AIPTEK 5300 Manuel utilisateur
1
Welcome
Dear user, thanks for purchasing this product.
Much investment in time and effort has gone into its development,
and it is our hope that it will give you many years of trouble-free service.
Safety Notice
1. Do not drop, puncture or disassemble the
camera; otherwise the warranty will be voided.
2. Avoid all contact with water, and dry hands
before using.
3. Do not expose the camera to high temperature
or leave it in direct sunlight. Doing so may
damage the camera.
4. Use the camera with care. Avoid pressing hard
on the camera body.
5. For your own safety, avoid using the camera
when there is a storm or lightning.
6. Avoid using batteries of different brands or
types at the same time. This may lead to the
potential for serious damage.
7. Remove batteries during long periods between
usage, as deteriorated batteries may affect the
functionality of the camera.
8. Remove batteries if they show signs of leaking
or distortion.
9. Use only the accessories supplied by the
manufacturer.
10. Keep the camera out of the reach of infants.
Get user manuals: See SafeManuals.com
2
Table of Contents
Welcome .......................................................................... 1
Safety Notice ................................................................... 1
Table of Contents ........................................................... 2
Getting Started ................................................................ 4
Knowing your camera parts .................................................................. 4
Loading batteries .................................................................................. 5
Inserting a SD/MMC card (optional) ..................................................... 6
Attaching the wrist strap (optional) ....................................................... 7
Basic Operations ............................................................ 8
Turning on your camera ........................................................................ 8
Turning off your camera ........................................................................ 8
Using the LCD monitor ......................................................................... 9
Reading the LCD indicators .................................................................. 10
Setting language ................................................................................... 11
Recording a video clip .......................................................................... 12
Taking a still picture .............................................................................. 14
Recording a voice clip .......................................................................... 17
Playing back your recordings ............................................................... 18
Connecting the camera to a TV ............................................................ 20
Advanced Operations .................................................... 21
Menu operation ..................................................................................... 21
Menu illustration ................................................................................... 21
Setting video resolution ........................................................................ 22
Setting picture resolution ...................................................................... 23
Setting white balance ........................................................................... 24
Setting exposure compensation ........................................................... 25
Setting image effect .............................................................................. 26
Setting date stamp ................................................................................ 27
Deleting files ......................................................................................... 28
Viewing file information ......................................................................... 29
System Settings ............................................................. 30
System menu items .............................................................................. 30
Setting date and time ............................................................................ 31
Setting LCD brightness ......................................................................... 31
Toggling OSD on or off ......................................................................... 32
Toggling beep sound on or off .............................................................. 32
Get user manuals: See SafeManuals.com
3
Table of Contents
Setting flicker ........................................................................................ 33
Setting language ................................................................................... 33
Setting auto-off option ........................................................................... 34
Restoring factory defaults ..................................................................... 34
Formatting storage medium .................................................................. 35
Copying Files to Your PC ............................................... 36
Installing the driver to your PC ............................................................. 36
Connecting the camera to your PC ...................................................... 38
Copying files to the PC ......................................................................... 39
Viewing/Playing files on your PC .......................................................... 41
File location .......................................................................................... 42
Using PC Camera ........................................................... 43
Installing the software ........................................................................... 43
Starting the application ......................................................................... 43
Using DV 5300 PC Camera .................................................................. 46
Addenda .......................................................................... 49
Troubleshooting .................................................................................... 49
Flicker Settings ..................................................................................... 52
Battery Life Indicator ............................................................................. 52
Storage Capacity .................................................................................. 53
System Message .................................................................................. 54
Specifications ....................................................................................... 55
Get user manuals: See SafeManuals.com
getting started
4
Getting Started
Knowing your camera parts
Record button ( )
Microphone
Up/Down buttons ( )
Menu/OK button ( )
Strap hook
Shutter button ( )
Back LED
Mode button ( )
Power button ( )
USB/AV-out port
Port cover
LCD panel
Lens
Focus switch
Flash strobe
Front LED
Speaker
Battery/Card
compartment cover
Bottom
View
Get user manuals: See SafeManuals.com
5
getting started
Loading batteries
1 Open the battery
compartment cover.
Slide the battery compartment
cover open in the direction of
indication.
2 Install batteries.
Place two AAA batteries into
the compartment. Note that the
positive(+) and negative(-) ends
cannot be reversed.
3 Replace the cover.
After the batteries are properly
installed, replace the battery
compartment cover.
Do not use different types or brands of batteries at the same time.
Alkaline batteries or rechargeable NiMH batteries are
recommended for high performance.
Get user manuals: See SafeManuals.com
getting started
6
Inserting a SD/MMC card (optional)
In addition to the built-in flash
memory, your camera can store
data on a Secure Digital (SD) card
or a MultiMedia card (MMC).
To insert a memory card, gently
push the card as indicated until
the card reaches the bottom of the
slot. When the card is successfully
inserted, a icon will appear on
the LCD. To remove the memory
card, gently push the card and it
will pop up. Then pull the card out
of the slot.
The SD card comes with a write-protect switch. When the write-
protect switch is set to the Lock position, the card will become
non-writable. To ensure that the camera can operate normally,
you should set the write-protect switch to the Unlock position
before inserting the SD card.
Do not remove the SD/MMC card while the camera is processing
data (when the LED indicates red light).
When a SD/MMC card is inserted, the camera will use the card
as the main storage medium. Files stored in the camera’s built-in
memory will become inaccessible until the SD/MMC card is
removed.
Get user manuals: See SafeManuals.com
7
getting started
The wrist strap provides a convenient way for you to carry your
camera around.
1 Stretch out the strap hook.
Hold your camera upside down, and the
strap hook will stretch out.
2 Thread the strap through the
hook.
Thread the thinner part of the strap through
the strap hook as illustrated. Threading in
the indicated direction will save you much
time as the hook will remain stretched in
this way.
3 Thread the strap through the
loop.
Thread the other end of the strap through
the loop, and you are ready to carry your
camera with ease.
Attaching the wrist strap (optional)
hook
Get user manuals: See SafeManuals.com
basic operations
8
Basic Operations
Turning on your camera
Rotate the LCD panel as indicated. Then press and hold down
the power ( ) button for 2~3 seconds to turn on the camera.
Turning off your camera
Press and hold down the power ( ) button for 2~3 seconds to
turn off the camera.
OR
If the camera stays inactive for a long period of time, it may
automatically shut down due to the Auto-Off setting. See page
34 for more information.
If the camera is not turned on after pressing the power button,
please check:
1. There are two AAA batteries installed in the camera.
2. The batteries have enough power left.
3. The polar(+ -) directions of the installed batteries are correct.
Get user manuals: See SafeManuals.com
basic operations
9
Using the LCD monitor
The LCD monitor can be used to compose image settings for
shooting, to review recorded files, or to change menu options.
The LCD panel can be rotated to the
following positions:
1 Initial position.
In this position, the camera is suitable for
taking self-portraits.
2 Rotate the LCD panel.
The LCD panel can be rotated up to 270
degrees as indicated. You can position the
panel at any angle to serve your filming
purpose.
3 Normal position.
Normally, the LCD panel is rotated 180
degrees to face the user, so that the user can
get a clear preview on the LCD.
270
When the LCD panel is flipped over, the previewed image on the
LCD will be automatically adjusted.
Get user manuals: See SafeManuals.com
