INSTRUCTION MANUAL
1
BLACKBIRD 250
3
SPECS
· Frame diagonal size: 250 with stock arms, 270mm with 6in props arms,
330mm with 7in props arms
· Weight: 192g (approx)
· Materials: G10 and Aluminum. (optional CF version)
· Stainless steel fasteners.
· Props size: 5in with stock arms. 6in and 7in with optional arms
· Flight controller mount : 30.5mm x 30.5mm
· Motor mounting: M2 12mm—16mm, M3 12mm—19mm
· Inside battery mounting space: 110mm x39 mm x 32mm (LxWxH)
Key Features:
· Strong “BOX” frame construction to protect the FPV camera and electronics.
· Innovative frame geometry for the 250 FPV racing class.
· Two position motor angle for fast forward speeds.
· Vibration isolated mounting plate for FPV cameras of 32mmx32mm (LxW) or less. Mobius camera mounting slots .
· Innovative electronics layout. ESC’s can be mounted on the side of the frame.
· Unique adjustable battery position and quick battery mounting with single velcro strap.
· Compatible with any 30.5mmx30.5mm mount spacing controllers, and other electronics. CC3d, Naze 32.
· Fits 5in props. 6in and 7in with optional extended arms.
· Rubber landing supports for low profile flying and soft landing.
· Arms accept any mini size motors with mounting dimensions of M2 12mm-16mm and M3 12m to 19mm
· Mini Hex upgradable with optional Hexa arms kit
· Full support of AIMDROIX optional accessories.
X1 X1
1 X1
3
2 4 X4
5 6
X1 11
X2
8
X3
9
X2 X4
7
X2
REQUIRED PARTS
*Images are not at real scale*
X1
10
X4
6
M3 x 20mm
PLASTIC
M3 x 16mm M3 x 12mm M3 x 8mm
M3 PLASTIC NUT
M3 NYLON
LOCK NUT
6
FASTENERS
M3 x WASHER
TL
Threadlock
Recommended
(TL)
M3 x 6mm
39mm
STANDOFF
32mm
STANDOFF
8mm PLASTIC
SPACER
LANDING SUPPORTS
SIDE PLATES TO BOTTOM PLATE
2
11
M3x12
18
M3 NUT
X4
7
X 3
18
TOP TO BOTTOM PLATE STANDOFFS
PDB AND FC ASSEMBLY
M3x6
8
M3x6
32mm
STANDOFF
X2
M3 x 20mm
PLASTIC
X4
M3 PLASTIC NUT
X4
8mm PLASTIC
SPACER
X4
TL
IS NOT NECESARRY TO INSTALL THE FLIGHT
CONTROLLER ON THIS STEP. IT’S SHOWN ONLY
AS A REFERENCE.
ARMS SHAFTS ASSEMBLY
ARM TO FRAME ASSEMBLY
9
9
4
10
x2
REAR SHAFT
FRONT SHAFT
17mm
APPLY CA GLUE
REAR ARM
FIXING PLATE
9
10
ARMS
ARMS TO SHAFT
39mm
standoff
M3x6
39mm
standoff
10
M3x6
TL
M3x6
M3x6
M3x16
X 8
M3 Nylon lock X 8
M3
WASHER
X 8
TL
5
MAIN FRAME ASSEMBLY IS NOW COMPLETE
CAMERA PLATE
11
AT THIS LEVEL, YOU CAN NOW START
INSTALLING THE MOTOR S, ESC,
RECEIVER, AND OTHER ELECTRONICS
THAT YOU WANT TO HAVE IN YOUR
BLACKBIRD 250.
1
7
8
FPV CAMERA MOUNT
12
CAMERAS AND VTX CONFIGURATION EXAMPLE
FPV CAMERA BRACKET NOT INCLUDED.
WE OFFER CUSTOM MOUNT FOR FPV
CAMERAS THAT DOESN’T HAVE A MOUNTING
BRACKET . PLEASE CONTACT US AT
M3 Nylon lock
M3x6
MOBIUS OR RUNCAM HD
CAMERA
VIDEO TRANSMITTER
WE ARE WORKING HARD TO COMPLETE THIS
MANUAL . MORE DETAILS WILL BE ADDED DAILY
UNTIL THE MAUAL IS COMPLETEDED. IF YOU
NEED ASSITANCE ON YOUR CURRENT BUILD, YOU
CAN CONTACT US AT support@aimdroix.com .
USE THE PICTURES LOCATED IN THE WEBSITE AS
REFERENCE.
