Airwell AWSI-XAD012-N11 Manuel utilisateur

DCI Light Commercial Series

CBD IndoorUnits

DCD IndoorUnits

FBD IndoorUnits

FWDB indoor Units

XAD IndoorUnits

OutdoorUnits

AWSI-XAD012-N11

AWAU-YLD012-H11

AWSI-XAD018-N11

AWAU-YLD018-H11

REFRIGERANT

R410A

HEATPUMP

REFRIGERANT

SM YLD DCI Ver.6 GB

JUNE 2016

Contents

Contents i

Part 1 General Information .................................................................................................... 1

Part 2 Indoor Units ............................................................................................................... 31

Part 3 Outdoor Units........................................................................................................... 147

Part 4 Installation................................................................................................................ 178

Part 5 Electrical Control System....................................................................................... 211

※The specifications, designs, and information in this book are subject to change without notice for

product improvement.

General Information

General Information 1

Part 1

General Information

1. Model Lists.......................................................................................................................... 2

2. External Appearance.......................................................................................................... 3

2.1 Indoor Units............................................................................................................... 3

2.2 Outdoor Units ............................................................................................................ 4

3. Product specification......................................................................................................... 5

4. Features ............................................................................................................................ 30

Model Lists

2 General Information

1. Model Lists

1.1 Indoor Units

R410A (capacity multiplied by 1000Btu/h)

Type

Function

Super slim cassette

Cooling and heating

●

Duct

Cooling and heating

●

Ceiling-floor

Cooling and heating

●

Ceiling-floor(Wine Cellar)

Cooling

●

Four-way cassette(compact)

Cooling and heating

●

Console

Cooling and heating

●

1.2 Outdoor Units

Universal Outdoor unit Model

Compressor type

Compressor Brand

Matched indoor units

AWAU-YLD012-H11

Rotary

GMCC

AWSI-CBD012-N11

AWSI-DCD012-N11

AWSI-XAD012-N11

AWAU-YLD018-H11

Rotary

GMCC

AWSI-CBD018-N11

AWSI-DCD018-N11

AWSI-FBD018-N11

AWSI-FWBD018-N11

AWSI-XAD018-N11

AWAU-YLD024-H11

Twin-rotary

GMCC

AWSI-CBD024-N11

AWSI-DCD024-N11

AWSI-FBD024-N11

AWSI-FWBD024-N11

AWAU-YLD030-H11

Twin-rotary

GMCC

AWSI-DCD030-N11

AWSI-CBD030-N11

AWSI-FBD030-N11

AWAU-YLD036-H11

Twin-rotary

Mitsubishi

AWSI-CBD036-N11

AWSI-DCD036-N11

AWSI-FBD036-N11

AWAU-YLD036-H13

Twin-rotary

Mitsubishi

AWAU-YLD048-H13

Twin-rotary

Mitsubishi

AWSI-DCD048-N11

AWSI-FBD048-N11

AWSI-CBD048-N11

AWAU-YLD060-H13

Twin-rotary

Mitsubishi

AWSI-DCD060-N11

External Appearance

General Information 3

2. External Appearance

2.1 Indoor Units

Compact Four-way cassette

Super slim cassette

Ceiling-Floor

Console

Duct(12000-48000Btu/h)

Duct(60000Btu/h)

External Appearance

4 General Information

2.2 Outdoor Units

Single fan outdoor unit

Double fan outdoor unit

Product specification

6 General Information

Model Indoor Unit

AWSI-XAD012-N11

Model Outdoor Unit

AWAU-YLD012-H11

Installation Method of Pipe

Flared

Characteristics

Units

Cooling

Heating

Average

Capacity (1)

3.5

3.6

Pdesign

3.5

SEER /SCOP (2)

W/W

6.1

3.8

Energy efficiency class

A++

Annual energy consumption

kWh

201

1290

Tbiv

N/A

-7

Tol

N/A

-15

Power supply

V/Ph/Hz

220-240V/Single/50Hz

Circuit breaker rating

INDOOR

Fan type & quantity

Centrifugal fan x1

Fan speeds

H/M/L

RPM

810/780/680/530

Air flow (3)

