel utilisateur

Alcatel

Alcatel ONE TOUCH 4033A Manuel utilisateur

Alcatel

Alcatel 2038A Manuel utilisateur

Alcatel

Alcatel 5002S Manuel utilisateur

Alcatel

Alcatel Onetouch 155 Manuel utilisateur

Alcatel

Alcatel OT-305A Manuel utilisateur

Alcatel

Alcatel onetouch 3075A Manuel utilisateur

Alcatel

Alcatel 1X 5059A Manuel utilisateur

Alcatel

Alcatel OneTouch Home F102 Manuel utilisateur

Alcatel

Alcatel One Touch 500 Manuel utilisateur

Alcatel

Alcatel 1S 5024A Manuel utilisateur

Alcatel

Alcatel 1060D Manuel utilisateur

Alcatel

Alcatel OneTouch CJA60G5KFAAA Manuel utilisateur

Alcatel

Alcatel 5056E Manuel utilisateur

Alcatel

Alcatel OneTouch 918 Manuel utilisateur

Alcatel

Alcatel One Touch Idol 6030 Manuel utilisateur

Alcatel

Alcatel One Touch 356 Manuel utilisateur

Alcatel

Alcatel PIXI THEATRE Manuel utilisateur

Alcatel

Alcatel 510A Manuel utilisateur

Alcatel

Alcatel ONE TOUCH OT-E206C Manuel utilisateur

Alcatel

Alcatel IDOL 5S Manuel utilisateur

Alcatel

Alcatel ONE TOUCH 6033A Manuel utilisateur

Manuels Téléphone portable populaires d'autres marques

Zte

Zte BLADE A520 Manuel utilisateur

Nokia

Nokia Lumia 620 Manuel utilisateur

Blackbe;rry

Blackbe;rry KEYone Manuel utilisateur

Bea-fon

Bea-fon X5 Premium Manuel utilisateur

Blackbe;rry

Blackbe;rry 8707 Series Manuel utilisateur

Blackbe;rry

Blackbe;rry Storm Mode d'emploi

LG LM-X420QN Manuel utilisateur

LifeWatch

LifeWatch V Manuel utilisateur

Bea-fon

Bea-fon SILVER LINE SL860 Manuel utilisateur

IKI Mobile

IKI Mobile KF4.5i Manuel utilisateur

Hitech

Hitech HT-850 Manuel utilisateur

Yezz

Yezz Fashion F10 Manuel utilisateur

Point Mobile

Point Mobile PM60 Manuel utilisateur

Blackbe;rry

Blackbe;rry Q10 Manuel utilisateur

Blackbe;rry

Blackbe;rry Bold 9900 Manuel utilisateur

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Manuel utilisateur

LG LM-K420EMW Manuel utilisateur

ISAFE MOBILE

ISAFE MOBILE IS655.2 Manuel utilisateur
