Quick Start

Guide

TV LISTENING SYSTEM

BeHear PROXY + HearLink PLUS

[email protected]

www.alango-behear.com

1. Connect HearLink PLUS to a power outlet (a) or the TV set’s

USB port (b) using the supplied USB power cable. HearLink

PLUS will turn ON automatically.

Remove for

Bypass use

TX Verify that the mode switch

is set to TX position

2. Connect the HearLink PLUS TX port to the TV (or other

media device) via the supplied optical or 3.5mm audio

cable. The active connection type is indicated by the

illuminated text ( or ).

OPT AUX

Remove for

Bypass use

AUX OPT

Make sure to remove the plastic

protectors from the optical cable

terminals prior to insertion.

Getting Started

3. Turn on the BeHear PROXY

neck speaker by sliding up

the Power button and holding

it until the unit vibrates and

the LED turns light blue.

A voice prompt will be played.

Verify that the mode

switch is set to

Loudspeaker position.

4. Successful connection of the BeHear PROXY is indicated

by the illuminated A on the HearLink PLUS panel.

The LL is illuminated to indicate that the Low Latency

APTX-LL Bluetooth CODEC is being used.

If the automatic connection is delayed, briefly shift

up the BeHear PROXY Power button to reconnect it

to the HearLink PLUS transmitter.

Press to increase the volume. A tone is played

when maximum volume is reached.

Press to decrease the volume. A tone is played

when minimum volume is reached.

Short press to toggle audio Play/Pause.

1. HearLink PLUS Manual Control

Press to decrease the volume. A tone is played

when minimum volume is reached.

Press to increase the volume. A tone is played

when maximum volume is reached.

Short press to toggle Play/Pause audio.

2. BeHear PROXY Remote Control

Manage audio play using controls on the neck speaker.

Audio Playback

Helpful Information

2. If you do not hear audio:

Ensure that the ‘audio out’ port of your TV connected to

the HearLink PLUS is active. For some devices you need

to enable the audio output. Refer to your device’s user

manual.

Toggle the Play/Pause button on the BeHear neck

speaker or button on the HearLink PLUS.

3. If the automatic connection is delayed, briefly shift up

the BeHear PROXY Power button to reconnect it

to a previously paired HearLink PLUS transmitter.

1. Charge the neck speaker directly from a wall outlet or

computer USB port.

The LED indicator is red during charging and turns green

when the neck speaker is fully charged.

Full charging takes up to 3 hours.

When pairing is complete (after 5-30 seconds) will

be illuminated on the HearLink PLUS panel.

Successful connection of the BeHear PROXY neck

speaker is indicated by the illuminated or on the

HearLink PLUS panel.

4. To restore connection between BeHear PROXY and

Hearlink Plus transmitter:

Place HearLink PLUS into pairing mode with a short

press on its button.

When in pairing mode the indicator light will ﬂash TX

quickly.

Turn OFF BeHear PROXY.

Shift its power switch up and hold it until the voice

prompt says: “Pairing mode active” and the LED blinks

in alternating red and blue.

Place the BeHear PROXY neck speaker close to the

HearLink PLUS device.

5. Use the HearLink PLUS Bypass mode to maintain the

existing interfaces between your TV and peripheral

audio equipment.

Remove protection sticker from the rear panel and

connect the Hearlink PLUS TX port to the TV via the optical

or 3.5mm audio cable, and the RX port to a speaker or

other peripheral audio equipment using the same type of

cable as the TX port connection.

To passthrough HearLink PLUS

set its Mode switch to Bypass

position, indicated by .

Bypass

AUX OPT

AUX

OPT

Remove the sticker to expose the RX ports.

Non-Wireless Speaker

6. More details about Hearlink Plus and BeHear PROXY can

be found in their user manuals.

[email protected]

www.alango-behear.com

To restore connection with the

BeHear PROXY neck speaker set

the Mode switch to TX.
