AGPtek W20 Manuel utilisateur
AGPTEK
User Manual
English 01 | Deutsch 17 | Francais 36 | Italiano 54 | Español 72
Kids Smart Watch
Model: W20
1
Thank you for purchasing this product. Please read this user manual carefully before
use and keep this instruction for future reference. If you have any problem about this
In The Box
Watch*1, USB Cable*1, Transparent Film*1, User Manual*1
Product Diagram
Flashlight
Camera
Mic
Home Button
Reset Button
SIM Card Slot
Micro USB Port
2
Charging
Remove the rubber protective cover on the USB charging port, and then connect the
Micro-USB end of USB charging cable to the watch and the other end to the USB
charger.
1.Charging Voltage≤5V-1A.
2.After the charger is plugged to the power socket, the power icon at the top right of
the screen will start scrolling, which indicates that it is in charging mode. The
power icon will stop scrolling with a full battery icon when fully charged.
3.Charging and data transmission options will appear when it is connected to
computer for charging. Select the charging option.
Install A SIM Card
Shutdown first. And remove the dust cover. Then follow the direction of the arrow
and insert a Nano SIM card into the slot. Finally, install the cover.
3
⚝The SIM card must support 2G GSM, or the function of communication will not be
available!
⚝SOS Function. On the Clock Interface, continuously press the home button twice
to dial the first number of the Contacts.
Basic Operation
Power on: Long press the home button to turn on the watch.
Power off: When on Clock Interface, long press the home button to turn off the
watch.
4
Light up screen/Return: Short press the home button .
If the device fails to turn on, this could be caused by low battery. Please try again
after recharging the device for 20 minutes.
Full Touch Screen: 1.54 Inch full touch screen, swipe left and right on the interface to
turn pages. Tap on the function icon to enter the function.
When on Clock Interface, swipe down the screen, tab the trumpet icon , and it will
switch to the mute mode.
Bright Screen Time: The bright screen time can be set in Settings, and there are 5
choices: 15s/30s/45s/60s/constant. When there is no operation, the screen will be
dark, and press the home button to brighten it.
Clock Display
When the home button is pressed, the clock will be displayed. Tap the center of
the screen to switch the clock interfaces between analog and digital. Swipe left or
5
right on the screen to see more clock interfaces. When the watch is on clock interface,
press the home button to go to the home menu for selecting different function.
Analog clock interfaces Digital clock interfaces
Function Introduction
1. Dial
Tap to input and dial the number.
2. Contacts
Tap the icon to set the number for Dad, Mother or other contacts. After the
6
number has been input, click “SAVE” to save the number. To make a phone call, just
click on the image of corresponding contact.
Note: 10 contacts can be stored at maximum.
3. Recents
All recent calls can be found here .
4. Camera
Start record the memories by taping on home menu.
Tap to take a photo.
Tap to view the photos.
5. Pictures
All image files can be viewed here . Tap the arrow icon on the screen to move to
the previous or next image. Tap on the screen to delete.
6. Music
7
Kindly Remind: Music Player will be workable after inserting SD card including
Music.
To upload music to the watch, copy any MP3 music files to the watch folder "My
Music" into the SD Card. Then insert the SD Card into the watch.
1) Tap to begin playing.
2) Tap to stop music.
3) Tap to increase the volume.
4) Tap to decrease the volume.
5) Tap to move to the previous or next song. Press and hold to fast
reverse or fast forward.
6) Tap at the bottom of the screen to return to the menu.
How to operate the music accessory function:
Tap the bottom left icon to enter the music list. "Options":
8
A. Play: Start playing music.
B. Details: Check the detailed information of songs stored in the built-in memory
card.
C. Refresh List: Playlist update. If not displayed in the music list after importing songs,
tap here.
D. Settings:
a. Priority list: Choose watch or memory card.
b. Create list automatically:
On: If you select “Watch'' in A item, the songs in the main unit will be automatically
played as a list. If you select "Memory card", the songs in "My Music" are
automatically played as a list.
Off: Create your own "My Music" list (If you select OFF, tap "Save" at the bottom left to
enter the list management screen. Then tap "Options" to perform the following
