Akai AKDVD7 Manuel utilisateur
7” Portable
DVD Player
User Manual
MODEL: AKDVD7
2
Welcome
Welcome to AKAI.
This user manual tells you all you need to know about setting up your new product.
Please take special note of any important safety and usage information presented with the symbol.
All products brought to you by AKAI are manufactured to the highest standards of performance and safety
and, as part of our philosophy of customer service and satisfaction, are backed by a comprehensive
1Year Warranty.
3
Welcome 2
Product Overview 4
Controls and Connections 5
Remote Control 9
Operation 12
Troubleshooting 21
Specifications 23
Compliance and Responsible Disposal 24
Contents
4 | PRODUCT OVERVIEW
Product Overview
A. 7” Portable DVD Player
B. Remote Control
C. AAA Batteries
D. Car Adaptor
E. AC Adaptor
F. AV Cable
G. User Manual
H. Warranty Certificate
I. General Safety Warnings
What’s in the box:
I
CONTROLS AND CONNECTIONS | 5
Controls and Connections
1. LCDTFT screen
2. Speakers
3. Infra-red signal receiver: Accepts
remote control signal.
Left LED Indicator: Red during
charging, green when fully charged.
Right LED indicator: Green when
player is on, red when on standby.
Front view
1
3
2
6 | CONTROLS AND CONNECTIONS
USB/CARD
Top view
4. MENU/SOURCE: Return to the disc
main menu; press and hold to switch
to AV IN or DVD mode.
5. VOL +/SETUP: Increase volume; press
and hold to enter system setup.
6. VOL -/STOP: Reduce volume; press
and hold to stop playing.
7. PREV / NEXT: Skip to the
previous or next title, chapter, or track.
REV / FWD: Fast rewind or
forward the current track.
/ / / : Navigation buttons.
USB/CARD: Press and hold to switch
between DVD, USB and SD Card
mode.
8. OK / : Confirm, or play/pause.
9. OPEN: Push down to open the DVD
4
5
6
7
8
9
CONTROLS AND CONNECTIONS | 7
SD/MMC CARD
Side view
10 11 12 13 14 15 16
compartment.
10. USB Slot: See below.
11. SD Card Slot: See below.
12. Earphone Jack: See below.
13. AV OUT: See next page.
14. AV IN: See next page.
15. ON/OFF Switch:Turn the unit on/off.
16. DC IN: See next page.
10 USB
STORAGE
Insert a USB to playback music and photos.
11 SD Card Slot
STORAGE
Insert a SD/MMC memory card to playback your multi-media
files, including music and photos.
12 Earphone
Jack
SOUND
Connect to your earphones, amplifier or audio device, using
an AUX cable (not included).
8 | CONTROLS AND CONNECTIONS
13 AV OUT
SOUND
Send the image from the DVD player to aTV screen using
the supplied AV cable.The AV cable must be connected to an
externalTV device.
14 AV IN
SOUND
Send the image from another device to the DVD player using
the supplied AV cable.
16 DC IN
POWER
Connect the supplied AC adaptor or car adaptor to power and
charge the unit.
REMOTE CONTROL | 9
Setup
Insert two AAA size batteries according to the polarity
markings (+ / -) inside the compartment. Make sure
the batteries are correctly aligned and properly
pushed into place.
Precautions When Using Batteries
• Do not use old and new batteries together.
• Do not use different types of batteries (e.g.
Manganese and Alkaline batteries) together.
• Remove the batteries from the remote if you do
not intend to use it for a long time.
• When discarding used batteries, follow any
guidelines for recycling and disposal of batteries
that apply in your local area.
• Keep batteries away from children and pets.
• Never throw batteries into a fire or expose them
to extreme heat.
Remote Control
AAA size
batteries
included
1
2
3
10 | REMOTE CONTROL
POWER
VOLUME
1 2 3 +
-
4 5 6
78 9
0/10 10+
MUTE
SOURCESETUP
OK
OSD DVD/USB/SD
LCD ON/OFF
POWER
VOLUME
1 2 3 +
-
4 5 6
78 9
0/10 10+
MUTE
SOURCESETUP
OK
OSD
SUBTITLE STEP STOP TITLE/MENU
ANGLE ZOOM GOTO AUDIO
PROG A-B SLOW REPEAT
DVD/USB/SD
LCDON/OFF
Remote Control
LCD ON/OFF:Turns off the
display while still playing audio
to help save battery life.
NUMBER BUTTONS: Numerical
input to directly access a specific
chapter or track.
SETUP: Access/exit the System
Setup menu.
/ / / : Navigate the
System menu.
OK: Confirm a selection.
: Skip to the previous title,
chapter or track.
: Fast rewind current track.
POWER: Put the DVD Player on
Standby/On.
VOL + / VOL - : Adjust the
volume level.
MUTE: Mute the sound; press
again to restore the sound.
SOURCE: Press repeatedly to
cycle through DVD/AV IN mode.
: Skip to the next title, chapter
or track.
: Fast forward current track.
: Play/pause playback.
