Akuvox C313X Manuel utilisateur
C313X
Quick Guide
b
Unpacking
Please make sure the package contains the following items:
Screw fixing seat x 2
ST4X20 screw x 2
10 Pin cable x 1
11 Pin cable x 1
Wall bracket x 1
C313X x 1
M4X30 screw x 2
C313X
Front Panel
Touch Screen
Product Overview
MIC
C313X
C313X
Rear Panel
RJ45 Interface
10 Pin Terminals
Loudspeaker
Network Interface（Power in）
11 Pin Terminals
C313X
Installation
Mark two fixation holes through
wall bracket on the wall,the
distance between which is
60mm. Make sure the all cables
can be passed from the middle
of wall bracket.
Take down the bracket,
then using a 5mm hand drill
to make the two fixation
holes on the wall you
marked before.
Once the fixation holes are
made, insert the two screw
fixing seats provided.
Use two ST4X20 screws to fix
the wall bracket on the wall.
Without 86 embedded box in the wall
C313X
Device Mounting
Push down to fix the
device securely.
With 86 embedded box in the wall
Make sure all cables in
the 86 embedded box.
Fix the wall bracket on the
86 embedded box with
two M4X30 screws.
C313X
Configuration
Operation
1. After setting up network and power, press Status icon to check IP address (DHCP by default).
2. Launch web browser and type in the IP address to access web interface, login with username and password.(admin by default).
3. Register the device with your SIP account.(please refer to user manual for more information).
Make a call
Press Intercom key , enter the callee’s number or room address , then choose Audio or Video
mode to call out.
Receive a call
When receiving a video call, users can choose Audio or Video mode to answer. However, if there is an
audio call, users can only press Audio mode to pick up.
C313X
Unlock
During the talk, press the Open Door key in talking interface to unlock the door.
Monitor
Press Monitor key to receive the video from indoor IPC or community IPC any time.
SOS
Press SOS key in case of an emergency.
