The JP-DVF-PR is a JP Series video door station with a built-in AC-PROX-1G proximity card reader. The station connects directly to a

JP-4MED master station using 2-conductor wire, and the card reader uses a standard Wiegand connection to connect to a compatible

access control system.

JP-DVF-PR

INSTALLATION GUIDE

1. Camera

2. Microphone

3. White LED for low light illumination

4. Speaker

5. Directory card

6. Call button

7. Card reader

• PTZ camera

• Stainless steel faceplate

• Built-in RFID card reader

Features

For ush mounting, recess the supplied back box into the wall,

then attach the mounting bracket using the four provided bracket

screws.

Back Box Dimensions: 10-1/2" H x 5-13/16" W x 2-5/16" D

JP-DVF-PR Dimensions: 11-11/16" H x 7" W x 2-1/16" D

For surface mounting, use the SBX-IDVFRA surface mount box.

This box can mount to a standard single-gang box or to any at

surface.

To insert the transparent nameplates, remove the vandal-

resistant front panel from the ush mount back box. Peel o󰀨 the

protected seals from both sides of the plate. Write in the desired

text, being sure to leave 1" of white space on the right side.

Insert the nameplate into the opening.

Installation

Package Contents

JP-DVF-PR

Door Station

Security Driver

Transparent

nameplate (2)

Flush mount backbox

and tamper-resistant screws

JP-DVF-PR Names and Functions

For more details about the features and information above, please contact Technical Support.

205/23

Aiphone Corporation | www.aiphone.com | (800) 692-0200

Wiring Diagram

Card Reader

Reader Type: 125kHz Proximity Card

Reader

Reader Model: AC-PROX-1G

Power Source: 5 ~ 16V DC

Current: 30mA (average); 75mA (peak)

Terminations: Color-coded pre-wired pigtail

Wiring Distance: 500'

Operating Temp: -31°~150°F (-35°~66°C)

Operating Humidity: 0% to 90% relative humidity

non-condensing

Connect theConnect the

reader to thereader to the

access controlaccess control

host accordinghost according

to the host'sto the host's

installation guide.installation guide.

1A1

1A2

FCC WARNING:

This device complies with Part 15 of the FCC rules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference.

(2) This device must accept any interference that may cause undesired operation.

For proper regulatory compliance, the drain wire should be disconnected at the power supply end of the cable.

Changes or modications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

Wiegand Wiring

Conductor Function

Red 5 ~ 16V DC

Black Ground

Green Data 0

White Data 1

Brown Red LED

Orange Green LED

Yellow Card Present

Blue Beeper

Violet eaPower

Drain Shield Ground

Specications

Door Station

Camera Unit: 1/4" color CMOS

Scanning Line: 525 lines

Min. illumination: 5 Lux

Terminations: Screw terminals

Operating Temp: -4°~140°F (-20°~60°C)

Wiring Distance: 330'

Dimensions: 11-11/16" H x 7" W x 2-1/16" D

w/ SBX-IDVFRA: 11-11/16" H x 7" W x 3-5/16" D

JP-4MED

JP-DVF-PR

Access

Control Host PS-2420UL