H/M/L

m3/hr

700/640/560/440

External static pressure

Min-Max

Sound power level (4)

H/M/L

dB(A)

Sound pressure level(5)

H/M/L

dB(A)

44 / 40 /36

Moisture removal

l/hr

1.5

Condensate drain tube I.D

ODФ16

Dimensions

WxHxD

700x600x210

Weight

Package dimensions

LxWxH

810x305x710

Packaged weight

Stacking height

units

8 levels

OUTDOOR

Refrigerant control

Capillary +EXV

Compressor type. model

Rotary DC Inverter

Fan type & quantity

Axial x 1

Fan speeds

H/L

RPM

850

Air flow

H/L

m3/hr

2200

Sound power level(4)

H/L

dB(A)

Sound pressure level(5)

H/L

dB(A)

Dimensions

WxHxD

760x590x285

Weight

35.4

Package dimensions

LxWxH

887x355x645

Packaged weight

37.9

Stacking height

units

4 levels

Refrigerant type

R410A

Refrigerant charge (standard connecting tubing length)

kg(5m)

1.1

Additional charge per 1 meter

gr / 1m

Connections between units

Liquid line

In.(mm)

1/4"(Φ6.35)

Suction line

In.(mm)

3/8"(Φ9.52)

Max.tubing length

Max.20

Max.height difference

Max.10

Operation control type

Remote control

Product specification

General Information 9

Model Indoor Unit

AWSI-XAD018-N11

Model Outdoor Unit

AWAU-YLD018-H11

Installation Method of Pipe

Flared

Characteristics

Units

Cooling

Heating

Average

Capacity (1)

4.7

Pdesign

4.7

SEER /SCOP (2)

W/W

5.6

3.8

Energy efficiency class

A+

Annual energy consumption

kWh

294

1842

Tbiv

N/A

-7

Tol

N/A

-15

Power supply

V/Ph/Hz

220-240V/Single/50Hz

Circuit breaker rating

10+16

INDOOR

Fan type & quantity

Centrifugal fan x1

Fan speeds

H/M/L

RPM

900/850/780/700

Air flow (3)

H/M/L

m3/hr

740/700/640/560

External static pressure

Min-Max

Sound power level (4)

H/M/L

dB(A)

Sound pressure level(5)

H/M/L

dB(A)

45/ 42 /39

Moisture removal

l/hr

2.0

Condensate drain tube I.D

ODФ16

Dimensions

WxHxD

700x600x210

Weight

Package dimensions

LxWxH

810x305x710

Packaged weight

Stacking height

units

8 levels

OUTDOOR

Refrigerant control

Capillary +EXV

Compressor type. model

Rotary DC Inverter

Fan type & quantity

Axial x 1

Fan speeds

H/L

RPM

800

Air flow

H/L

m3/hr

2500

Sound power level(4)

H/L

dB(A)

Sound pressure level(5)

H/L

dB(A)

Dimensions

WxHxD

845x700x320

Weight

Package dimensions

LxWxH

965x395x755

Packaged weight

Stacking height

units

3levels

Refrigerant type

R410A

Refrigerant charge (standard connecting tubing length)

kg(5m)

1.8

Additional charge per 1 meter

gr / 1m

Connections between units

Liquid line

In.(mm)

1/4"(Φ6.35)

Suction line

In.(mm)

1/2"(Φ12.7)

Max.tubing length

Max.30

Max.height difference

Max.20

Operation control type

Remote control

Features

30 General Information

4. Features

4.1. To meet Europe A level, actual EER/COP of new product with BLDC motors of indoor & outdoor unit and

DC compressor will be higher than 3.4.

4.2. Low ambient kit is standard for outdoor units

4.3. Network control function is standard for the indoor units.

4.4. Standard auto restart function and follow me function.

4.5. Slim cassette with standard remote controller, wire controller and CCM for optional. Med Duct and

HESP duct with standard wired controller, remote controller and CCM for optional.

4.6. Standard anti-cold air function.

4.7. Standard auto defrosting function.

4.8. Standard self-diagnose function.

4.9. Standard timer function and sleep mode function controlled by controller.
