AirLive VS-100 Manuel utilisateur
VS-100
H.264 PoE Video Server
Use
r
’s Manual
Copyright and Disclaimer
Copyright & Disclaimer
No part of this publication may be reproduced in any form or by any means, whether
electronic, mechanical, photocopying, or recording without the written consent of OvisLink
Corp.
OvisLink Corp. has made the best effort to ensure the accuracy of the information in this
user’s guide. However, we are not liable for the inaccuracies or errors in this guide.
Please use with caution. All information is subject to change without notice
All Trademarks are properties of their respective holders.
Table of Contents
i AirLive VS-100 User’s Manual
Table of Contents
1. Overview...................................................................................................1
1.1 Introduction..............................................................................1
1.2 Product Features and Specification.........................................2
1.3 System Requirement...............................................................4
2. Package Contents and Installation ........................................................5
2.1 Package Contents...................................................................5
2.2 Hardware Overview.................................................................6
2.3 Hardware Installation...............................................................8
2.4 Search and Set up by IPWizard II .........................................11
2.5 Using UPnP of Windows® XP or Vista..................................16
3. Remote Access to VS-100.....................................................................17
3.1 Router....................................................................................17
3.2 Access the VS-100 via Internet Explorer...............................18
3.3 Logging in as an User............................................................19
3.4 Logging in as an Administrator..............................................19
4. Operating the Video Server...................................................................20
4.1 Live View ...............................................................................20
4.2 Administrating the Video Server............................................28
Appendix A: Alarm I/O Connector..............................................................73
A.1 Interfacing to the External I/O ...............................................73
A.2 Explanation of External I/O Circuit Diagram..........................74
Appendix B: FAQ .........................................................................................75
Appendix C: PING IP Address ....................................................................81
Appendix D: Bandwidth Estimation...........................................................82
Appendix E: Power Line Frequency...........................................................83
Appendix F: 3GPP........................................................................................85
1. Overview
1 AirLive VS-100 User’s Manual
1 1. Overview
1.1 Introduction
The VS-100 is an inexpensive fully scalable surveillance technology. Because the Video
Servers can be plugged into your existing local area network infrastructure, you will
potentially save thousands of dollars on unnecessary cabling.
The device is accessible via the LAN or Internet connection. Connect your Video Server
directly to a local area network or xDSL modem, and with Microsfto® Internet Explorer you
get instant, on demand video streams. Within minutes you can set up the device to capture
a video sequence to a PC. The live video can be uploaded to a website for the world to see.
1. Overview
AirLive VS-100 User’s Manual 2
1.2 Product Features and Specification
Feature Summery
zUpgrade your CCTV camera to network-enabled camera
zSupport up to D1 resolution
zMultiple H.264, Motion JPEG and MPEG-4 video streams
zSupport 802.3af Power over Ethernet function
zOne MicroSD slot for store video clips locally
zSupport RS-485, Digital Input and Digital Output for additional control
zUPnP and setup wizard for easy installation
zAddition 12V DC output for powering camera
z64 channel surveillance software
Specification
Model Name VS-100
Video Encoder H.264, MPEG4 and Motion JPEG simultaneously
(Tri-encoders)
Video Profile
9 profiles simultaneously
- H.264 4CIF / CIF / QCIF
- MPEG4 4CIF / CIF / QCIF
- M-JPEG 4CIF / CIF / QCIF
Frame Rate Up to 30fps for all profiles
Image Setting
De-interlace (4CIF resolution)
De-noise
Brightness, sharpness, contrast, color
Text, time and date overlay
Streaming Simultaneously multi-profile streaming
Streaming over UDP, TCP, or HTTP
Multicast streaming
M-JPEG streaming over HTTP
Supports 3GPP mobile surveillance
Controllable frame rate and bandwidth
Constant and variable bit rate (MPEG4 / H.264)
1. Overview
3 AirLive VS-100 User’s Manual
Audio
Audio Encoder RTSP: G.711 64kbps, G.726 32kbps
3GPP: AMR
Audio Streaming One-way or two-way
Audio Input Built-in or external microphone
Audio Output Line level out
Network
Supported Protocols TCP, UDP, HTTP, SMTP, FTP, NTP, DNS, DDNS, DHCP,
ARP, Bonjour, UPnP, RTSP, RTP, RTCP, PPPoE, 3GPP,
ICMP, IGMP, SAMBA
Security Password protection, IP address filtering, user access log
Users 20 simultaneous unicast users
Two-level user privilege
Ethernet 10/100M auto negotiation
System Integration
Alarm Triggers Intelligent video motion detection and external input
Motion Detection 10-zone video motion detection
Alarm Events
File upload via FTP or email
Notification via email, HTTP, and TCP
External output activation
Go to PTZ preset position
Audio alerting output
Video Buffer Pre- and post- alarm buffering
General
Power Supply 12V DC external power adapter
Power Consumption 4W
Connectors
RJ-45 10BaseT/100BaseTX , DC jack
1 alarm input and 1 output
RS485
External MIC in
Audio line out
Video out
Micro SD card
12V DC output (400mA max.)
Operating
Temperature 0°C ~ 40°C
Operating Humidity 20% ~ 80% (non-condensing)
Dimension 125X90X31mm (HXWXD)
1. Overview
AirLive VS-100 User’s Manual 4
Viewing System
OS Windows® XP, Vista
Browser IE 6.0 or latter, Firefox 2.0 or later, Safari
Cell Phone With 3GPP player
Video Player VLC, Quick Time, Real Player, Core Player
Software
Bundled NVR
Program CamPro Express 64, CamPro HD
1.3 System Requirement
zMicrosoft Internet Explorer 6.0 or later
zMicrosoft Media Player 11.0 or later (to playback recorded file)
zVGA Monitor resolution 1024 x 768 or higher
zPentium-4 2.0 GHz or higher
zMemory Size: 512MB or more
zWindows XP, Vista
2. Package Contents and Installation
5 AirLive VS-100 User’s Manual
2.1 Package Contents
User can find the following items in the package as below:
zVS-100 is the main element of the product.
zPower Adapter dedicates 12V DC electric power output to Video Server.
zPower cable for external camera to supply 12VDC power to external camera.
zA/V Cable is for audio line output (white cable) and video output (yellow cable).
zUser’s Manual CD provides important information and instructions for operating the
Video Server.
zQuick Start Guide provides important information and instructions for installing this
device.
Note: Using a power supply with a different voltage than the one included with the Network
Camera will cause damage and void the warranty for this product.
2 2. Package Contents
and Installation
2. Package Contents and Installation
AirLive VS-100 User’s Manual 6
2.2 Hardware Overview
Front Side
LAN Socket
The LAN socket is a RJ-45 connector for connections to 10Base-T Ethernet or 100Base-TX
Fast Ethernet cabling. This Ethernet port built N-Way protocol can detect or negotiate the
transmission speed of the network automatically. Please use Category 5 “straight through”
cable to connect the Video Server to a 100Mbps Fast Ethernet network switch or hub. Note
that, in case you need to connect the device to PC or notebook directly, you should use
“cross-over” cable instead.
Video-in Jack
You can Install 1 video camera and connect it to video-in jack.
12VDC-Out Jack
The output power is 12VDC. This is used to supply 12VDC power to one external camera.
The output power is 12VDC/400mA maximum.
2. Package Contents and Installation
7 AirLive VS-100 User’s Manual
DI/DO/RS485 and DI/DO Connector
The Video Server provides a terminal block with 6 pins of connectors for DIDO and RS485.
Please refer to the Appendix B in this manual for more information.
Bottom Side
Audio in Jack
Audio in (microphone) jack allows an external microphone attached to this device.
Micro SD Card Slot
User can insert a micro SD card into this slot for event recording.
Status LEDs
The Status LED will turn green while system is booting up successfully.
This LED is also used to indicate the status of Network connection. The LED will flash
green while some one accesses this Video Server.
